- Page 1 TwinLock compact Manual TwinLock compact Manual EN 1300 M 106302 / M 106301 G 106016 / G 106015 Class 2 / C Version 1.06...
- Page 2 Trademarks and logos The use of a trademark or logo not shown below does not indicate that it is freely available for use. INSYS ® is a registered trademark of INSYS MICROELECTRONICS GmbH. Windows™ is a registered trademark of Microsoft Corporation.
- Page 3 TwinLock compact Manual The manual contains detailed information for the operation and the programming of the high-safety lock TwinLock compact and is mainly intended for the system MASTER responsible for the system configuration and administration. For users, we recommend the Quick Reference Guide. The concise document contains all important information required for normal system operation in short form.
-
Page 4: Table Of Contents
TwinLock compact Manual Table of contents 1. SYSTEM DIAGRAM ............................6 2. SYSTEM DESCRIPTION..........................7 2.1. I ......................... 7 NPUT ONTROL 2.2. L ........................7 OCK COMPACT 2.3. B ......................7 ISTRIBUTOR ONNECT 2.4. E XT.......................... 8 XTENSION 2.5. C ) .......................... - Page 5 TwinLock compact Manual 7.4. D ..........................58 ISPLAY VENT 7.5. U ........................59 ANAGEMENT 7.6. C ....................... 60 USTOMER ANAGEMENT 8. TECHNICAL DATA ............................61 Revision History Support / Hotline Version 1.06...
-
Page 6: System Diagram
TwinLock compact Manual 1. System Diagram TwinLock compact – 1 lock with 12 VDC power supply / TwinXT optional TwinConnect TwinXT TwinLock TwinLock compact – 2 locks with 12VDC power supply / TwinXT optional TwinConnect TwinXT TwinLock TwinLock Version 1.06... -
Page 7: System Description
TwinLock compact Manual 2. System Description TwinLock compact is an electronic high safety lock system with integrated arming device for a burglary alarm system class 3/C. It is a modular system. The security-relevant system parts are designed fully redundant. The system consists of the following components: Control units = Terminals locks Bus distributor = Connector for the individual components (hub) -
Page 8: Extension Unit : Twinxt
TwinLock compact Manual 2.4. Extension Unit : TwinXT The TwinLock compact system can be extended by 2 inputs and 2 outputs by means of the extension unit TwinXT very easily. Basically, a TwinXT can be connected to each lock in the system. Consequently, each lock can be specifically locked or released, and each lock can have a bolt system contact. -
Page 9: Chip Cards (Twincard)
TwinLock compact Manual 2.5. Chip Cards (TwinCard) TwinCard code access Chip card as ‘physical code’ to disarm a BAS. The code is changed continuously. TwinCard configuration Chip card for the system configuration and the event log. In cooperation the with PC software TwinComm, the configuration can be imported or exported and the log can be read out. -
Page 10: Configuration Set Twincomm
TwinLock compact Manual 2.6. Configuration Set TwinComm The TwinLock compact system can be configured fast and conveniently using the program TwinComm in connection with the chip card reader of the configuration set and the chip card TwinCard configuration. All settings and the event log can be displayed, printed and saved. -
Page 11: Function Description
TwinLock compact Manual 3. Function Description Code and Locking Functions 1 Master code per lock 1 System code 99 User codes per lock Status indicator for programmed user codes Code linking (Four-eye code ) Silent alarm Code manipulation detection Quick unlocking code Opening duress (forced sequence) Parallel code Automatic lock with door switch... -
Page 12: Code And Locking Functions
TwinLock compact Manual 3.1. Code and Locking Functions Master code Each lock has a master code (ID = 00 + 6-digit master code). The master code has the authorization to program lock-specific procedures (e.g. time delay, user codes, etc.) or to unlock, respectively. The master code can not be deleted or deactivated. - Page 13 TwinLock compact Manual Quick opening code A user can be assigned the function of the quick opening code, which circumvents a programmed time delay. The user who has stored the code with number 09 has the quick opening code by default. Code distribution in the TwinLock 7220 system lock 1 1 Systemcode =...
- Page 14 TwinLock compact Manual Parallel code For a 2 lock system, the function ‘parallel code’ can be programmed. This function can only be configured via the PC software TwinComm. In this case, the unlocking codes apply to 2 locks, e.g. the user does no longer need to select a lock, and he is not bound to a specific lock.
-
Page 15: Timer Functions
TwinLock compact Manual 3.2. Timer Functions Time delay Unlocking delay, individually configurable (00 - 99 min.). A release time (00 - 99 min.) can be programmed for each unlocking delay. After the time delay expiration an unlocking code must be re-entered. The programming is performed by the system manager. -
Page 16: Service Functions
TwinLock compact Manual 3.3. Service Functions Event Log The latest 768 events (programming processes, hardware errors, and certain status messages, manipulation and sabotage attempts) are logged in chronological order, including date and time (perhaps the user number). There is also the possibility to transfer the entire event memory to the TwinCard configuration. -
Page 17: Operational Safety
TwinLock compact Manual 3.4. Operational Safety Redundancy A dual bus system and a dual electronic and mechanical locking system in the locks guarantee high system stability. The two identical system parts are completely independent from each other and can therefore function individually. Voltage monitoring When the power supply is applied or when the system recovers from energy saving mode, the state of the battery (system voltage) is checked. - Page 18 TwinLock compact Manual Power Failure The FlatControl receives its power supply via each of the two bus cables. When a voltage failure occurs, an emergency current feed for the entire system is possible via a jack at the bottom of the keyboard. For this, an adapter cable 7237-101-0 and a 9 volt block battery (alkaline type) is required.
-
Page 19: Sabotage Safety
TwinLock compact Manual 3.5. Sabotage safety Input unit TwinControl/FlatControl The input unit in the unsecured area is secured by different measures. Opening the case (battery compartment TwinControl) is immediately detected and displayed until an authorized user unlocks the system lock properly. A person standing next to the authorized user cannot watch the entering of the code. -
Page 20: Operation
TwinLock compact Manual 4. Operation 4.1. Display and Control Elements of the Input Equipment LC-Display Background lighting Menu keys Keypad Emergency power Insertion of the chip card Chip at the bottom Version 1.06... - Page 21 TwinLock compact TwinLock compact TwinLock compact TwinLock compact TwinLock compact TwinLock compact TwinLock compact Mo 15.09.08 11:15 open close status / info configuration service import / export configuration system date/time Reset configuration service mastercodes motor-service configuration service managercode install new lock user codes configurations service...
-
Page 22: General Operating Instructions
TwinLock compact Manual 4.3. General Operating Instructions System Activation When idle, the TwinLock System is activated by operating a menu key at the control unit. After the activation, a system check is performed and the individual states of the connected locks and of the TwinLock system are displayed. system check system check lock opened 01... - Page 23 TwinLock compact Manual System Menu The start page of the menu structure is called system *** TwinLock *** menu . The system menu consists of one editable line Mo 15.09.08 12:00 (line 1 = system line, which can contain individual text), and the current date/time display (line 2).
-
Page 24: General Operation Processes
TwinLock compact Manual 5. General Operation Processes 5.1. Unlocking a Lock TwinLock compact Select the menu item ‘Unlock’. open (see menu plan 4.2) open Select the lock lock 01 code entry Select the user number user no.: 02< Code entry Enter the unlock code code:****** The entry consists of 6 numbers... -
Page 25: Closing A Lock
TwinLock compact Manual 5.2. Closing a Lock Select the menu item “Close” TwinLock compact (see menu plan, 4.2.) close Select a lock close lock 01 Lock locks close Please wait close lock closed 01 With the lock closed, the system cannot be re-configured close system locked Automatic return after 3 seconds... -
Page 26: Status Request Of A Lock/ Version Request
TwinLock compact Manual 5.3. Status Request of a Lock/ version request Select the menu item “Status” TwinLock compact Status / Info (see menu plan 4.2.) Status / Info Lock closed 01 The status of the selected component is displayed. Version query SW version : TS01 With 2 locks in the system, the version of the Lock... -
Page 27: Responses
TwinLock compact Manual 5.4. Responses Unlocking Messages open No unlocking possible, because the current time is not time lock week within the time window defined in the weekly program. open No unlocking possible, because the current date coincides time lock day with the date of a defined special day. - Page 28 TwinLock compact Manual Final bolt position of the lock is not accessible at bus A System check or bus B. failure motor AB Please call customer service ! Status General lock fault. DMS XX Error Please call customer service ! General Error Messages .
-
Page 29: Programming The System With The Control Unit
TwinLock compact Manual 6. Programming the System with the Control Unit The following functions and settings can be performed using the control unit: • Reprogram master code • Reprogram manager code • Program user codes • Delete a user code •... -
Page 30: Reprogramming A Master Code
TwinLock compact Manual 6.1. Reprogramming a Master Code Select the menu item “Master Code” configuration Mastercodes (see menu plan, 4.2.) configuration Select lock lock 01 Enter the master code Mastercodes Code:****** Schlosses eingeben Mastercodes Evaluate the entry Please wait New M-Code Enter the new master code Code:****** Of the selected lock... -
Page 31: Reprogramming The Manager Code
TwinLock compact Manual 6.2. Reprogramming the Manager Code Select the menu item 'Managercode' configuration Manager Code (see menu plan, 4.2.) Select the lock configuration lock 01 Enter the Manager Code of the Manager code Code:****** Selectec lock Manager Code Evaluate the entry Please wait New Manager Code Enter the new manager code... -
Page 32: Programming And Reprogramming Of A User Code
TwinLock compact Manual 6.3. Programming and Reprogramming of a User Code The programming of the user codes is just possible if the locks are open. Select the menu item 'User Codes' configuration usercodes (see menu plan, 4.2.) usercodes programming Select programming Usercodes Select the lock lock 01... -
Page 33: Delete A User Code
TwinLock compact Manual 6.4. Delete a user code usercodes Select menu item ‘Delete user delete codes’ (see menu diagram, 4.2.) delete Select lock lock 01 Enter the user number 00 Code entry for the master code user no.: 00 Enter the master code of the old M/U code selected lock code:******... -
Page 34: Display The Programmed User Codes
TwinLock compact Manual 6.5. Display the Programmed User Codes Select the menu item ‘Display User Code’ Usercodes Anzeige Usercode ( see menu plan 4.2 Select the lock Usercodes Schloss 01 Mastercodes Enter the master code of the Code:****** selected lock Mastercodes Evaluate the entry Bitte warten... -
Page 35: Setting The Date, Time And Weekday
TwinLock compact Manual 6.6. Setting the Date, Time and Weekday Select the menu item 'Date/Time' configuration date/time (see menu plan 4.2) Enter system code System Code Code:****** System code Evaluate the entry Please wait Select time-date/weekday time: 10:01 Mo Display current settings date: 20.12.07 Activate the entry with enter Set the day of the week with menu keys... -
Page 36: Code Linkage Programming (Four-Eye-Code)
TwinLock compact Manual 6.7. Code Linkage Programming (Four-Eye-Code) Menu item 'Code Linkage' configuration code linkage select (see menu plan 4.2) Enter system code System code Code:****** System code Evaluation of the entry Please wait Select the code linkage *=yes *=No linkage type code linkage code linkage... -
Page 37: Program Unlocking Time Delay
TwinLock compact Manual 6.8. Program Unlocking Time Delay Select the menu item ‘Delay’ configuration Delay (see menu plan 4.2) Delay When several locks are available Lock 01 In the system, select one lock Master code Code:****** Enter the master code of the Selected lock Master code Please wait... -
Page 38: Program Opening Duress (Forced Sequence)
TwinLock compact Manual 6.9. Program Opening Duress (Forced Sequence) Select the menu item ’Opening duress’ configuration Opening duress (see menu diagram / see above) System code Enter system code Code:****** Systemcode Evaluate the entry Please wait Display of the current setting Forced sequence *= Yes *=No... -
Page 39: Program Silent Alarm
TwinLock compact Manual 6.10. Program silent alarm Select the menu item 'Silent alarm' configuration Silent alarm (see menu plan 4.2) Enter system code System Code Code:****** System Code Please wait Evaluate the entry Display of the current setting Silent alarm *=yes *=No and selection of the new condition... -
Page 40: Programming Activation Of Twinxt Lock I/O
TwinLock compact Manual 6.11. Programming activation of TwinXT lock I/O Select the menu item 'Lock I/O' configuration lock I/O (see menu plan 4.2 ) Systemcode Enter manager code Code:****** Evaluate the entry Systemcode Please wait Activate TwinXT locj I/O *=yes *=No Door switch Activation of the function:... -
Page 41: Reset The Input Unit
TwinLock compact Manual 6.12. Reset the Input Unit Select the menu item 'System Reset' System Reset (see menu plan 4.2.) System code Enter system code Code:****** System code Evaluate the entry Please wait Action completed Reset saved Automatic return after 3 seconds System reset: Only the owner of the manager code can perform the system reset. - Page 42 TwinLock compact Manual After a control unit has been reset, it is restarted. The system sends a prompt for re- registering. System-Setup New system To re-integrate the existing locks into the system, the menu item “Terminal switch” must be activated using the arrow keys. System setup Switch to “Terminal switch”.
-
Page 43: Lock Motor Service
TwinLock compact Manual 6.13. Lock Motor Service Select the menu item 'Motor service' Service Motor-Service (see menu plan 4.2) Select the lock Motor service Lock 01 Enter the master code of the Master code Code:****** selected lock Master code Evaluate the entry Please wait Open and close gradually Motor service... -
Page 44: Register/Replace Locks In The System
TwinLock compact Manual 6.14. Register/Replace Locks in the System Service Select the menu item ‘Reg. lock’ Reg. lock (see menu plan 4.2) Enter system code System code Code:****** System code Evaluate the entry Please wait Selection: Re-register SReg. lock Reg. lock New lock Replace lock replace a lock... -
Page 45: Write Log And Configuration To Chip Card
TwinLock compact Manual 6.15. Write Log and Configuration to Chip Card Select the menu item 'Import / Export' TwinLock compact Import / Export (see menu plan 4.2) Enter System Code Systemcode Code:****** System code Evaluate the entry Please wait Select data export Import / Export Daten - Export with the menu keys... -
Page 46: Write Log And Configuration To Chip Card
TwinLock compact Manual 6.16. Write Log and Configuration to Chip Card *** TwinLock *** Select the menu item 'Import / Export' Import / Export (see menu plan 4.2/ see above) System code Enter system Code:******** code System code Please wait Evaluate the entry Import / Export Select data export... -
Page 47: Read New System Language
TwinLock compact Manual 6.17. Read New System Language To switch the language of your system, you need an according TwinCard language. The language cards can be ordered on request. Select the menu item 'Import / Export' *** TwinLock *** Import / Export (see menu plan 4.2) Enter system System code... -
Page 48: Ignore Bolt System Position Switch
TwinLock compact Manual 6.18. Ignore Bolt System Position Switch System Central inactive Select "Yes“ Central inactive *= Yes *=No Central inactive The setting is stored Stored The bolt system position switch, which may be connected to TwinAlarm or TwinXT, is ignored for one locking procedure. -
Page 49: Activate Parallel Code
TwinLock compact Manual 6.19. Activate Parallel Code Settings Parallel code Systemcode Enter system code Code:****** System code Evaluate the entry Please wait Parallel code Display of the current setting *= Yes *=No and selection of the new condition Parllel code Save setting Saved Action completed... -
Page 50: Automatic Locking
TwinLock compact Manual 6.20. Automatic Locking The TwinLock system can be automatically locked using a door switch or a bolt system position switch. The switch is connected to a TwinXT or TwinAlarm system, depending on the system variant. In idle state (display off), the door or bolt system switch is queried periodically. Pressing the key will automatically lock the system. -
Page 51: Programming The System With The Pc Software Twincomm
TwinLock compact Manual 7. Programming the System with the PC Software TwinComm TwinCard - Configuration - The following functions can be performed with the configuration software TwinComm. General settings • Silent alarm, alarm delay • TwinXT active • Automatic switching to daylight savings time •... -
Page 52: General Operation
TwinLock compact Manual 7.1. General Operation License chip card To active the PC software you will need a license chip card, which is a part of the scope of delivery of the configuration set. After TwinComm is started, this card must be inserted into the chip card reader. - Page 53 TwinLock compact Manual To read the data from the chip card “ TwinCard configuration“, it must be inserted into the chip card reader. Then push the button “Read chip card". To save the data to the chip card “TwinCard configuration“, it must be inserted into the chip card reader.
-
Page 54: Programming Of General Settings
TwinLock compact Manual 7.2. Programming of General Settings Code linkage Programming the four-eye code principle For unlocking and programming, 2 code entries each are required Activate TwinXT Lock I/O. The inputs and outputs of the extension unit TwinXT activated queried. TwinXT must be activated for the function of automatic locking with door switch. - Page 55 TwinLock compact Manual Programming of the codes In all locks, the same codes must be programmed for the according users, e.g. user 08: Code : lock 1 : 080808 Code : lock 2 : 080808 Notes: 1. For this functionality, the explicit four-eye code (code linkage) is deactivated.
- Page 56 TwinLock compact Manual Manual locking after bolt system query Before the locking procedure, the position of the bolt system is queried using a switch. For this action, the functions TwinXT active must be programmed. TwinAlarm active not with TwinLock compact Silent alarm Activate silent alarm, time delay 01-99 minutes...
-
Page 57: Programming The Unlocking Delay
TwinLock compact Manual 7.3. Programming the Unlocking Delay For each lock, an unlocking delay of 01 – 99 minutes can be programmed. A release time of 01 – 15 minutes can be programmed as well, during which a code entry must take place after the unlocking delay has expired. -
Page 58: Display Event Log
TwinLock compact Manual 7.4. Display Event Log The following events are logged: All unlocking and locking procedures and all code entries are logged. Furthermore, all configuration procedures and manipulation attempts are logged. The log list can be printed on a connected printer or saved and archived in a file. Use the button “Update user”... -
Page 59: User Data Management
TwinLock compact Manual 7.5. User Data Management Each user of the lock can be allocated a name which is also saved in the event log. The user overview can be printed or saved administrative purposes. Version 1.06... -
Page 60: Customer Data Management
TwinLock compact Manual 7.6. Customer Data Management Customer data can be saved and archived for each programming. This means that an individual configuration file can be created for each customer. This file can be read also at a later date. Version 1.06... -
Page 61: Technical Data
TwinLock compact Manual 8. Technical Data Input Unit: FlatControl Power supply: 9 VDC Alternatively, power supply unit 12 VDC via TwinConnect Alternatively emergency power supply via mini DC jack Current consumption: Stand-by condition: approx. 30 A Input condition (display active) approx. -
Page 62: Revision History
1.06 15.09.08 Update user terminal and number of users !!! Subject to correction !!! Support / Hotline Carl Wittkopp GmbH & Co. KG INSYS Microelectronics GmbH Sternbergstr. 5 Waffnergasse 8 D – 42551 Velbert D – 93047 Regensburg Tel.: +49(0)2051 – 9566-0 Tel.: +49(0)941 –...
