- Page 1 TEA-101D TRANSMITTER Programmable temperature transmitter with 4-20 mA output Instruction Manual...
- Page 2 (not included in delivery). Program Tsensor for transmitter setting is available at ATAL B.V.. Program enables to set measured range and on/off the LCD display. It supports make the adjustment of the device too. This procedure is described at file „Calibration manual.pdf“...
- Page 3 Dimensions Typical application wiring Calculation of minimum power voltage Uss for proper operation: Uss min> Uo min+Imax*Rz, where: Uo min= 9 V Imax... approximately 20 mA Rz... sensing resistor (shunt) Choice of optimal power voltage and load resistor for current loop. area no 1..
-
Page 4: Technical Parameters
LCD Info mode Several settings of installed transmitter are possible to verify without using computer. It is necessary to connect at least power of current loop I1. Unscrew the transmitter lid and shortly press button between display and interconnection terminals by means of a tool (e.g. screwdriver). Range and type of value for output 1 (current loop I1 = symbol „1“... - Page 5 USB port of the PC. • It is necessary to have installed configuration program Tsensor on the PC, It is free available at Atal B.V.. During installation please take care about installation of driver for USB communication cable •...
- Page 6 Error 2 There is a reading „Err2“ on LCD display. Output value is about 3.8 mA. Measured value is below lower limit of allowed full scale range. This state appears if measured temperature is lower than approximately -210°C (i.e. low resistance of temperature sensor, probably short circuit). Error 3 There is a reading „Err3“...
- Page 7 Notes:...
