Satlink WS-6933 User Manual

Digital satellite finder meter
Hide thumbs Also See for WS-6933:

Advertisement

Table of Contents

WS-6933
USER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Satlink WS-6933

Summary of Contents for Satlink WS-6933

  • Page 1 WS-6933 USER‘S MANUAL...

  • Page 3: Table Of Contents

    CONTENT 1. GUIDE....................1 ..1.1.Important.Safety.Instructions..........1 ..1.2.Unpacking...................2 ..1.3.PRODUCT.OVERVIEW.&.ILLUSTRATION......2 2. OUTLINE....................4 3. THE MENU OSD INSTRUCTION..........4 ..3.1.Antenna.Setup.................5 ..3.2.Find.Satellite................5 ..3.3.Satellite.Setup................6 ..3.4.Transponder.Setup..............7 ..3.5.Calculate.Angle...............7 ..3.6.System.Setup................8 4. Technical Specification..............9...

  • Page 5: Guide

    Digital Satellite Finder 1. GUIDE 1.1 Important Safety Instructions Thank. you. for. choosing. our. product.. Before. installation,. we. would. like. to. remind. you. some. notes,. which. is. very. important.for.operating.safely.and.properly,.as.follows: Be. sure. to. read. this. user. manual. before. starting. your. operation. You.must.install.the.dish.with.correct.direction.and.angle..

  • Page 6: Unpacking

    Digital Satellite Finder 1.2 Unpacking Open.the.package.and.make.sure.it.includes.all.below.items,. if.any.missing,.please.contact.the.reseller.for.replacement. 1.Digital.SatelliteMeter 2.User’s.manual 3.USB.cable 4.Adaptor 5.Silicone.case 1.3 PRODUCT OVERVIEW&ILLUSTRATION...
  • Page 7 Digital Satellite Finder Description FUNCTION Power.Switch Turn.on/off.meter LNB.IN Connect.to.satellite.antenna.cable LCD.Screen Video.display USB.Port Connect.to.PC DC.Slot Connect.to.Adaptor.Input Digital.tube Quality.shows Power Power.indicator.light 22Khz.indicator.light 22KHZ Vertical.polarization.voltage.output. light Horizontal.polarization.voltage.output. light LOCK Signal.lock.indicator.light Charger Charger.indicator.light.. OK.KEY RETURN RETURN.KEY Right.KEY ◄ DOWN.KEY ▼ Left..KEY ► ▲ Up.KEY Torch Torch..

  • Page 8: Outline

    Digital Satellite Finder 2. OUTLINE Digital.meter.for.signal.strength.and.quality Sound.and.Light.Alarm.for.Locking.Signal Auto.Calculate.Angle.of.AZ.,EL Supports.DISEQC.1.0/1.1.,0/22khz.Tone Beep.Integrated LNB.short.protect 7.4V/800mAh.Li-Ion.Battery.Included Software.upgrade.via.USB.port Easy.to.carry 3. THE MENU OSD INSTRUCTION If you have installed and connected the cables of the meter,open the power switch, into the main menu. Antenna Setup Find Satellite Satellite Setup Transponder Setup System Setup...

  • Page 9: Antenna.setup

    Digital Satellite Finder 3.1 Antenna Setup Sat Name:.press.◄►.key.to.select.satellite LNB Type:press.◄►.key.to.select.LNB.Type Low Freq: press.◄►.key.to.select.Low.Freq.or.press.OK. key;.then.use.the.▲▼key.to.input.the.value Hi Freq: press.◄►.key.to.select.HiFreq.or.press.OK.key;. then.use.the.▲▼key.to.input.the.value 22K: press.◄►.key.to.switch.the.22K.tone;.if.you.select. universal.type.the.22K.setting.is.auto DiSEqC1.0 1.1:press.◄►.key.to.switch.LNB.port LNB Power: press.◄►.key.to.switch.LNB.power.on./off. When.all.of.settings.are.ok;.press.RETURN.key,.then.press. OK.key.for.save.the.edit. 3.2 Find Satellite In.the.first.line,.we.can.press.left.or.right.key.to.switch.the. satellite.

  • Page 10: Satellite.setup

    Digital Satellite Finder In.the.second.line,.we.can.press.left.or.right.key.to.switch. TP;.then.press.ok.key,.we.can.use.up.or.down.key.to.edit. TP.frequency. In.the.third.line,.we.can.press.ok.key,.then.edit.Symbol.rate. In.the.fourth.line,.we.can.press.left.or.right.key.to.select. h.or.v.polar. When.all.of.settings.are.ok,.we.can.check.the.LNB.signal. 3.3 Satellite Setup 1. Add Satellite 2. Edit Satellite 3. Delete Satellite Add Satellite: the.setting,.refer.to.Antenna.Setup. Edit Satellite: press.◄►.key.to.page.up./down;.then.press. ▲▼.key.to.select.the.satellite;.press.ok.key.to.edit.satellite.

  • Page 11: Transponder.setup

    Digital Satellite Finder setting,.refer.to.Antenna.Setup. Delete.Satellite:.refer.to.Edit.Satellite.then.press.ok.key.to. delete.satellite. 3.4 Transponder Setup 1. Add Transponder 2. Edit Transponder 3. Delete Transponder lease.refer.to.Satellite.Setup 3.5 Calculate Angle Press▲▼ key to move the cursor, then press OK key to select the option. Press ▲▼ to input value press ◄► to set east/west or north/south.

  • Page 12: System.setup

    Digital Satellite Finder 3.6 System Setup The first line is the SW Ver The second line is the Hardware serial number. Set language: switch the system language. Key press Beep: switch the key Beep. Signal Lock Beep: switch beep alarm. Flashlight: switch flashlight .

  • Page 13: Technical Specification

    Digital Satellite Finder 4. Technical Specification TRANSMISSION.STANDARDS DVB-.S/S2 SATELLITE.INPUT/DEMODULATION Connector.Type F.Type Input.Frequency 950.to.2150.MHz Signal.Input.Level -.65.to.-25.dBm Band.Switch.Control 22KHz LNB.Supply 13V/18V,.IMax.300mA Demodulation.Type QPSK\8PSK Symbol.Rate 2<Rs<45M.band(SCPC/MCPC) LCD.FEATURES LCD.Type FSTN.Positive.transflective Number.of.Dots 128.x64 Active.area.(WxH) 59.6x43.mm DATA.SERVICE.PORT Connector Data.protocol USB.to.RS-232 POWER..SUPPLY Li-Ion.Battery 7.4V/800mAh Adapter OUTPUT.:DC12V/1A, INTUPT.:100-240VAC.50/60Hz Power.consumption Max..5W PHYSICAL.CHARACERSTICS...
  • Page 14 USER‘S MANUAL...
