- Page 1 160F 168F 168F-2 168F-D 168F-2D...
- Page 2 PREFACE Thank you for choosing a general gasoline engine by our company. Based on the latest engine technology at home and abroad, our Co. has individually developed general gasoline engines with 4-stroke single cylinder, OHV and forced-air cooling. The engine is characterized by advanced design, compact structure, reliable performance, convenient service low fuel consumption and easy speed adjustment.
- Page 3 tual status. The copyright of this manual belongs to our Co., any group or individual is forbidden to reprint or copy any it. The manual is subject to change without notice. Please pay special attention to statements preceded by the following words: △...
-
Page 4: Table Of Contents
CONTENTS Safety Precautions ........................5 Parts Description ..........................7 Battery connection .......................... 8 Control Connection of Remote Distance (option) ................ 10 Pre-Operating Inspection ......................11 Ⅰ.Engine oil ..........................11 Ⅱ.Oil in the reduction gear box ....................12 Ⅲ.Air cleaner ..........................13 Ⅳ.Fuel and fuel tank ........................ - Page 5 Maintenance ..........................26 ⅠMaintenance schedule ....................... 26 Ⅱ.Method ............................. 28 Transport, Storage and Removal from Storage ................37 ⅠTransport ........................... 37 Ⅱ.Storage ............................. 37 Ⅳ.Removal from storage......................39 Troubleshooting ..........................40 Ⅰ.Starting engine difficultly ......................40 Ⅱ.Low gasoline engine power output ..................43 Ⅲ.Gasoline engine connot run smoothly ..................
-
Page 6: Safety Precautions
SAFETY PERCAUTIONS △ ! WARNING ● Before operating the engine, be sure to read and familiar with the manual carefully, otherwise injury to personnel or damage to equipment may occur. Please pay special attention to the following: 1. Running the engine in a well-ventilated place, keep it at least one meter away from building walls or other equipments, keep away from inflammables such as gasoline, matches and so on to avoid possibility of fire. - Page 7 9. This machine should not be used underground or in areas where explosive conditions may be pre- sent. 10. It’s recommended that the operator wears the protection equipment during operation.
-
Page 8: Parts Description
PARTS DESCRIPTION The main part of engine are located as follow (Fig.1) -
Page 9: Battery Connection
BATTERY CONNECTION (electric-start type) In the case that the specifications of the battery are 12V and more than 18A.h, connect its posi- tive lead to the electromagnetic coil while connect its negative lead to engine mount strew, base screw any place capable of grounding with the engine well. Make sure the battery leads are connected tightly and no corrosion is found. - Page 10 ● Do not add distilled water over electrolyte upper lev- el mark, or electrolyte will spill out to corrupt the engine parts. If so, be sure to wash them away with water. ● Make sure not to connect the battery leads in reverse order, or short-circuit or breaker’s cutting may re- sult.
-
Page 11: Control Connection Of Remote Distance (Option)
CONTROL CONNECTION OF REMOTE DISTANCE (OPTION) The holes in levers of both the choke and throttle valve are used for mounting optioned steel wires. Fig.2, 3 ＆ 4 shown illustrate how to mount a solid steel wire and a meshed steel wire. If choosing a meshed steel wire, a return spring is added. -
Page 12: Pre-Operating Inspection
PRE-OPERATE INSPECTION Ⅰ.ENGINE OIL CAUTION ● Engine oil is a key factor in deciding the engine’s performance. Do not apply engine oil with additives or 2-stroke gasoline oil, as they haven’t enough lubrication, which may shorten the engine’s service life. ●... -
Page 13: Ⅱ.oil In The Reduction Gear Box
CAUTION ● Run with insufficient engine oil may damage the engine severely. Ⅱ. OIL IN THE REDUCTION GEAR BOX (only for the model equipped with it) 1/2 Reduction gear box with an auto-centrifugal clutch. Brand of the oil is the same as that of engine oil. Oil capacity: 0.50 liters Check the oil level in the following order (Fig. -
Page 14: Ⅲ.air Cleaner
Ⅲ. AIR CLENANER 1. Double-core type (Fig. 8) Dismantle the air cleaner housing and check its filter element, make sure it is clean and intact, otherwise clean or replace it. 2. Dust – collecting type (Fig. 9) a) Dismantle the dust – collecting hood and check the core of the air cleaner, make s- ure it is clean and intact, otherwise clean or replace it. - Page 15 3. Semi –dry type (Fig. 10) a) Remove the air cleaner housing and check the filter element for dirt and impurity. Clean or replacement should be done if necessary. b) Check the air cleaner for dirt, and remove it if any. 4.
-
Page 16: Ⅳ.fuel And Fuel Tank
CAUTION ● Never run the engine without an air cleaner, or sever wear of the engine may occur. Ⅳ. FUEL AND FUEL TANK 1. Fuel The engine must apply unleaded gasoline with an octane number over 86. Using unleaded gaso- line will decrease the possibility of producing carbon deposit and prolong the engine’s service life. - Page 17 3. Fuel Tank Fuel tank capacity: 2.5liters for 160F, and3.6liters for 168F ＆ 168F – 2. 4. Check a) Remove the fuel filler cap and check fuel level. b) If the fuel level is too low, refuel the tank. Remember adding fuel not over the fuel filter...
- Page 18 △ ! WARNING ● Gasoline is extremely flammable and is explosive under certain conditions. Refueling in a well – ventilator area with the engine stopped. Do mot smoke and allow flames or sparks in the area where gasoline is stored or where the fuel tank is refueled. ●...
-
Page 19: Starting Of The Engine
STARTING OF THE ENGINE 1. Push the fuel cock to “ON”. (Fig. 13) 2. Push the choke lever to “CLOSE”. (Fig. 14) NOTE If the engine is hot, closing the choke is unnecessary. - Page 20 3. Move left the throttle lever a little (Fig. 15) 4. Start the engine (Fig. 16). a) Push the engine switch to “ON”. b) Pull slightly the starting rope handle up until feeling anti-action, and then make a rapid pull. Fig.
- Page 21 CAUTION Releasing the handle suddenly may make it hitting the engine. Release the handle slowly conforming with its recoiling force. c) Electric starter Push the engine switch to “START” and remain there the engine starts. Once engine starts, reset the engine switch to “ON”. CAUTION Use the engine switch not more than 5 minutes each time to avoid dam- age of the engine.
-
Page 22: Operation
OPERATION 1. Preheat the engine and push back the choke lever to “OPEN”(Fig. 17). 2. Set the throttle lever in proper position to ensure the engine runs at required velocity. (Fig.18) - Page 23 Engine Oil Alarm The engine oil alarm is designed to alarm the user the fact that the engine oil in the crankcase in insufficient. Run with insufficient engine oil may damage the engine. Once oil level in the crankcase is too low, the engine oil alarm will stall the engine automatically to make it free of damage while the engine switch is still at “ON”.
-
Page 24: Stop
STOP In an emergency, push the engine switch to “OFF” to stall the engine. Stop it in normal in the fol- lowing sequence: 1. Push right the throttle valve lever to the bottom (Fig. 19). 2. Push the engine switch to “OFF” (Fig. 20). 3. -
Page 25: Exhaust Control System
EXHAUST CONTROL SYSTEM With the engine running, carbon monoxide, oxide of nitrogen and hydrocarbon will produce, and in certain conditions, oxide of nitrogen and hydrocarbon will react chemically each other to make smoke while carbon monoxide is toxic, so exhaust control of them is very important. The company decreases the exhaust emissions by introducing poor-fuel carburetors and other devices into the engine to solve the problem. -
Page 26: Ⅲ.modifying
Ⅲ. MODIFYING Modifying the exhaust control system may make actual exhaust emissions exceeding statutory limit values. Illegal modification is as follows: 1. Dismantle or modify any part of air inlet or outlet system. 2. Modify or take off speed-adjusting connection device or speed adjustment device to result in the engine’s running or outside the set parameters. -
Page 27: Maintenance
MAINTENANCE Ⅰ. MAINTENANCE SCHEDULE To keep the engine in a sound condition, the user should maintain it according to the table below: Initial 1 month Initial 3 month Every 6 month Every 1 years Frequency Items Each time or 20 Hrs or 50 Hrs or 100 Hrs or 300 Hrs... - Page 28 CAUTION Use only parts manufactured by the company or equivalents in quality; otherwise damage to engine may occur. NOTES : Only for inside-ventilating double-core carburetors. : Only for paper core air cleaners. ① More often than that in the schedule if in dusty circumstances. ②...
-
Page 29: Ⅱ.method
△ ! WARNING Stall the engine before service. If service is required with the engine running, besure to keep good ventilation in the area. The exhaust emissions from the engine contain toxic carbon mon- oxide, inbreathing of it may do harm to personnel and even result in death of personnert. Ⅱ. - Page 30 NOTE Do not dump oil containers or discarded engine oil into rubbish boxes or onto the ground. For the sake of environmental protection, we suggest you take in discarded engine oil with a closed container and bring to local recycling station. 2.
- Page 31 Unscrew the wing nut, dismantle the air cleaner housing. Check the two cores for damage. If any, re- place with new one. a) Foam filter element: clean with home detergents and warm water (or non-flammable or high flash – point cleaning solvents) and dry up, then soak in clean engine oil until saturated.
- Page 32 b) Foan filter element: clean with home detergents and warm water (or non – flammable or high flash – pointcleansing solvents ) and dry up, then soak in clean engine oil until saturated. Squeeze out excess oil, otherwise, the engine will discharge smoke in starting stage. c) Paper filter element: knock the core againt a soild plane to get rid of accumulated dust or bl- ow out dust from inside to outside with high –...
- Page 33 Oil bath type (Fig. 26) a) Remove the wing nut and air cleaner housing, and take out the filter element. Check if both the cores are damaged. If any, replace it with new one. b) Clean the bores with home detergents (or high flash-point cleansing solvents) and warm water, and dry them up.
- Page 34 3. Washing of Deposit Cup (Fig. 27) Set the fuel switch at “OFF”, remove the deposit cup and O-ring. Wash them in non-flammable or high flash-point cleansing solvents, and then dry them up, at last, carry out reinstallation. Set the fuel switch to “ON” and check for leaks.
- Page 35 △ ! WARNING Be careful not to touch the muffler during or just after the engine. b) Clean the spark plug with a steel brush. If the insu- lator is damaged, replace the spark plug instead. c) Measure the spark plug clearance with a feeler. The clearance should be 0.7～0.8mm (Fig.
- Page 36 5. Spark Eliminator (Option) The spark eliminator should be serviced at least once every 100 hour’s operation so as to keep it in a sound condition. △ ! WARNING The muffler is very hot during running the engine and even a long time after stopping. Never touch it, or you may get burns.
- Page 37 CAUTION Be careful not to damage the mesh of the spark eliminator. Never use a damaged spark eliminator. 6. Adjustment of Carburetor Idling a) Start and preheat the engine until arriving at its normal working temperature (Fig.31). b) Obtain standard idling by adjusting the throttle fixing screw under the engine runs at a low speed.
-
Page 38: Transport, Storage And Removal From Storage
TRANSPORT, STORAGE AND REMOVAL FROM STORAGE Ⅰ. TRANSPORT Transport with the fuel switch turned off. Transport or store the engine it is cool so as to avoid getting burns or fire. CARTION Do not incline the engine so as to avoid spilling fuel. Spilled fuel or fuel vapor may ignite to cause fire. - Page 39 2. Disconnect the spark plug. Fill a spoon of fresh engine oil from the spark plug mount hole into the cylinder. Rotate the engine to distribute engine oil evenly, followed by fitting the spark plug to original position. 3. Pull the starting rope slowly until feel a slight anti-action, and then keep pulling so as to align the arrow of the starting sleeve with the hole of the starter.
-
Page 40: Ⅳ.removal From Storage
Ⅲ. REMOVAL FROM STORAGE Before reusing, service the engine in accordance with the instructions of the table. Storage time Service item Within one month One～two months Drain out original fuel of the fuel tank and refuel Drain out original fuel of the fuel tank and refuel; Two months～one year Drain out fuel in the carburetor○... -
Page 41: Troubleshooting
△ ! WARNING Fuel is extremely flammable and explosive under certain conditions. Keep cigarette, open flames and sparks away from operating site. TROUBLESHOOTING Ⅰ. STARTING ENGINE DIFFICULTLY TROUBLE CAUSE REMEDY 1. Something wrong with There is no enough fuel in fuel tank or Fill fuel, open fuel cock the fuel system fuel cock is closed... - Page 42 TROUBLE CAUSE REMEDY 1. something wrong with the fuel Fuel is filthy or deteriorated Replace system There is filthy or deteriorated Replace Normal cylinder compression Too much fuel in engine cyl- Drain extra fuel, dry up spark Normal spared inder plug electrodes ...
- Page 43 TROUBLE CAUSE REMEDY 1. Poor cylinder compression Piston ring is so worn to over Replace a set of piston rings Normal fuel supply system its wear limit Normal ignition system Piston ring is sticking Clear up carbon fouling Piston ring is broken Replace Spark plug is not installed...
-
Page 44: Ⅱ.low Gasoline Engine Power Output
fuel. To prevent fire, keep sparks for away from the spark plug mount hole. Once you find any of above problems, contact the authorization entitle to the dealer of the privi- lege helps for you. Ⅱ. LOW GASOLINE ENGINE POWER OUTPUT TROUBLE CAUSE REMEDY... -
Page 45: Ⅲ.gasoline Engine Connot Run Smoothly
TROUBLE CAUSE REMEDY Intake pipe is leaking Replace or replace it Poor compres- Piston or cylinder or piston ring is Replace it with a new one sion worn. Air leakage from the surface Replace cylinder gasket by which cylinder block contacting with cylinder head. -
Page 46: Ⅳ.stop Suddenly When Running
TROUBLE CAUSE REMEDY Engine is too hot Shoot trouble Abnormal combus- Too much carbon fouling in combustion chamber Clear away tion Improper gasoline brand or low gasoline quality Replace with qualified gasoline There is water in floater room Clean Improper spark plug electrodes Adjust Engine cannot start clearance... - Page 47 TROUBLE CAUSE REMEDY Ignition system Spark plug is struck through, Replace spark plug or short-circuited by carbon deposit Side electrode of spark plug Replace spark plug and remove is dropped out the dropped object When running Hi-voltage wire is dripped Connect it Engine oil in the crankcase is Add engine oil until it arrives...
-
Page 48: Ⅴ.gasoline Engine Is Excessively Hot
Ⅴ. GASOLINE ENGINE IS EXCESSIVEL HOT TROUBLE CAUSE REMEDY Improper ignition time Adjust ignition advance angle proper- Gasoline engine is excessively Insufficient engine oil supply Refill sufficient engine oil Exhaust pipe is clogged Dredge exhaust pipe Flow guard is leaking Repair leakages Dirt or something like the fill up Clear away dirt or something like this... -
Page 49: Ⅵ.there Is Abnormal Noise When Engine Running
NOTE: The gasoline engine should run under certain temperature. Generally, permitting temperature at the flow guard outlet is between 80～100℃, while the temperature of the crankcase is about 60℃ under the magneto. If temperatures surpass the limits, it is an indication that gasoline engine is exces- sive hot. - Page 50 TROUBLE CAUSE REMEDY Improper valve clearance Readjust valve clearance properly The other Fly wheel is not connected to crankshaft Connect tightly tightly...
-
Page 51: Specifications
SPECIFICATIONS Ⅰ. MAIN SPECIFICATIONS 1. Design Data Model 160F 168F/168FD 168F-2/168F-2D Items 305×365×335 313×376×335 L × W × H (mm) 317×341×318 〈305×385×334〉 〈313×396×335〉 Dry weight (kg) 14〈16〉 16〈17.9〉 Engine type 4-stroke, OHV, single cylinder tilt 25° Displacement (cm Bore × stroke (mm) 60×42... -
Page 52: Ⅱ.timing Of Distribution
160F 168F/168FD 168F-2/168F-2D Items Non – transistorized ignition (TCI) Ignition system Spark plug type F6TC Out direction of power shaft Counterclockwise 2. Date relating to Adjustment Item Date Spark plug clearance 0.7～0.8mm Carburetor idling 1700±150rpm Valve clearance (cold engine) Intake: 0.15±0.02mm;... -
Page 53: Ⅲ.torque Of Important Bolts
Exhaust valve opening: BBDC30°; Exhaust valve closing: ATDC10° Ⅲ. TIGHTENING TORQUE OF IMPORTANT BOLTS Item Torque Value (N · m) Cylinder head bolt Flywheel bolt 70～80 Crankcase cover bolt Tie – rod bolt...
