  • Page 1 173F-R(H) 177F-R(H) 182F-R(H) Ⅰ...
  • Page 2 PREFACE Thank you for choosing a general gasoline engine by the company. The manual gives information with respect to operation and maintenance of the general gasoline engine, and be sure to read it carefully first before operation. All the materials and diagrams of this manual are in accordance with the newest products at the publishing time.

  • Page 3: Table Of Contents

    CONTENTS Safety precautions ……………………………………………………………………………………………（1） Parts description ……………………………………………………………………………………………… （2） Battery connection (only for electric-start type) …………………………………………………………… （4） Control connection of remote distance (option) ……………………………………………………………… （5） Pre-operate inspection ……………………………………………………………………………………… （7） Starting the engine ………………………………………………………………………………………… （13） Running the engine …………………………………………………………………………………………（15） Stop…………………………………………………………………………………………………………… （17） Exhaust control system …………………………………………………………………………………… （19） Maintenance …………………………………………………………………………………………………...

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS WARNING: Before operating the engine, be sure to read and familiar with the manual carefully, otherwise personal injury or equipment damage may produce. Please pay special attention to the following: 1. Running the engine in a well-ventilated place, keep it at least one meter away from building walls or other equipments, keep away from inflammables such as gasoline, matches and so on to avoid possibility of fire.

  • Page 5: Parts Description

    PARTS DESCRIPTION...

  • Page 7: Battery Connection (Only For Electric-Start Type)

    BATTERY CONNECTION (electric-start type) In the case that the specifications of the batte4ry are 12V and more than 18A.h, connect its positive lead to the electromagnetic coil while connect its negative lead to engine mount strew, base screw or any place capable of grounding with the engine well.

  • Page 8: Control Connection Of Remote Distance (Option)

    ● Make sure not to connect the battery leads in reverse order, or short-circuit or breaker’s cutting may result. CONTROL CONNECTION OF REMOTE DISTANCE (OPTION) The holes in levers of both the choke and throttle are used for mounting optioned steel wires. The diagrams shown illustrate how to mount a solid steel wire and a meshed steel wire.
  • Page 9 Accessory options Remote-controlled throttle...

  • Page 10: Pre-Operate Inspection

    PRE-OPERATE INSPECTION ENGINE OIL CAUTION: ● Engine oil is a key factor in deciding the engine’ s Performace. Do not apply engine oil with additives or 2-stroke gasoline engine oil, as they haven’t en- ough lubrication, which may shorten the engines service life.
  • Page 11 4. If the oil level is too low, add the recommended engine oil up to the oil filler neck. 5. Reinstall the dipstick. CAUTION: Run with insufficient engine oil may damage the engine Severely. OIL IN THE REDUCTION GEAR BOX 1.173F-L/177F-L（1/2 Reduction gear）...
  • Page 12 AIR CLEANER Ⅰ. Double-core type Dismantle the air cleaner housing and check its filter element, make sure it clean and intact, otherwise clean or replace it. Ⅱ. Single-core type Dismantle the air cleaner housing and check its filter element, Make sure it is clean and intact, otherwise clean or replace.
  • Page 13 Ⅲ. Dust-collecting type 1. Dismantle the dust-collecting hood and check the filter element of the air cleaner; make sure it is clean and intact, otherwise clean or replace. 2. Check whether there is any dust or dirt inside the dust- collecting hood, if any, clear away.
  • Page 14 FUEL AND FUEL TANK Fuel The engine must apply unleaded gasoline with an octane number over 86. Using unleaded gasoline will decrease the possibility of producing carbon deposit and will prolong the engine’s service life. Never apply used or polluted gasoline or a mixture of gasoline with engine oil. Make sure the fuel is free of dirt and water. Gasoline Containing Alcohol If you decide to use a gasoline containing alcohol (fuel blend), be sure its octane rating is at least as high as high as that recommended by the company.
  • Page 15 Fuel Tank Fuel tank capacity 6.0 liters for 173F-L, 17F-L /173F-H, 177F-H. Check 1. Remove the fuel filler cap and check fuel level. 2. If the level is too low, refuel the tank. Remember adding fuel not over the fuel filler shoulder. WARNING: ●...

  • Page 16: Starting The Engine

    STARTING THE ENGINE 1. Push the fuel cock to “ ON ”. 2. Push the choke lever to “ CLOSE ”. NOTE: if the engine is hot, closing the choke is unnecessary.
  • Page 17 3. Move left the throttle lever a little. 4. Start the engine as follows: a) Hand-operated kick-starter Push the engine switch to “ ON ”. Pull slightly the starting rope handle up until feeling anti-action, and then make a rapid pull. CAUTION: Releasing the handle suddenly may make it hitting the engine.

  • Page 18: Running The Engine

    engine. Try once more 10 minutes later after last attempt failures. RUNNING THE ENGINE 1. Preheat the engine and push back the choke lever to “ OPEN ”. 2. Set the throttle lever in proper position to ensure the engine runs at required velocity.
  • Page 19 ENGINE OIL ALARM The engine oil alarm is designed to function when the engine oil in the crankcase is insufficient. Lack of engine oil may damage the engine. Once oil level in the crankcase is too low, the engine oil alarm will stall the engine automatically to make it free of damage while the engine switch is still at “...

  • Page 20: Stop

    OPERATING ON HIGHLANDS On highlands, the standard mixture ratio is relatively too big so the engine performance may be impaired while the fuel consumption may increase, besides, too big mixture ratio will pollute the spark plug to result in starting the engine difficultly.
  • Page 21 2. Push the engine switch to “ OFF ”. 3. Set the fuel cock to “ OFF ”. CAUTION: Sudden stopping at high speed under heavy load is forbidden, otherwise damage will result.

  • Page 22: Exhaust Control System

    EXHAUST CONTROL SYSTEM With the engine running, carbon monoxide, oxide of nitrogen and hydrocarbon will produce, and in certain conditions, oxide of nitrogen and hydrocarbon will react chemically each other to make smoke while carbon monoxide is toxic, so exhaust control of them is very important. The company decreases the exhaust emissions by introducing poor-fuel carburetors and other devices into the engine to solve the problem.
  • Page 23 3. Modifying Modifying the exhaust control system may make actual exhaust emissions exceeding statutory limit values. Illegal modification as such: a) Dismantle or modify any part of air intake or exhaust system. b) Modify or take off speed – adjusting connection device or speed adjustment device to result in the engines running beyond the set parameters.

  • Page 24: Maintenance

    MAINTENANCE MAINTENANCE SCHEDULE Frequency Each First month Each season Every 6 month Each year Item time or 20 hrs or 50 hrs or 100 hrs or 300 hrs √ Oil level check Engine oil √ √ Replace √ Oil level check Reduction gear oil √...
  • Page 25 CAUTION Use only parts from the company or equivalents in quality; otherwise engine damage may result. NOTE: : only for inside-ventilating double-core carburetors. : only for paper core air cleaners. Every two years or 600 hour’s later for dust collecting air cleaners. ①...
  • Page 26 Engine oil capacity in the 1/2reduction gearbox is 0.3 liters, engine oil capacity in the crankcase is 1.1 liters 1/2 Reduction 1/6 Reduction NOTE: Do not dump oil containers or discarded engine oil into rubbish boxes or onto the ground. For the sake of environmental protection, we suggest you take in discarded engine oil with a closed container and bring to local recycling station.
  • Page 27 CAUTION: Never run the engine without an air cleaner, or air with dirt and dust may enter the engine so speed the engine’s wear. Unscrew the wing nut, dismantle the air cleaner housing. Check if the two cores are damaged, if so, replace with new one. a) Foam filter element: clean with home detergents and warm water (or non-flammable or high flash-point cleansing solvents) and dry up, then soak in clean engine oil until saturated.
  • Page 28 a) Foam filter element: clean with home detergents and warm water (or non-flammable or high flash-point cleansing solvents ) and dry up, then soak in clean engine oil until saturated. Squeeze out excess oil, otherwise, the engine will discharge smoke in starting stage. b) Paper filter element: knock the core against a solid plane to got rid of accumulated dust or blow out dust from inside to outside with high-pressure air flow (not more than 30psi).
  • Page 29 Oil bath type 1. Remove the nut and air cleaner housing, and take out the filter element. 2. Clean with home detergents (or high flash-point cleansing solvents) and warm water, and dry up. 3. Soak in clean engine oil until saturated. Squeeze excess oil, or the engine will discharge smoke in starting stage.
  • Page 30 WARNING: ● Gasoline is extremely flammable and explosive in certain condition. Keep cigarette, sparks and open flames away. ● After reinstalling the deposit cup, make sure the area around spark plug Spark plug type:BPR6ES (NGK) or NHSP LD F7RTC Proper spark plug clearance ensures the engine’s normal running under no deposit around the spark plug.
  • Page 31 1. Remove the spark plug cap. 2. Clear away dirt around the spark plug base. 3. Dismantle the spark plug with a spark plug wrench. 4. Clean with a steel brush. If the insulator is damaged, replace the spark plug instead. 5.
  • Page 32 SPARK ELIMINATOR (Option) The spark eliminator should be serviced at least once every 100 hour’s operation so as to keep it in a sound condition. WARNING: The muffler is very hot during running the engine and even a long time after stopping. Never touch it, or you may get burns.

  • Page 33: Transport, Storage And Removal From Storage

    CAUTION: ● Be careful not to damage the mesh of the spark eliminator. ● Never use a damaged spark eliminator. CARBURETOR IDLING ADJUSTMENT 1. Start and preheat the engine until arriving at the normal working temperature. 2. Obtain standard idling by adjusting the throttle fixing screw under the engine’s idling.
  • Page 34 1. Replace engine oil. 2. Disconnect the spark plug. Fill about a spoon of fresh engine oil from the spark plug mount hole onto the cylinder. Crank the engine up to distribute engine oil evenly. Reinstall the spark plug. 3. Pull the starting rope slowly until feeling a slight anti-action, and then keep pulling it so as to align the arrow of the starting sleeve with the hole of the starter.
  • Page 35 Removal from storage Before reusing, service the engine in accordance with the instruction of the table STORAGE TIME SERVICE ITEM Within one month One ~ two months Drain out original fuel of the fuel tank and refuel Drain out original fuel of the fuel tank and refuel; Two month ~one year Drain out fuel in the carburetor①;...

  • Page 36: Troubleshooting

    TROUBLESHOOTING Ⅰ. START ENGINE DIFFICULTLY 1. By using kick-starter TROUBLE CAUSE REMEDY There is no enough fuel in fuel Fill fuel, open fuel cock. tank of fuel cock is closed. Air vent in the fuel filler cap is Dredge air vent. 1.
  • Page 37 TROUBLE CAUSE REMEDY Fuel is too filthy or deteriorated. Replace. 1. Normal cylinder compression. There is water in fuel. Replace. 2. Normal spark plug spark. 3. Something wrong with the fuel Too much fuel in engine. Drain extra fuel, dry up spark plug system.
  • Page 38 TROUBLE CAUSE REMEDY High – pressure coil is damaged. 1. Normal cylinder compression. Replace 2. Normal fuel supply. 3. Normal high – pressure coil Ignition coil is damaged. Replace spark. Magneto loses magnetism. Replace 4. Normal spark plug. Piston ring is worn to or even Replace over its wear limit.
  • Page 39 TROUBLE CAUSE REMEDY Air leakage in valves. Check valve. Clearance and tightness, repair if necessary. WARNING: ● When testing the spark plug, never hold the high- voltage wire of the spark plug with wet hand. ● Make sure there is no spilled fuel outside the engine and that the spark plug isn’t dipped with fuel. ●...
  • Page 40 Ⅱ. LOW GASOLING ENGINE POWER OUTPUT TROUBLE CAUSE REMEDY Incorrect ignition Readjust ignition Ignition system time. advance angle Air in fuel line or fuel Exhaust air or dredge line clogged. fuel line Main oil flow hole is Readjust not adjusted properly. When turning throttle greater, speed increase...
  • Page 41 TROUBLE CAUSE REMEDY much fouling in muffler and Clear away exhaust pipe. Air cleaner is clogged Clean air cleaner filter element Intake pipe is leaking. Repair or replace Piston or cylinder or Replace the worn piston ring is worn. Air leakage from the surface which cylinder...
  • Page 42 Ⅲ. GASOLINE ENGINE GANNOT RUN SMOOTHLY TROUBLE CAUSE REMEDY Piston, cylinder or piston ring is worn Replace the worn excessively. Piston pin and piston pin hole are worn Replace piston or piston pin excessively. Engine is pinking Tie rod small head is worn excessively. Replace tie rod Roller bearing for crankshaft main shaft Replace roller bearing...
  • Page 43 TROUBLE CAUSE REMEDY Incorrect ignition time Readjust Something wrong with induced coil, and Check and replace damaged parts so on Ⅳ. STOP SUDDENLY WHEN RUNNING TROUBLE CAUSE REMEDY Fuel is used up Refill fuel Carburetor is clogged Check fuel line and dredge Fuel supply system Float is leaking...
  • Page 44 TROUBLE CAUSE REMEDY Side electrode spark plug is dropped Replace spark plug High-pressure wire is Weld on dropped out Ignition coil is struck through Replace ignition coil short-circuited Parking wire located engine Find out meeting and insulate body Cylinder pulled The other damage, valve...
  • Page 45 Ⅴ. GASOLINE ENGINE IS EXCEESIVELY HOT TROUBLE CAUSE REMEDY Improper ignition time Adjust ignition advance angle properly Insufficient fuel supply Refill engine oil Exhaust pipe is blocked up Dredge exhaust pipe Gasoline engine is Flow guard is leaking Repair damaged part excessively hot Dirt or something like this fill up Clear away dirt or something like this...
  • Page 46 TROUBLE CAUSE REMEDY Cylinder or piston or piston ring is worn, resulting in air flow between Replace the worn cylinder and crankcase Improper adjustment of engine speed Readjust engine speed to proper valve produces excessive rotational speed by speed regulator Crankshaft main bearing is burnt out Replace main bearing NOTE: the gasoline should run under cretin temperature.
  • Page 47 Ⅵ. THERE EXISTS ABNORMAL NOISE WHEN ENGINE RUNNING TROUBLE CAUSE REMEDY Piston, piston ring or cylinder is worn Replace the worn Tie rod or piston pin and piston pin Replace the worn hole is worn There is noise of beating Crankshaft main bearing is worn Replace Piston ring is broken...

  • Page 48: Specifications

    TROUBLE CAUSE REMEDY Improper valve clearance Readjust valve clearance properly The other Fly wheel is not connected with Connect tightly crankshaft tightly SPECIFICATIONS MAIN SPECIFICATION 173F-L 173F-R 173F-H 177F-L 177F-R 177F-H 430× 430×420 430×440 430×420 430×410× 430×410× L×W×H (mm) ×410 ×410...
  • Page 49 Max. theory power 4.73/1800 4.73/600 6.6/1800 6.6/600 【kW / r/min】 Using power recommended 4.3/1800 4.3/600 5.7/1800 5.7/600 【kW / r/min】 Max. torque (N·m/r/min) 25.1/1530 75/510 31/1500 93/500 ≤374 Fuel consume. (g/kWh) Cooling system Force air-cooled Ignition system Spark plug type BPR6ES(NGK).NHSP LD F7RTC Lubrication mode Splash...
  • Page 50 Dry weight (kg) 4-stroke, OHV, single cylinder tilt 25 ℃ Engine type Displacement (cm Bore × Stroke (mm) 82*64 88*64 Max. theory power 8.0/1800 8.0/600 9.5/1800 9.5/600 【kW / r/min】 Using power recommended 7.1/1800 7.1/600 8.2/1800 8.2/600 【kW / r/min】 42/1500 126/500 46/1500...
  • Page 51 Output direction of power Counterclockwise shaft 190F-L 190F-R 190F-H L×W×H (mm) 460×435×440 460×466×440 460×450×440 Dry weight (kg) 4-stroke, OHV, single cylinder tilt 25 ℃ Engine type Displacement (cm Bore × Stroke (mm) 90*66 Max. theory power 10.5/1800 10.5/600 【kW / r/min】 Using power recommended 8.5/1500...
  • Page 52 Cooling system Force air-cooled Ignition system Spark plug type BPR6ES(NGK).NHSP LD F7RTC Lubrication mode Splash Output direction of power Counterclockwise shaft DATE RELATING ADJUSTMENT Item Date Spark plug clearance 0.7~0.8mm ≤850rpm ≤400rpm Carburetor Intake: 0.15±0.02mm; Valve clearance (cold engine) Exhaust: 0.20±0.02mm;...

  • Page 53: Electric Diagram

    ELECTRIC DIAGRAM(for electric-start type)
  • Page 54 Note: The diagram for other types may be different with the exception of electric-start type.
