Page 1: Table Of Contents
2009 WRANGLER/WRANGLER UNLIMITED TABLE OF CONTENTS What’s New for 2009 The Market SUVPS Three-Minute Drill Delivering the Vehicle Features, Options & Package Groups Dimensions — Exterior Dimensions — Interior Technical Specifi cations All product information is current at time of production approval, October 2008. ©2008 Chrysler LLC. -
Page 2: What's New For 2009
2009 WRANGLER/WRANGLER UNLIMITED WHAT’S NEW FOR 2009 The phenomenally successful Jeep Wrangler continues to be the vehicle of choice for customers wanting more fun and adventure. For the 2009 model year, it receives several enhancements. A right-hand-drive four-door Wrangler Unlimited X model is now available. Trailer Sway Control is now included as part of the optional Trailer Tow Group. -
Page 3: The Market
Unlimited fulfi lls everyone’s dreams, regardless of age WRANGLER because Unlimited is built for adventure. 2009 Jeep Wrangler continues to be the vehicle of choice for customers wanting to have more fun and RUBICON AND UNLIMITED RUBICON adventure. Traditional Wrangler customers cover Once the pavement is left behind, Wrangler Rubicon a broad spectrum, from Gen Xers to Boomers. - Page 4 Wrangler is the only vehicle in its class to offer removable multipiece fl oor carpeting and fl oor drain plugs for easier cleaning • Jeep Wrangler (2-door) has the shortest turning diameter in its class* • Jeep Wrangler and Wrangler Unlimited have best-in-class ground clearance* •...
-
Page 5: Suvps Three-Minute Drill
® electronic remote locking rear differential folding rear seat (Unlimited) Removable carpeting and drain plugs for ease of cleaning STYLING Classic Jeep brand DNA with its seven-slot grille, ® VALUE round headlamps and trapezoidal wheel openings The best coverage in the industry — the LIFETIME ®... -
Page 6: Delivering The Vehicle
2009 WRANGLER/WRANGLER UNLIMITED DELIVERING THE VEHICLE Taking ownership of a new vehicle is a To support their purchase decision, remind them signifi cant event for your customer. The goal of of all the features that make their vehicle unique. Delivery is to make certain the customer is By reviewing these features and their benefi... -
Page 7: Features, Options & Package Groups
Seat Belts Axle — Next Generation Dana 44 heavy-duty solid rear — Front-passenger seat belt alert ® Badging — “Jeep,” “Wrangler,” “Trail Rated ” — Three-point Unibelt for all seating positions; front Battery — 600-amp, maintenance-free height-adjustable with traveling inboard buckles and Brakes —... - Page 8 Interior Assist Handle — Front-passenger, instrument panel-mounted — Rearview day/night Axle — Next Generation Dana 44 heavy-duty rear Badging — “Jeep,” “Wrangler Unlimited” Power Accessory Outlet Battery — 600-amp, maintenance-free — 12-volt in instrument panel and cigar lighter Brakes — Four-wheel disc ABS with vented front and solid...
- Page 9 2009 WRANGLER/WRANGLER UNLIMITED FEATURES, OPTIONS & PACKAGE GROUPS Wrangler Wrangler Unlimited FEATURES, OPTIONS & PACKAGES Sahara Rubicon Sahara Rubicon Engine Transmission 3.8L OHV 12V V6 6-speed manual 3.8L OHV 12V V6 4-speed automatic Air Bags — Advanced multistage driver and front-passenger All Models Include —...
- Page 10 2009 WRANGLER/WRANGLER UNLIMITED FEATURES, OPTIONS & PACKAGE GROUPS Wrangler Wrangler Unlimited Sahara Rubicon Sahara Rubicon FEATURES, OPTIONS & PACKAGES (CONT.) Floor Mats — Carpet, front • • • — Carpet, front and rear (CLE) • • • • Four-Wheel-Drive System (4WD models) —...
- Page 11 2009 WRANGLER/WRANGLER UNLIMITED FEATURES, OPTIONS & PACKAGE GROUPS Wrangler Wrangler Unlimited Sahara Rubicon Sahara Rubicon FEATURES, OPTIONS & PACKAGES (CONT.) Seating — Two-tone vinyl • — Two-tone premium cloth (includes driver’s seat height adjuster) • • • • — Two-tone premium cloth with Stain Repel seat fabric (includes driver’s seat height adjuster and front seatback map pocket)
- Page 12 2009 WRANGLER/WRANGLER UNLIMITED FEATURES, OPTIONS & PACKAGE GROUPS Wrangler Wrangler Unlimited Sahara Rubicon Sahara Rubicon FEATURES, OPTIONS & PACKAGES (CONT.) Sway Bar Disconnect — Electronically controlled, front (4WD models) (requires Tru-Lok rear differential) (SHG) • • Tire Pressure Monitoring Warning Lamp All Models Include Tires —...
-
Page 13: Dimensions - Exterior
2009 WRANGLER/WRANGLER UNLIMITED DIMENSIONS — EXTERIOR Wrangler Sahara Rubicon P225/75R16 and Tire Sizes P255/75R17 P255/70R18 LT255/75R17 Wheelbase 95.4 Ground clearance 8.8/10.1 10.3 10.2 Overall length 162.9/163.8 163.8 163.8 Overall height 70.9/72.2 72.4 72.3 Overall width 82.8 Track — Front/Rear 61.9/61.9 Liftgate load fl... - Page 14 2009 WRANGLER/WRANGLER UNLIMITED Wrangler Unlimited Sahara Rubicon P225/75R16 and LT255/75R17 Tire Sizes P255/75R17 P255/70R18 Wheelbase 116.0 Ground clearance 8.7/10.0 10.2 10.1 Overall length 183.7/184.4 184.4 Overall height (hardtop) 70.8/72.1 72.4 72.3 Overall width 82.8 Track — Front/Rear 61.9/61.9 Liftgate load fl oor height 31.4/32.7 32.9 32.9...
-
Page 15: Dimensions - Interior
2009 WRANGLER/WRANGLER UNLIMITED DIMENSIONS — INTERIOR Wrangler Wrangler Unlimited Front row — Head room 41.3 — Leg room 41.0 — Shoulder room 55.8 — Hip room 55.6 — Seat adjustment (fore and aft) Second row — Head room 40.3 — Leg room 35.6 37.2 —... -
Page 16: Technical Specifi Cations
2009 WRANGLER/WRANGLER UNLIMITED TECHNICAL SPECIFICATIONS Wrangler Wrangler Unlimited Sahara Rubicon Sahara Rubicon GVWR (lb) 4,900 5,000 5,100 5,400 5,100 5,500 5,250 5,700 Fuel-tank capacity (gal) 18.6 22.5 Drivetrain Standard Engine 3.8L OHV 12-valve V6 — Horsepower (SAE net @ rpm) 202 @ 5,000 —... - Page 17 For each feature, remember to emphasize the benefi ts to the customer — the reasons why Jeep Wrangler is their best purchase choice. Some features may be optional or not available on some models. Consult the Features, Options & Package Groups charts to determine the availability of specifi...
- Page 18 2009 WRANGLER/WRANGLER UNLIMITED PRODUCT PRESENTATION FRONT (CONT.) WRANGLER FEATURES/FUNCTIONS CUSTOMER BENEFITS RUGGED DURABILITY • Durability-tested 150,000 customer-equivalent miles • Helps maintain rigidity on all types of terrain for driving confi dence and vehicle control • Advanced rectangular-shaped tubular-frame design is lightweight with exceptional strength •...
- Page 19 CLASSIC JEEP BRAND DNA ® • Design features seven-slot grille, round headlamps • Retains classic Jeep brand styling that embodies and trapezoidal wheel openings more than 67 years of 4x4 leadership * See the “Disclaimers” list. WRANGLER/WRANGLER UNLIMITED...
-
Page 20: Driver Side
2009 WRANGLER/WRANGLER UNLIMITED PRODUCT PRESENTATION DRIVER SIDE WRANGLER FEATURES/FUNCTIONS CUSTOMER BENEFITS ELECTRONIC STABILITY PROGRAM (ESP)* • Compares the driver’s intended course with the • Automatically helps/assists driver in maintaining vehicle’s actual course and then compensates control of vehicles during extreme steering for differences maneuvers •... - Page 21 2009 WRANGLER/WRANGLER UNLIMITED PRODUCT PRESENTATION DRIVER SIDE (CONT.) WRANGLER FEATURES/FUNCTIONS CUSTOMER BENEFITS BRAKE ASSIST • Overcomes the tendency of not applying the brakes • Helps vehicle stop sooner in emergency situations hard enough in an emergency braking situation by reacting faster than the driver is able to in by using the ESP* system to instantly apply the applying maximum brake pedal pressure maximum available brake pressure...
- Page 22 TRAIL RATED ® • Wrangler 4x4’s capabilities have been authenticated • Validates Wrangler’s capabilities to handle by Jeep engineers some of the steepest, toughest, and slipperiest ® off-road terrain • Trail Rated badging FENDER FLARES •...
- Page 23 2009 WRANGLER/WRANGLER UNLIMITED PRODUCT PRESENTATION DRIVER SIDE (CONT.) WRANGLER FEATURES/FUNCTIONS CUSTOMER BENEFITS SUNRIDER ® SOFT TOP • 50"x30" on Wrangler • Opens the sky to driver and front-seat passenger • 50"x60" on Wrangler Unlimited • Provides three top choices: sunroof open, soft top up, and soft top down •...
-
Page 24: Passenger Side
2009 WRANGLER/WRANGLER UNLIMITED PRODUCT PRESENTATION PASSENGER SIDE WRANGLER FEATURES/FUNCTIONS CUSTOMER BENEFITS TIRE PRESSURE MONITORING WARNING LAMP • Automatically checks the level of air pressure in • Monitors tire pressures in all road conditions all four tires and displays a warning lamp in the •... - Page 25 2009 WRANGLER/WRANGLER UNLIMITED PRODUCT PRESENTATION INTERIOR (CONT.) WRANGLER FEATURES/FUNCTIONS CUSTOMER BENEFITS REAR-SEAT CHILD SEAT ANCHOR SYSTEM (LATCH) • LATCH is a system for mounting a child seat • Helps ensure safe and proper installation of LATCH-compatible aftermarket child seats • Lower child seat anchors and upper tether anchors SENTRY KEY ®...
- Page 26 2009 WRANGLER/WRANGLER UNLIMITED PRODUCT PRESENTATION INTERIOR (CONT.) WRANGLER FEATURES/FUNCTIONS CUSTOMER BENEFITS AVAILABLE uconnect gps* • Replaces MyGIG ® Multimedia Infotainment System • Provides outstanding convenience and ease of use by combining navigation with touch-screen • Features turn-by-turn navigation and real-time operation traffi...
