Installation and Operation Data
Installation and
Op er a tion Man u al
Jandy
Slide
®
Backwash Valve
FOR YOUR SAFETY - This product must be installed and serviced by authorized personnel
qual i fi ed in pool/spa installation and maintenance. Improper installation and/or operation
will void the warranty.

Advertisement

Table of Contents
loading

Related Manuals for Jandy Slide Backwash Valve

Summary of Contents for Jandy Slide Backwash Valve

  • Page 1 Installation and Op er a tion Man u al Jandy Slide ® Backwash Valve FOR YOUR SAFETY - This product must be installed and serviced by authorized personnel qual i fi ed in pool/spa installation and maintenance. Improper installation and/or operation will void the warranty.

  • Page 3: Section 1. Svlv8 Installation

    DEL48 or DEL60 model filters (in which the top port is the filter outlet). If mounting a Jandy Slide Valve on Pentair or Sta-Rite Filters, use a combination of p/n SVLV2 (Slide Valve without unions) and p/n 8044 (Versa-Coupler Kit).

  • Page 4: Section 2. Svlv2 And Versa-Coupler Installation

    NOTE: For new installations other than Jandy DEL48 or DEL60, use the SVLV2 and the Versa Coupler Kit, p/n 8044 (See Figure 4). If using the Slide Valve with a Pentair fi lter, use Filter Inlet Pentair Pool Products™ Union Set #27002, and (PORT D) then proceed to section B.

  • Page 5: Section 3. Normal Operation

    NOTE Refer to Figure 5 for Steps 6 and 7. (DE Filters) Plumb the Slide Valve outlet labeled PORT A to the heater or pool return lines. (Sand Filters) Plumb the Slide Valve outlet PORT E labeled to the heater or pool return lines. (DE Filters) Plumb the Slide Valve outlet labeled PORT E to the waste line as needed.

  • Page 6: Section 4. Backwash Mode

    Page 6 Section 4. Backwash Mode Turn off the system pump(s). WARNING To prevent equipment damage and possible injury, the pump must be turned off and the pressure relief valve on top of the filter must be opened. Wait for all air to evacuate the system Release all pressure from the system at the main fi...
  • Page 7 Shaft Assembly Lid Union Nut Index Plate/Lid Lid O-ring Shaft O-ring, Top (Black) Shaft O-ring, Bottom (Purple) Figure 9. Remove Slide Valve Shaft Assembly Inspect the shaft and the o-rings for wear, cuts, cracks, and debris. If the o-rings show any sign of wear or damage, replace with Jandy O-ring and Roll Pin Replacement Kit (P/N R0442100).

  • Page 8: Section 6. Jandy Slide Valve Exploded View And Replacement Parts 2, 3 List

    Page 8 Section 6. Jandy Slide Valve Exploded View and Replacement Parts List Description Rebuild Kit (O-rings, Roll Pins and Index Plate/Lid) O-ring, Lid O-ring, Shaft, Top, Black O-ring, Shaft, Bottom, Purple O-ring, Union Tail Piece Roll Pin, Handle (1") Roll Pin, Shaft ( ") Index Plate/Lid...
