Covert Extreme
After you're familiar with the basic operations of the Camera, you are now
ready for advanced operations，and the options and parameters of the Camera are
explained in more detail.

4.1 Settings Menu

To view the camera settings menu, press MENU in the SETUP mode (Power
switch is at the SETUP position). The settings menu will be shown on the LCD on
the camera or the external TV monitor (only when the camera is connected to a TV).

4.1.1 Set Camera Mode

There are two modes: Camera or Video. There are two ways to set the camera
mode: 1. Via shortcut key; 2. Via setting menu.
1. Via shortcut key: You can set mode to "video" by pressing "▲" key and set
mode to "camera" by pressing "▼"key in TEST mode.
2. Setting menu: The following shows how to set camera mode to Video,
provided that the previous option is Camera:
a) Press MENU to display the setting menu.
Press "▲" or "▼" to select Mode.
b)
Press "►" to select Video.
c)
Press OK to save the current setting and the option will be un-highlighted.
d)
Press MENU to cancel setting and return to info display.

4.1.2 Format SD-Card

The system will delete all images or videos stored in the SD-card after formatting,
so make sure that you have made a backup of important data.
a) Press MENU to display the setting menu.
b) Press "▲" or "▼" to select Format.
c) Press OK to choose Enter to enter into submenu.
d) Press "►" to select Yes. Yes will be highlighted.
e) Press OK to start formatting the SD-card. During formatting, the display
screen will show a message "Formatting..." as below.
Press MENU to return to info display.

4.1.3 Set Photo Size

This parameter has two values: 5 mega pixels (5M Pixel or 5MP) and 3 mega
pixels (3M Pixel or 3MP). The default value is 5 mega pixels.
The following shows you how to set pixel size as "3M Pixel" provided that the
