Sony KDL-40XBR4 Service Manual page 148

NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
REF. NO. PART NO.
UB1
A-1257-224-A
(The UB1 Board contains critical adjustment data, therefore,
if service is required, complete board replacement is the
repair method.)
ACCESSORIES AND PACKING
1-832-937-11
!
* X-2186-601-1
X-2186-603-1
2-593-320-02
2-580-663-01
2-632-670-01
2-694-444-01
* 3-270-340-01
* 3-270-342-01
* 3-270-919-01
* 3-270-920-01
2-595-155-02
* 2-887-795-01
* 2-691-386-01
* 2-887-794-01
* 2-691-385-01
3-214-429-11
3-214-429-21
3-214-429-31
3-214-428-13
3-214-428-22
3-214-428-32
* 3-276-781-01
3-274-931-11
KDL-40XBR4/40XBR5/46XBR4/46XBR5
Downloaded from www.Manualslib.com
NOTE: Les composants identifi es per un trame et une
marque ! sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifi e.
DESCRIPTION VALUES
UB1 BOARD, COMPLETE
AC POWER-SUPPLY CORD SET
BAG ASSEMBLY, RUDDER LOCK
(Contains the 3 items below)
LOCK ASSEMBLY, RUDDER
SCREW, CION (M6X18)
SCREW, WOOD 3.8X20\
BAG, PROTECTION
(KDL-40XBR4/40XBR5 ONLY)
BAG, PROTECTION
(KDL-46XBR4/46XBR5 ONLY)
CARTON, INDIVIDUAL
(KDL-40XBR4 ONLY)
CARTON, INDIVIDUAL
(KDL-40XBR5 ONLY)
CARTON, INDIVIDUAL
(KDL-46XBR4 ONLY)
CARTON, INDIVIDUAL
(KDL-46XBR5 ONLY)
CLAMP
CUSHION, LOWER
(KDL-40XBR4/46XBR4 ONLY)
CUSHION, LOWER
(KDL-40XBR5/46XBR5 ONLY)
CUSHION, UPPER
(KDL-40XBR4/46XBR4 ONLY)
CUSHION, UPPER
(KDL-40XBR5/46XBR5 ONLY)
GUIDE, QUICK SET UP (ENGLISH VERSION)
GUIDE, QUICK SET UP (FRENCH VERSION)
GUIDE, QUICK SET UP (SPANISH VERSION)
MANUAL, INSTRUCTION (ENGLISH VERSION)
MANUAL, INSTRUCTION (FRENCH VERSION)
MANUAL, INSTRUCTION (SPANISH VERSION)
SHEET, PROTECTION
(KDL-40XBR5/46XBR5 ONLY)
SHEET, PROTECTION
(KDL-40XBR5/46XBR5 ONLY)
manuals search engine
REF. NO. PART NO. DESCRIPTION
* 3-270-341-01 TRAY
(KDL-40XBR4/40XBR5 ONLY)
* 2-691-384-01 TRAY
(KDL-46XBR4/46XBR5 ONLY)
* 2-696-914-01 TRAY, TOP
(KDL-40XBR4/40XBR5 ONLY)
* 2-696-915-01 TRAY, TOP
(KDL-46XBR4/46XBR5 ONLY)
COLORED BEZELS
The Driver, Instruction Manual, and Screw Assembly below
are necessary to replace a colored bezel.
2-687-996-01 DRIVER (Used to remove screws from Bezel)
2-687-069-02 INSTRUCTION MANUAL
X-2148-273-1 SCREW ASSEMBLY
For KDL-40XBR4/40XBR5 ONLY
CHAMPAGNE GOLD
X-2179-330-1 BEZEL ASSEMBLY
3-218-762-01 STAND COVER
METALLIC ROSE
X-2179-333-1 BEZEL ASSEMBLY
3-218-762-11 STAND COVER
SILVER
X-2186-663-1 BEZEL ASSEMBLY
2-673-578-02 STAND COVER
NEW BLACK
X-2186-516-1 BEZEL ASSEMBLY
2-673-578-81 STAND COVER
For KDL-46XBR4/46XBR5 ONLY
CHAMPAGNE GOLD
X-2179-331-1 BEZEL ASSEMBLY
3-218-762-01 STAND COVER
METALLIC ROSE
X-2179-334-1 BEZEL ASSEMBLY
3-218-762-11 STAND COVER
SILVER
X-2186-664-1 BEZEL ASSEMBLY
2-673-578-02 STAND COVER
NEW BLACK
X-2186-532-1 BEZEL ASSEMBLY
2-673-578-81 STAND COVER
KDL-40XBR4/40XBR5/46XBR4/46XBR5
UB1
VALUES
147
