SERVICE MANUAL
(SUPPLEMENT)
PLC-XP56
:
Note
Model PLC-XP56L does not provide projection lens.
Any information not contained in this manual will be found in the original model's service manual
SM5110500-00 for models PLC-XP55 and PLC-XP55L.
FILE WITH ORIGINAL SERVICE MANUAL (SM5110500)
PRODUCT CODE
1 122 275 00
(ME5A)
1 122 275 20
(ME5AL)
1 122 283 00
(PE5A)
1 122 283 20
(PE5AL)
1 122 283 02
(PE5C)
1 122 283 22
(PE5CL)
Multimedia Projector
- NOTE -
FILE NO.
Model No. PLC-XP56
PLC-XP56L
U.S.A., Canada,
Europe, Asia, Africa
Original Version
Chassis No. ME5-XP5600
ME5-XP56L00
NOTE: Match the Chassis No. on the unit's
back cover with the Chassis No. in the
Service Manual.
If the Original Version Service
Manual Chassis No. does not match
the
unit's,
additional
Literature is required.You must refer to
"Notices" to the Original Service
Manual prior to servicing the unit.
REFERENCE NO.
Service
SS5110711
-00
