- Page 1 USER MANUAL Please read the user manual clearly for avoiding any wrong opeartion, current manual is not the newest and not complete, please contact us if any query. ~ 1 ~...
-
Page 2: Table Of Contents
CATALOGUE MAIN FEATURE ..............................4 INSTALL & USE ..............................5 Camera Buttons ............................. 5 Remote Controller ............................6 Install Battery ..............................7 Install Mount ..............................8 Install Camera to Waterproof Case ........................ 9 Note: Press the Color button 2 seconds at the back of waterproof case, camera will Power on and start video Record directly, press once to pause and restart the record, press the button 2 seconds again, the camera will power OFF directly &... - Page 3 Record Mode setting ............................ 23 Video Resolution setting ..........................24 SPECIFICATION .............................. 25 ~ 3 ~...
-
Page 4: Main Feature
MAIN FEATURE 480 x 240 , 1.5” TFT LCD screen 5MP HD CMOS sensor 170° Super wide angle under 720P, 127° wide angle under 1080P Full HD 1080P video, H.264 code compression in MP4 video format, easy to play and edit ... -
Page 5: Install & Use
INSTALL & USE Camera Buttons 1，MIC input 8，Down/Zoom -/Remote pair 2，HDMI output 9，Power On/Capture 3，USB/RCA video output 10，REC/ Confirm 4，Power charge indicator 11， MIC 5，1.5”TFT LCD 12， Speaker 6，UP/Zoom + 13， REC indicator 7，Main Menu ~ 5 ~... -
Page 6: Remote Controller
Remote Controller Video record Power Take picture Single press the “ Power” button on camera to open the remote receiving mode. ( Blue indicator on camera will turn on). Press the “ Menu” button once to close the remote receiving mode(Blue indicator) for saving power if not use. 1. -
Page 7: Install Battery
Install Battery Install the battery correctly as the picture showed below: Open the battery cover Put the battery into the housing Close the battery door ~ 7 ~... -
Page 8: Install Mount
Install Mount Open the standard mount, and put the camera into it as picture showed below. ~ 8 ~... -
Page 9: Install Camera To Waterproof Case
Install Camera to Waterproof Case Open the door in front of waterproof case, and put camera into it. Close the front door Note: Press the Color button 2 seconds at the back of waterproof case, camera will Power on and start video Record directly, press once to pause and restart the record, press the button 2 seconds again, the camera will power OFF directly &... -
Page 10: Install Memory Card
Install Memory Card a ，Please install the TF card according to the picture showed below: b ，Camera does not have built in memory, support １GB~32GB TF card expand. c ，Usable memory could be checked in the system after inserted the TF card. There without the card icon on the screen if no TF found Screen will display the TF card... -
Page 11: Camera Usb Charge
Camera USB charge Connect camera with PC or other DC5V charger to charge, USB cable offered with this camera. The blue LED indicator at the bottom(open the door )will turn ON if camera connected with correct charging device. Blue LED indicator at the bottom will turn OFF after full charged. ~ 11 ~... -
Page 12: Charging Time And Using Time
Charging time and using time Charging Time Standby REC time 3.5 Hours under power on 3.5 Hours (approximately) 110 Minutes（1080P） 2 Hours under power off (approximately) (approximately) Battery icon 76% - 100% Power 36% - 75% Power 10% - 35% Power <... -
Page 13: Video Record And Taking Picture
Video record and Taking picture a . Press 【POWER】button to power on the camera, press 【REC】button to start record video, REC icon ( Red color ) will display on the screen. Press 【PREV/NEXT】to adjust the focus under 720P ( Zoom in/Zoom out). Press【REC】again to stop video record and video clip will be saved automatically. -
Page 14: Video Playback
The camera can’t take pictures if installed in the waterproof case, please use remote controller to do this. Video Playback Press 【MENU】button to enter the main menu, use 【PREV/NEXT】to select the video folder, here has a number at the corner to show the quantity of the video clips inside. -
Page 15: Picture Playback
Picture playback Press 【MENU】 button to enter the main menu, use 【PREV/NEXT】to select the picture folder, here has a number at the corner to show the quantity of pictures inside. Press 【REC】button to confirm and enter the folder, the video clips display in thumbnail 2 x 3 . -
Page 16: Delete Files
Delete files Long press 【REC】button under playback mode, the delete option will display on the screen as below. Press 【PREV/NEXT】button to change option. No：Will cancel operation and quit Yes：Will delete selected file ALL：Will delete all files in the folder Press 【REC】to process the operation NOTE: The files can not recovery after delete, please back up in advance. -
Page 17: Camera Connect To Tv
Camera connect to TV A，USB - RCA cable to connect camera with TV Connect the RCA side to TV ( YELLOW-VIDEO ; WHITE-AUDIO), connect the Micro-USB side to camera: B，Connect with TV by HDMI cable “ HDMI to Micro HDMI ” cable is necessary for this operation. Connect the standard HDMI to TV, and Micro-HDMI to camera. -
Page 18: Camera Connect To Pc
Camera connect to PC Connect camera with computer by USB cable, transfer the files and power charge. After connected with computer and power on the camera, the camera screen will display USB connect icon like below: Under power on state to read the memory card and charge the power. Under power off state to charge the power only. -
Page 19: System Menu
SYSTEM MENU Booting Picture Icon Instruction 1920x1080 Video size Record icon 28000M Available memory Capture icon 15：33：24 Available time of Continuous shot memory icon 2010/09/21 System date Memory card icon 04：27：48 System time Power indicate ~ 19 ~... -
Page 20: Main Menu
Main Menu Icon Instruction： Video folder: Number will display at the corner to show the quantity of video clips Picture folder: Number will display at the corner to show the quantity of video clips Video setting: recording and capture settings System setting ( Language, date &... -
Page 21: Fast Setting
Fast setting Long press 【POWER】button 2 seconds to power on the camera, press 【MENU】to enter the main menu, press 【REC】 to confirm and enter the system setting menu. Language setting Select language menu and press【REC】to enter, use【PREV/NEXT】 to choose suitable language, then press 【REC】again to confirm. ~ 21 ~... -
Page 22: Date & Time Setting
Date & Time setting Press 【PREV/NEXT】to select the option and press 【REC】 button to active the setting. Red color means active setting, press 【PREV/NEXT】to change the setting. Press 【REC】again to confirm and go to next option. After settings, press 【REC】 to save and quit automatically. ~ 22 ~... - Page 23 Record Mode setting Press 【MENU】to enter the system menu, press 【REC】 to confirm and enter the record setting. Select “ REC mode” and press【REC】to enter the setting. Press【PREV/NEXT】to select and press【REC】again to confirm and save the setting automatically. Normal REC： Press the【REC】button to start the video record, press 【REC】 again to stop record, time length of video clip is optional and could be set under “Loop setting”.
- Page 24 Motion Detect：The camera will start video record while movement detected face to the lens. Video Resolution setting Press【PREV/NEXT】 to select, and press【REC】to enter the setting. Select the suitable resolution RESOLUTION FRAME RATES RATIO 1920x1080 FULL HD 1080p 30fps 16：9 1440x1080 FULL HD 1080p 30fps 4：3...
- Page 25 SPECIFICATION ITEM PERFORMANCE REMARK 32MB TF CARD 1-64GB SDHC SUPPORT SIZE 1.5 INCH TFT LCD RESOLUTION 480x240 SIZE 1/2.5 INCH CMOS SENSOR PIXELS 2592H x 1944V MAIN VIDEO OUTPUT HDMI/USB SPEC BUILT IN OPTIONAL AUDIO OUTPUT HDMI/USB SPEAKER BUILT IN INTERFACE USB 2.0 BATTERY...
- Page 26 ITEM PERFORMANCE REMARK PICTURE FLIP 180° upright AUTO SCREEN OFF LOW POWER PROTECTION AUTO POWER OFF 5、10、20 MINS FULL HD1920 × 1080 30FPS FULL HD1440 × 1080 30FPS VIDEO OPTIONAL SIZE HD 1280 × 720 60FPS RECORD HD 1280 × 720 30FPS SPEC QVGA 848×480 60FPS 4000 ×...
- Page 27 Please login www.jeasun.net for more product information. ~ 27 ~...
