SwissPhone s.QUAD Voice User Manual

User Manual
s.QUAD Voice

1. Introduction

Congratulations
Swissphone receiver! When you
purchased the new s.QUAD, you
chose a top-range device. The
s.QUAD delights with its optimum
combination of user-friendly design,
high carrying comfort and top quali-
ty. It offers easy operation via four
buttons and a graphical display.
The s.QUAD can be custom configu-
red. For this reason, some of the
functions described in this brief operating manual may be mis-
sing on your device.
This brief operating manual provides important information that
will help you get the most out of your device. Always keep this
manual ready to hand.
We wish you success in using the s.QUAD.

2. Getting started

Insert power source
The s.QUAD works with either a dry cell battery or a rechargeable
battery. Insert the power source into the s.QUAD, making sure
that you observe correct polarity. The s.QUAD will turn on auto-
matically. A functional test is then performed. After the test,
please specify whether you have inserted a dry cell battery or a
rechargeable battery. The device is now ready for operation.
Further information on the power supply can be found in the
chapter 'Charging the battery/power supply'.
Turn on
To manually turn on the s.QUAD, you must press and hold one of
the four buttons until the start screen or start text appears on the
display. The home screen is visible after a few seconds and the
s.QUAD is ready for operation.

3. Button function and navigation

BACK navigation FORWARD
button navigation button
– Scroll backwards – Scroll forward in
in the menu the menu
– Change settings – Change settings
– Display the start – Display the sec-
screen or start text ondary menu
by holding the
button
ESC button
– Leave the current menu level
– Go to the home screen
by holding the button
on your new
OK confirmation
button
– Read messages
– Confirm and ac-
knowledge alert
– Confirm menu
selection
– Call up the last
message received
FORWARD
ESC BACK OK
Open user menu
The BACK and FORWARD navigation buttons allow you to switch
from the home screen to the user menu. Press the FORWARD
button to navigate to the next menu item, the BACK button to
navigate back to the previous item. To confirm a selection you
have made or a changed value, press the OK button. Each press
of a button activates the backlight. By pressing the 'OK' button
from the home screen, you can call up the last received message
from the memory.
Back to home screen
Press the ESC button to go to the next higher menu level. If you
hold down the ESC button for two seconds, you return from the
submenu to the home screen. If you do not press any of the but-
tons for a pre-configured time interval, the s.QUAD automatically
returns to the home screen.
Release key lock (if activated)
To release the key lock, press the two
navigation buttons BACK and FORWARD
simultaneously.
Start-up image/Start-up text
If you hold down the BACK navigation button in the home screen,
the start-up image or start-up text appears.
Secondary menu
If you hold down the FORWARD navigation button in the home
screen for two seconds, you reach the secondary menu (only if
configured in the menu). Functions that are seldom used can be
placed on a second menu level (secondary menu) in order to
declutter the main menu. When you leave the secondary menu,
the device automatically returns to the start screen.

4. Display

The home screen is divided into five sections:
1 line: Status line
st
2 line: Profile
nd
3 line: Time, alarm clock
rd
4 line: User line
th
5 line: Notification line (unread mes-
th
Status line
The following symbols may be displayed in the status line:
Alert type
Out of range display
Bluetooth
Key lock
Battery level
sages, charger masks and so on)
Monitor alert
Loud alert
Quiet alert
Ascending alert
Discrete alert
Silent alert
No reception of alert messages
Bluetooth turned on, but not
connected with a device
Bluetooth is connected with a
device
Key lock is activated
Display Battery full, ¾, ½, ¼
Flashing Charge the battery!
Profi
This l
Time
This
clock
Alar
User
A use
Notif
This l
there
the fo
Folde
5. P
Rece
When
sound
the v
stop t
mess
navig
'Fixte
includ
The d
You c
scroll
The m
Liste
To lis
the O
ment
playe
figura
Mess
The
appro
Unrea
mess
