LUXURY WATERPROOF TELEVISIONS MADE IN ENGLAND
IN-WALL RANGE: 19" / 27" / 32" / 42" / 46" / 55"
User manual and installation guide for Videotree's in-wall
range of waterproof televisions.
Please read this guide carefully before installing and
operating your Videotree television and retain for future
reference.
USER MANUAL &
INSTALLATION GUIDE
1
LIFESTYLE RANGE
IP66
Protection Rating
2 YEAR
Warranty
www.videotree.com
Tel: +44 (0)1932 267 797
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Videotree Lifestyle
Summary of Contents for Videotree Lifestyle
- Page 1 LUXURY WATERPROOF TELEVISIONS MADE IN ENGLAND IN-WALL RANGE: 19” / 27” / 32” / 42” / 46” / 55” IP66 Protection Rating User manual and installation guide for Videotree’s in-wall range of waterproof televisions. 2 YEAR Warranty Please read this guide carefully before installing and operating your Videotree television and retain for future reference.
-
Page 2: Table Of Contents
STOP IMMEDIATELY. Place the television in a safe location and contact What You Will Need..................Videotree or a professional AV installer or electrician before continuing. Safety Precautions.................... It is the responsibility of the installer to ensure that your waterproof television is correctly installed and sealed to retain water-tightness. -
Page 3: Contents
WHAT YOU WILL NEED INTRODUCTION Thank you for choosing Videotree. The following guide will assist you with To install and mount your in-wall television, you may require the following the operation and installation of your in-wall television. Please carefully additional tools and accessories: read this guide and follow the instructions provided before attempting to install and operate your in-wall television. -
Page 4: Safety Precautions
Risk of damage to the television. May result in fire or electric shock. Do NOT plug too many devices into a singular power supply socket. Do NOT install the television without a safety earth. Your Videotree Risk of fire due to overheating. - Page 5 Risk of damage to the unit or personal injury. - Foreign objects have been placed into the unit. If any of the above applies, please contact Videotree immediately. Do NOT use the mains plug sockets to turn the television on or off.
-
Page 6: Connections
Baud Rate 115200 Pin 5 1. NC Data Bit 2. RX 3. TX Parity None 4. NC Stop Bits 5. GND Handshake None Male DB9 RS232 Pin Out www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... - Page 7 All television connections should use stereo 3.5mm mini jack. Use of other types of mini jack will damage the television. Use of other types of mini jack will damage the television. www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797...
-
Page 8: External Speaker Connections
The image shown is the sockets as shown in the image. connection to Videotree’s External Ceiling Speakers. Lift or Do NOT use the central socket. press the plastic levers to open... -
Page 9: Viewing Angles & Positioning
If you are unsure about the installation of your television STOP IMMEDIATELY and contact a professional. Incorrect installation could result in bodily injury or damage to the television. www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... -
Page 10: Television & Backbox Dimensions
1073 1266 PACKAGING DIMENSIONS Length 1200 1250 1500 Depth SCREEN Height 1200 Weight 11kg 16kg 22kg 29kg 35kg 40kg (kg) *Measurements are in millimetres (mm) unless otherwise stated. www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... -
Page 11: Installation
Tidy any excess length the cutout and fill in any gaps around away to tidy the area (power supply, the edge of the backbox using a filler. HDMI, aerial cable etc). www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... -
Page 12: Screen Removal
4. Release the glass sucker from the screen by pulling the levers. (Subtitle Toggle) Stop (Subpage) Skip backwards (Guide) PLEASE NOTE: The Master Remote Control is NOT waterproof. Do NOT get wet or submerge under water. www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... -
Page 13: Learning Remote Control
NUMB05 Control CHANNEL 6 NUMB06 CHANNEL 7 NUMB07 CHANNEL 8 NUMB08 PLEASE NOTE: The Learning Remote Control is splashproof ONLY. CHANNEL 9 NUMB09 Do NOT submerge under water. www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... -
Page 14: Rs232 Codes
Fast Forward DB9 Pin connection signals: Fast Backward 2 -RX 3 -TX Stop Stop 5 - Ground *See ‘Tuner User Guide’ for INDEX references and full tuner setup instructions. www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... -
Page 15: Auto-Installation
This function can also be found in the Main Menu. Volume Adjust: Adjust the volume by pressing either “VOL ” or “VOL ” buttons. A volume adjusting level will appear on the screen displaying the current volume. www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797... - Page 16 AUTO-INSTALLATION AUTO-INSTALLATION CONTINUED CONTINUED Setup 2: Select the Country Setup 4: Select “Auto Power Off” Setup 3: Select the Language Setup 5: Select the TV connection www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797...
- Page 17 KEY_CHANNEL_LIST Exit Menu KEY_RED Show “Find” Mode Menu OPTION VALUE Load Default Database / Import default Satellite Database Import database Satellite System Enter “Satellite System” menu for settings www.videotree.com www.videotree.com Tel: +44 (0)1932 267 797 Tel: +44 (0)1932 267 797...
-
Page 18: Troubleshooting
If the emitter does not flash then you will need to replace the batteries. If you are still experiencing difficulties operating your television after following the troubleshooting guide, please contact us or visit our website: Email: sales@videotree.com Telephone: 01932 267 797 www.videotree.com www.videotree.com www.videotree.com... -
Page 19: Technical Specifications
MOVIE Left/Right 88° / 88° .avi (DivX, Xvid, MPEG-4) .mp4 To comply with this directive, Videotree are offering customers the option AUDIO OUT .mpg MPEG-1, MPEG-2 to return their old televisions to us for correct disposal. Digital Audio SPDIF Coax .dat MPEG-1... -
Page 20: Product Care
The warranty covers manufacturer defects and mechanical faults for 2 years from the date of purchase. Your Videotree television is guaranteed for 2 years, but should last for around 10-15 years. We recommend that you regularly check and replace We recommend that you register your television for warranty by visiting: the batteries within the remote controls. -
Page 21: Product Codes
Telephone: 01932 267 797 (Mon-Fri, 9am-5pm) Overseas: +44 (0)1932 267 797 Fax: 01932 251 206 The contents of this manual are subject to change Email: sales@videotree.com at anytime. Please contact Videotree for more Web: www.videotree.com information. www.videotree.com Tel: +44 (0)1932 267 797...
