- Page 1 Label Printer User Manual LPQ58 LPQ80 Xiamen Hanin Electronic Technology Co.,Ltd ADD: Room 305A,Angye Building, Pioneering Park, Torch High-tech Zone, Xiamen, China 361009 Tel.: +86-(0)592-5885993 Fax: +86-(0)592-5885992 Web: www.hprt.com...
- Page 2 2014.10.28 Preliminary Cui Xiao Yang Kaiqu Ren Xiaowei 1.Add LED description. 2.Modify layout. 2015.04.14 3.Modify the LPQ58/80 TPH life. Ji Qiuxia Yang Kaiqu Ren Xiaowei 4.Modify the working condition temperature 1.Update the fonts(P8); 2015.12.10 2.Add more description of chapter 5...
-
Page 3: Table Of Contents
Table of Contents Chapter1 Introduction ......................5 1.1Packing List ......................5 1.2 Appearance And Components ................6 1.3 Dimension ......................7 Chapter 2 Specification ......................9 Chapter 3 Installation & Usage ....................11 3.1MediaLoading .....................11 3.1.1 Paper Roll Loading ...................11 3.1.2 Fanfold Paper and Big Roll Paper ..............13 3.2 POWER Connection ....................13 3.3 Interface Cable Connection ................14 3.4 Button and LED ....................15... - Page 4 User Manual LPQ58/LPQ80 Manual Information ■ This user manual contains basic information for product usage as well as for emergency measures that may be required. ※ The following separate manuals provide more detailed content on various technological issues and areas.
-
Page 5: Important Safety Instructions
User Manual LPQ58/LPQ80 ■Important Safety Instructions Before using the present appliance, please carefully read the following safety regulations in order to prevent any hazard or material damage. 1. Safety Warning Warning: The print head will become very hot during printing, avoid contact with the print head after printing has finished. - Page 6 User Manual LPQ58/LPQ80 Caution: Violating following instructions can cause slight wound or damage the appliance. 1) If you observe a strange smoke, odour or noise from the printer, unplug it before taking following measures. • Switch off the printer and unplug the set from the mains.
- Page 7 User Manual LPQ58/LPQ80 3. Other Precautions The copyright for this user manual and various other manuals is property of the HPRT Corporation. Any copying or conversion into electronic firm and saving of this material without the express written permission of HPRT Corporation. is strictly prohibited. Use of the information contained in this manual is not subject to any patent liability.
-
Page 8: Chapter1 Introduction
User Manual LPQ58/LPQ80 Chapter1 Introduction 1.1Packing List Notes: 1. Unpack the printer and keep the packing material in case you need to ship the printer in the future. 2. Make sure you own all parts as follows, if not, do contact the seller. -
Page 9: Appearance And Components
User Manual LPQ58/LPQ80 1.2 Appearance And Components Front Rear Inside Install the Cables Fastener Rev.1.3... -
Page 10: Dimension
User Manual LPQ58/LPQ80 1.3 Dimension LPQ58 Rev.1.3... - Page 11 User Manual LPQ58/LPQ80 LPQ80 Rev.1.3...
-
Page 12: Chapter 2 Specification
User Manual LPQ58/LPQ80 Chapter 2 Specification (2/1) Items Parameter LPQ58 LPQ80 Printing Method Direct Thermal Resolution 203dpi(8dots/mm) Printing Printing Speed 76mm/s Max. 102mm/s Max. Printing Width 56mm Max. 80mm Max. Printing Length 400mm 300mm Processor 32 bit RISC CPU Memory... - Page 13 User Manual LPQ58/LPQ80 (2/2) Items Parameter LPQ58 LPQ80 AC100V ~240V 50/60Hz 1.5A Power Input Power Adapter Power Supply DC12V 2A Operation 41℉ - 104℉(5℃-40℃),30% - 85% (no condensing) Environment -4℉ - 122℉(-20℃-50℃),10% - 50% (no condensing) Storage Dimension(L*H*W) 186*133*128mm 188*134*150mm...
-
Page 14: Chapter 3 Installation & Usage
User Manual LPQ58/LPQ80 Chapter 3 Installation & Usage 3.1MediaLoading 3.1.1 Paper Roll Loading 1. Use both of your index fingers to push the buttons towards front to open the top cover 2. Pull out the paper roll holder, 0.5/1.0/1.5 inch of core is accessible. - Page 15 User Manual LPQ58/LPQ80 4. Pull some paper out, adjust the paper guide to fix the paper. 5. Close the cover and tear off the excess paper. Rev.1.3...
-
Page 16: Fanfold Paper And Big Roll Paper
User Manual LPQ58/LPQ80 3.1.2 Fanfold Paper and Big Roll Paper When you use fanfold paper or big roll paper, please refer to the graph below to assemble the external roll mount and adjust the paper guide to fix the paper. -
Page 17: Interface Cable Connection
User Manual LPQ58/LPQ80 3.3 Interface Cable Connection Connect the interface cable as shown below. This printer supports the following communications interface standards. -- RS-232C(Serial) Cable -- USB B-Type Cable USB cable Serial cable 1) Turn off the 【POWER】 switch. 2) Connect the communication cable to the printer communication port to be used. -
Page 18: Button And Led
User Manual LPQ58/LPQ80 3.4 Button and LED 3.4.1 Control Button 【POWER】 button This button is used to turn the printer on/off. When the printer is off, keep pressing 【POWER】 button about 1.25 second, the printer is on and the LED indicator is blue. The printer work normally, the LED indicator is green. When paper out or abnormal working, the LED indicator is red. -
Page 19: Preparing For Label Printing
User Manual LPQ58/LPQ80 3.5 Preparing for Label Printing The movable paper sensor must be fixed as shown below to make sure that paper sensor can detect the paper status and label location under label printing mode. 3.6 Parameter Setting 3.6.1 Printer setting using utility tool Various printer settings(Baud rate, Density, Paper type, etc.) can be changed using the utility... - Page 20 User Manual LPQ58/LPQ80 Enter setting mode: Setting baud: Baud = 9600 The default baud rate is 9600, when the baud rate does not need to be changed, press the 【FEED】button once to quit the current menu and enter the next settings.
- Page 21 User Manual LPQ58/LPQ80 If you wants to change it, press 【POWER】 button to switch the setting value and the printer will prints out the current setting:‘ density: ***** ’.When the value is required, press the 【FEED】button once to confirm and quit, then enter the forth setting -print width setting.
-
Page 22: Test Printing
User Manual LPQ58/LPQ80 3.7Test Printing 3.7.1 Self Test The self-test checks whether the printer has any problems. The method of self-test: 1.Turn the printer off. 2.Load roll paper, close the printer cover. 3.Press the 【FEED】button and 【POWER】 button simultaneously turns the printer on, the printer prints ‘self-test page’. -
Page 23: Chapter 4 Interface
User Manual LPQ58/LPQ80 Chapter 4 Interface 4.1USB interface Figure 4-1 PIN No. Signal name VBUS 4.2 Cashdrawer Pin No. Signal Function Frame Ground DRAWER1 Drawer kick-out drive signal 1 DRSW Drawer open/close signal Drawer driving source Drawer kick-out drive signal 2... -
Page 24: Serial Interface
User Manual LPQ58/LPQ80 4.3 Serial Interface PIN No. Signal name Rev.1.3... -
Page 25: Chapter 5 Cleaning
User Manual LPQ58/LPQ80 Chapter 5 Cleaning Adhesives and coatings of the media can transfer onto the printer parts over time along the media path including the thermal print head and media sensor. This build-up can accumulate dust and debris. Failure to clean the print head, media path, and media sensor could result in print quality, worst more of inadvertent loss off labels, label jams and possible damage to the printer.
