- Page 1 Label Printer User Manual HLP106D Xiamen Hanin Electronic Technology Co.,Ltd ADD: Room 305A, Angye Building, Pioneering Park, Torch High-tech Zone, Xiamen, China 361009 Tel.: +86-(0)592-5885993 Fax: +86-(0)592-5885992 Web: www.hprt.com...
- Page 2 REVISION RECORDS REV. DATE DESCRIPTION DRAWN CHECKED APPROVED 2014.11.18 Preliminary Cui Xiao Yang Kaiqu Ren Xiaowei 1.Update Important Safety Instruction 2.Change structure General Specification 3.Update the printing speed to 120mm/s; 4.Change the picture of Control Panel 5.Update Chapter 5 2015.06.24 Ji Qiuxia Yang Kaiqu Ren Xiaowei...
-
Page 3: Table Of Contents
Contents MANUAL INFORMATION ......................1 IMPORTANT SAFETY INSTRUCTIONS ..................2 CHAPTER 1 INTRODUCTION...................... 4 1.1 Packing List ......................... 4 1.2 Appearance and Components ..................5 1.3Dimension ........................6 CHAPTER 2 SPECIFICATIONS ..................... 7 CHAPTER 3 INSTALLATION & USAGE ..................8 3.1 Media Loading ...................... -
Page 4: Manual Information
HLP106D User Manual MANUAL INFORMATION This user manual contains basic information for product usage as well as for emergency measures that may be required. ※ The following separate manuals provide more details on various technological issues and areas. 1.Windows Driver Manual This manual provides information on the installation instructions and main functions of the Windows Driver. -
Page 5: Important Safety Instructions
HLP106D User Manual IMPORTANT SAFETY INSTRUCTIONS Before using the appliance, please carefully read the following safety regulations in order to prevent any hazard or material damage. 1.Safety Precautions 1) Be sure to use the accompanying power charger, if not, it may cause fire, explosion or damage. - Page 6 HLP106D User Manual 4. Other Precautions The copyright for this user manual and various other manuals is property of our company. Any copying or conversion into electronic firm and saving of this material without the express written permission of our company is strictly prohibited. Use of the information contained in this manual is not subject to any patent liability.
-
Page 7: Chapter 1 Introduction
HLP106D User Manual CHAPTER 1 INTRODUCTION 1.1 Packing List Notes: 1. Unpack the printer and keep the packing material in case you need to ship the printer in the future. 2. Make sure you own all parts as follows, if not, do contact the local dealer. -
Page 8: Appearance And Components
HLP106D User Manual 1.2 Appearance and Components ￭ Front ￭ Rear ￭ Inside Rev.1.2... -
Page 9: Dimension
HLP106D User Manual 1.3Dimension Rev.1.2... -
Page 10: Chapter 2 Specifications
HLP106D User Manual CHAPTER 2 SPECIFICATIONS Items Parameter Printing Method Thermal Transfer/Direct Thermal Resolution 203dpi(8dots/mm) Printing Speed 102mm/s Max. Printing Printing Width 108mm Max. Printing Length 15mm - 300mm 32 bit RISC CPU Processor Memory Flash Adjustable reflective sensor, Fixed... -
Page 11: Chapter 3 Installation & Usage
HLP106D User Manual CHAPTER 3 INSTALLATION & USAGE 3.1 Media Loading 3.1.1 Open the Printer Cover Push two cover open buttons simultaneously and then lift the cover. 3.1.2 Open The Printing Group Press the two release latches simultaneously and lift the printing group. -
Page 12: Paper Roll Loading
HLP106D User Manual 3.1.3 Paper Roll Loading 1. Open the printer cover. 2. According to the roll paper core size, adjust the direction of paper supply shaft. Put the roll paper into the paper supply shaft. It can support three kinds of roll paper core, there are instruction on the paper supply shaft. -
Page 13: Ribbon Loading
HLP106D User Manual 3.1.4 Ribbon Loading 1.Put the new ribbon into the ribbon supply shaft, and put ribbon supply group into the printing group. Figure 3-3 2. Put the empty ribbon core into ribbon pick-up shaft, and put ribbon pick-up group into the printing group. - Page 14 HLP106D User Manual 3.Pull some ribbon out, pass through print head. Stick the front of ribbon to the empty ribbon core and wind the ribbon core 2~3 circles. Turn around the ribbon feed mechanism to make it smooth. 4. Press down the printing group and fix it, then close the printer cover.
-
Page 15: Power Connection
HLP106D User Manual 3.2 Power Connection 1. Make sure the printer is off. 2. Make sure that voltage of the power adapter conforms with voltage of power. 3. Connect the power adapter to the printer power supply connector. 4. Connect the power cord to the power adapter. -
Page 16: Interface Cable Connection
HLP106D User Manual 3.3 Interface Cable Connection The standard for the printer’s interface cable is below: - USB B-Type cable - Ethernet cable 1. Make sure the printer is off. 2. Please plug in the cables Insert the RJ-45 cable into Ethernet interface;... -
Page 17: Control Panel
HLP106D User Manual 3.5 Control Panel 1. READY and STATUS indicators Show the printer’s information via different colors(red & kelly) and LED status( on and flash) 2. FEED button ① Feed paper The printer will auto-feed the paper to the specified points according to the type of paper used. -
Page 18: Basic Operation
HLP106D User Manual 3.6 Basic Operation 3.6.1 Power On/Power Off Press “O” to power off the printer. Press "I" to power on the printer. 3.6.2 Feed Paper Pressing FEED button, printer will feed paper to the specified position according to the paper type. -
Page 19: Label Learning(Calibration)
HLP106D User Manual 3.8 Label Learning(Calibration) Note : Users must carry out the calibration under those conditions below: The first time to use the printer since installation; The first time to use the printer since sensor cleaning; ... -
Page 20: Chapter 4 Interface
HLP106D User Manual CHAPTER 4 INTERFACE 4.1 USB Interface Figure 4-1 SIGNAL NAME VBUS 4.2 Other Optional Interface Ethernet Port PIN NO. Signal Name Rev.1.2... -
Page 21: Chapter 5 Printer Cleaning
HLP106D User Manual CHAPTER 5 PRINTER CLEANING Adhesives and coatings of the media can transfer onto the printer parts over time along the media path including the thermal print head and media sensor. This build-up can accumulate dust and debris. Failure to clean the print head, media path, and media sensor could result in print quality, worst more of inadvertent loss off labels, label jams and possible damage to the printer.
