Harness - RMS Simba User Manual

Supplied with screws and fixings.
Tools Required: Sharp Trimming Knife or Blade.
NOTE: For safety reasons, the user should be removed from the buggy.
Remove and save any tri-glides placed on the harness straps before commencing
this installation.
With the mounting height for the upper harness straps established, peel the top of
the backrest upholstery forwards away from the Velcro pads.
sufficient to allow the harness straps to pass through. Then continue routing the
straps through the relevant slots in the backrest panel before re-installing the tri-
glides onto the straps.
It will not be necessary to pierce the backrest upholstery for the lower straps, as
these can be routed directly between the seat cushion and back upholstery,
continuing through one of the lower mounting slots in the backrest panel. Re-install
tri-glides onto these straps.
Re-attach the backrest upholstery as required.
Detach the harness centre panel from the straps and re-seat the user.
Correct positioning of the harness panel is achieved by a combination of upper and
lower strap adjustments both at the rear tri-glides and upper harness cam-lock
buckles.
The mounting slot positions for the upper harness
straps to pass through are indicated as shown by
pre-formed lines of stitching. Whilst these are also
visible from the rear of the upholstery, the slots
required should be located under the folds at the
front of the upholstery (as shown above).
Using a trimming knife or blade, carefully pierce
through between the stitching lines only, just
Four upper
mounting positions
Two lower
mounting positions

HARNESS

Dynamic harness shown
