Air / Hydraulic Floor Service Jack
This service jack is equipped with a manual foot and handle pump, along with an air-over hydraulic pump.
17
1
/
in.
8
3
3
/
in.
8
26
/
in. raised height
5
8
6
3
/
in.
4
lowered height
Max. Capacity: 10 Tons
Application: Designed to lift a wide range of motor vehicles.
Rated Capacity: 20,000 lbs.
Air Supply: 90–175 psi
Weight: 410 lbs.
5 in. dia.
Shaded area reflects
Parts List &
Operating Instructions
for:
55 in.
TOP VIEW
7
3
/
in. dia.
8
SIDE VIEW
9
/
in.
3
4
4 in. dia.
current revision.
Form No. 102753
20
/
in.
1
8
55
/
in.
1
4
© Bosch Automotive Service Solutions Inc.
Sheet No.
1 of 4
Issue Date: Rev. J, October 19, 2015
5110
