- Page 1 DC-S Series Installation Manual DC-S1283WRX Powered by...
- Page 2 Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
-
Page 3: Safety Precautions
Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. -
Page 4: Fcc Compliance Statement
© 2016 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements. -
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
• Supports H.264 video compression and M-JPEG still compresses and transmits video over ethernet. image compression algorithms You can use the IDIS Discovery program to change • Supports 4-stage video compression rate and network camera settings or the IDIS Solution Suite... - Page 7 • Slow shutter support for improved low-lighting video Remote monitoring and recording via multistreaming capture performance are available using the IDIS Solution Suite Compact • Day & Night feature (built-in IR cut filter changer) program. For more information on using IDIS Solution •...
-
Page 8: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Mount Adapter, Screws Open Source Guide Quick Guide... -
Page 9: Overview
Part 1 – Introduction Overview Lens Rear Side Product color and design may vary depending on the model. Body Lens Front Side Factory Reset Button SD Memory Card Slot • Cable Refer to the Cable. • Safety Wire Secures the body to the bracket or the bracket to the body. -
Page 10: Cable
For more information necessary. on network connection setup, refer to the IDIS Discovery operation manual. • Power Connect the power adapter. - Page 11 Part 1 – Introduction – ALO: It is the BJT (Bipolar Junction Transistor) - When inserting an alarm in/out, audio in/out, open collector output. If the voltage and current or video out, connector, hold down the button exceed the specification limit (Max load: 30mA, and push the connector in through the exposed Max Voltage: 5VDC), the product could be hole.
-
Page 12: Factory Reset
It's also possible to do a factory reset by pressing and releasing the reset switch while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. -
Page 13: Installation
Part 1 – Introduction Installation Insert a SD memory card into the SD memory card slot with the 'micro SD' print facing upward. • Check the wall or ceiling to see if it needs to be reinforced. The camera may fall off if the wall or ceiling is not strong enough to support its weight. -
Page 14: Dimensions
Part 1 – Introduction Route the cable from the camera through the Dimensions bracket. Assemble the mount adapter to the bracket. Connect external devices, the network cable, and the power. Supply the power. Ø228mm (8.98”) -
Page 15: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Alarm Out 24 VAC Sensor In Monitor Out... -
Page 16: With Non Directip™ Nvr-Based Layout
Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact. -
Page 17: Part 3 - Appendix
ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below. -
Page 18: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/2.8" CMOS Max. Resolution 1920 x 1080 Scanning Mode Progressive Scan Lens type AF Zoom Lens Focal Length f=4.3mm ~ 129.0mm Aperture F1.6 ~ 5.0 Iris Control DC Auto Iris Angular Field of View... - Page 19 Part 3 - Appendix Network Video Compression H.264(MP), M-JPEG Bitrate Control H.264 - VBR Max. Frame Rate 30fps : 1920 x 1080 Audio Compression G.726, G.711 Supported DirectIP 1920x1080, 1280x720, 704x480, 640x360, 352x240 Resolution Non DirectIP 1920x1080, 1280x720, 704x480, 352x240 Multi-Video DirectIP Quadruple...
- Page 20 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
