- Page 1 HD-TVI Camera User Manual IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
-
Page 2: Camera Installation
CAMERA INSTALLATION 1. TC-B1202 - 1 -... - Page 3 CAMERA INSTALLATION 2. TC-D1212R - 2 -...
- Page 4 CAMERA INSTALLATION 3. TC-D1222R - 3 -...
- Page 5 CAMERA INSTALLATION 4. TC-D1222WR - 4 -...
- Page 6 CAMERA INSTALLATION 5. TC-E1212WR - 5 -...
- Page 7 CAMERA INSTALLATION 6. TC-T1222WR - 6 -...
- Page 8 BOX CAMERA INSTALLATION GUIDE 1. Power : If camera power is on properly, red signal is turn on. 2. Video : Analog Video Signal Output 3. TVI : HD-TVI Signal Output 4. Power : Connect DC 12V Properly 5. RS-485 : Use RS-485 Protocol 6.
- Page 9 CAUTION CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK). DO NOT REMOVE COVER(OR BACK).
-
Page 10: Table Of Contents
Contents Contents General Features Precautions Safety Instructions Menu Set Up Set Up Menu ▶ Menu Set Up ▶ Lens ▶ Exposure ▶ White Bal ▶ Backlight ▶ ▶ Day&Night ▶ Image ▶ Motion ▶ System ▶ Exit ▶ Specifications Trouble Shooting - 9 -... -
Page 11: General Features
General Features ● Transfer Video Interface The combination of a 2Mega CMOS image sensor and TVI DSP provides an excellent resolution of TVI picture. ● 3D-DNR Smart 3DNR prevents the image blurring of moving object and activates only if moving objects are appearing on the scene. ●... -
Page 12: Precautions
Precautions Do not install the camera in Do not install or use the camera in an Do not install the camera under extreme temperature conditions. environment where the humidity is unstable lighting conditions. high. Do not install or use the camera in an Only use the camera under conditions Severe lighting change or flicker can environment where the humidity is high. -
Page 13: Safety Instructions
Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use appropriate low voltage power cable to prevent fire or electrical shock ◑... -
Page 14: Menu Set Up
How to Set Up the camera menu ● Setup Menu - 13 -... - Page 15 How to Set Up the camera menu ● Setup Menu - 14 -...
- Page 16 How to Set Up the camera menu ● Setup Menu - 15 -...
-
Page 17: Menu Set Up
Menu Set Up Menu setting can be selected by the button inside the camera. 1. Press the set button. * The Set Up menu will be displayed on the monitor. MENU 1.LENS DCAUTO 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.DNR 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION... -
Page 18: Lens
3. Change menu settings using the Left or Right button. * Available values or Status are displayed by pressing the Left or Right buttons. Press the button until desired value / status is displayed. 4. After Changing the setting move the arrow indicator to EXIT and press the SET button to EXIT. -
Page 19: Exposure
NOTE MODE MODE INDOOR RETURN * When you select the mode setup, you can select INDOOR, OUTDOOR or DEBLUR depending on the installation environment. *On manual mode, you can select NORMAL or DEBLUR depending on the installation environment. EXPOSURE 1. On the Set Up menu, Select EXPOSURE by using the Up or Down button. MENU 1.LENS 2.EXPOSURE... -
Page 20: White Bal
◆ BRIGHTNESS : The brightness can be adjusted. The brightness control range is 1~20. ◆ SHUTTER : DC lens is launched with the setting of 1/30 and the manual lens is launched with the setting of Auto shutter, but the shutter speed can be adjusted from 1/30 to 1/30,000. - Page 21 ◆ AUT0 : Use this mode when the color temperature is from 2,500k to 9,500k. ◆ AWB : The function to search for the color which is matched well with the ambient environment. ◆ AWC→SET : After letting camera focus on the blank white paper to the best condition of current lighting environment, press the SET button.
-
Page 22: Backlight
BACKLIGHT On this menu, backlight image can be compensated by users selecting one of modees. (HLC, BLC, WDR) 1. Move the triangular indicator to BACKLIGHT on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1.LENS 2.EXPOSURE... - Page 23 ◆ BLC : This fuction is used to counterbalance the screen image by increasing the brightness so that a subject which appears dark due to a strong backlight can be displayed in more detail. If you select BLC, a submenu appears where you can make finer adjustments. - H-POS/V-POS/H-SIZE/V-SIZE : Define the position and size of the area of interest by changing the position &...
-
Page 24: Dnr
This fuction is used to improve the picture quality by filtering the noise which is generated under low bright light conditions. You can set different levels here. 1. Move the triangular indicator to DNR by useing the Up and Down button. 2. - Page 25 ◆ AUTO : Automatically, It shifts into the color mode in the bright environment and the B/W mode in the low light condition. It can adjust the delay time, starting brightness and end brightness according to the ambient conditions by pressing the set button. DAY&NIGHT SMART IR IIIIIIIIIIIIIII| 20...
-
Page 26: Image
- EXTERN S/W [LOW/HIGH] : Set the external signal for switching between COLOR and B/W. - DELAY [LOW/MIDDLE/HIGH] : Set the delay time for switching between COLOR and B/W . IMAGE When selecting, the following submenu will appear. MENU 1.LENS 2.EXPOSURE 3.WHITE BAL AUTO... - Page 27 - D-ZOOM : You can use the digital zoom with x1~x8 magnification. The higher the digital zoom magnification is, the lower the resolution is. - ACE [LOW/MIDDLE/HIGH] : Intelligent light level control to over come even strong backlight conditions. - DEFOG [ON, OFF] : This fuction helps to recognize the object in a dusty weather condition. ON, a submenu appears where you can make finer adjustments.
-
Page 28: Motion
MOTION This function is used to detect moving objects in the monitored area. When choosing ON, the following submenu will appear where you can adjust the settings for the MOTION function. MENU 1.LENS 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.DNR 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION... -
Page 29: System
SYSTEM This can be used when you want to select the additional function control. 1.When the SETUP menu is displayed, select SYSTEM using the Up and Down button. 2. Select one of the mode using the Up and Down button. MENU 1.LENS 2.EXPOSURE... -
Page 30: Exit
Exit Press the Set button in the exit menu to save the current settings and exit the Set Up menu. - 29 -... -
Page 31: Specifications
Specifications MODEL TC-B1202 Sensor type 1/2.8" SONY 2Mega Exmor CMOS Sensor Effective pixels 1984(H) X 1105(V), 2.19M Pixels Total pixels 2000(H) X 1121(V), 2.24M Pixels Resolution 1920X1080(1080p@30f / 1080p@25f) Scanning system Progressive Scan Min. illumination 0.001 Lux @ F1.2 , (Sens-UP X32) Video Output 1.0Vp-p Composite. - Page 32 Specifications MODEL TC-D1212R Sensor type 1/2.8" SONY 2Mega Exmor CMOS Sensor Effective pixels 1984(H) X 1105(V), 2.19M Pixels Total pixels 2000(H) X 1121(V), 2.24M Pixels Resolution 1920X1080(1080p@30f / 1080p@25f) Scanning system Progressive Scan Min. illumination COLOR : 0.3 Lux @ F1.2, B/W : 0 Lux (IR LED ON)
- Page 33 Specifications MODEL TC-D1222R Sensor type 1/2.8" SONY 2Mega Exmor CMOS Sensor Effective pixels 1984(H) X 1105(V), 2.19M Pixels Total pixels 2000(H) X 1121(V), 2.24M Pixels Resolution 1920X1080(1080p@30f / 1080p@25f) Scanning system Progressive Scan Min. illumination COLOR : 0.9 Lux @ F1.8 IR LED B/W : 0 Lux (IR LED ON) Video Output...
- Page 34 Specifications MODEL TC-D1222WR Sensor type 1/2.8" SONY 2Mega Exmor CMOS Sensor Effective pixels 1984(H) X 1105(V), 2.19M Pixels Total pixels 2000(H) X 1121(V), 2.24M Pixels Resolution 1920X1080(1080p@30f / 1080p@25f) Scanning system Progressive Scan Min. illumination COLOR : 0.9 Lux @ F1.8, B/W : 0 Lux (IR LED ON) IR LED 28EA Video Output...
- Page 35 Specifications MODEL TC-E1212WR Sensor type 1/2.8" SONY 2Mega Exmor CMOS Sensor Effective pixels 1984(H) X 1105(V), 2.19M Pixels Total pixels 2000(H) X 1121(V), 2.24M Pixels Resolution 1920X1080(1080p@30f / 1080p@25f) Scanning system Progressive Scan Min. illumination COLOR : 0.9 Lux @ F1.8, B/W : 0 Lux (IR LED ON) IR LED 24EA Video Output...
- Page 36 Specifications MODEL TC-T1222WR Sensor type 1/2.8" SONY 2Mega Exmor CMOS Sensor Effective pixels 1984(H) X 1105(V), 2.19M Pixels Total pixels 2000(H) X 1121(V), 2.24M Pixels Resolution 1920X1080(1080p@30f / 1080p@25f) Scanning system Progressive Scan Min. illumination COLOR : 0.9 Lux @ F1.8, B/W : 0 Lux (IR LED ON) IR LED 42EA Video Output...
-
Page 37: Trouble Shooting
Trouble Shooting PROBLEM POSSIBLE CAUSE ☞ Check the power cable, power supply output and video Nothing appears on connection between the camera and monitor. the screen. ☞ Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞... - Page 38 - MEMO - - 37 -...
- Page 39 - MEMO - - 38 -...
