- Page 1 INSTAL ACIJA / UPOR ABA / VZDRŽEVANJE - SI 7003 - 7023 - 7103 - 7123 - 8103 VD - 8103 VDM - 8123 VD - 8123 VDM 8203 - 8203 M - 8223 - 8223 M - MO8302 - MO8303 - MO8322 - MO8323...
-
Page 2: Table Of Contents
WIRING- CONNECTING TO ELECTRICITY SUPPLY FIXTURE WARNINGS CONTROLS BURNERS: HOB: SELECTING BURNER ELECTRONIC IGNITION HOB (DEPENDING ON MODEL) MANUAL IGNITION HOB HOB FLAME REGULATION VISUAL FLAME CONTROL GAS CYLINDERS / BOTTLES MAINTENANCE CLEANING INJECTORS SMEV ACCESSORIES TEST PRESSURE POINT10 FIGURES AND TECHNICAL DRAWINGS 122-135... -
Page 3: Installation
SAFETY WARNINGS THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH THE REGULATIONS IN FORCE AND ONLY USED IN AN ADEQUATELY VENTILATED AREA. ALWAYS READ THE INSTRUCTIONS PROVIDED THOROUGHLY BEFORE INSTALLING AND USING THIS APPLIANCE. THIS APPLIANCE MUST BE INSTALLED BY SPECIALISED GAS SERVICE ENGINEERS. THIS APPLIANCE IS DESIGNED AND MANUFACTURED FOR COOKING FOOD ONLY. -
Page 4: Connecting To Gas Supply
3,2 - 233 PI8842D - PI8842S - PI8862D - PI8862S MO9122 3,6 - 262 7003 - 7023 - 7103 - 7123 8103 VD - 8103 VDM 8123 VD - 8123 VDM 3,8 - 277 8203 - 8203 M - 8223 - 8223 M... -
Page 5: Fixture
WHEN INSTALLING AND CONNECTING THE APPLIANCE TO THE GAS SUPPLY, ENSURE THAT THE GAS SUPPLY HOSE IS NOT TWISTED, STRETCHED OR SUBJECTED TO ANY FORM OF STRAIN WHICH COULD CREATE A HAZARD. The gas supply pipe connected to the appliance must be a rigid metal pipe with sealed fittings. It is possible to fit a flexible hose, however, in this case the following conditions must be respected: a) The hose can be accessed easily for inspection;... -
Page 6: Warnings
WARNINGS THIS APPLIANCE MUST ONLY BE USED BY RESPONSIBLE ADULTS. DURING USE AND IMMEDIATELY AFTER USE THE BURNER AND OTHER ACCESSIBLE PARTS MAY BE HOT; DO NOT TOUCH THESE PARTS AND ALWAYS KEEP CHILDREN AT A SAFE DISTANCE. AFTER USING THE APPLIANCE ENSURE THE KNOB/KNOBS ARE OFF. AFTER USE ALWAYS SHUT OFF THE GAS SUPPLY AT THE MAIN GAS TAP. -
Page 7: Burners
Technical specifications for burners referring to appliance model: MODEL THERMAL CAPACITY BURNERS AUXILIARY SEMI-RAPID RAPID Ø 47 mm Ø 62 mm Ø 77 mm gr/h gr/h gr/h 7003 7023 7103 7123 8103 VD 8103 VDM 8123 VD 8123 VDM 8203 8203 M 8223 8223 M... -
Page 8: Selecting Burner
- SELECTING BURNER THE FLAME MUST NEVER EXTEND BEYOND THE EDGE OF THE PAN. CENTRE THE PAN OVER THE BURNER ENSURING STABILITY ON THE PAN SUPPORT. BURNER PAN DIAMETER AUXILIARY from 6 to 16 cm Ø 47 mm SEMI-RAPID from 16 to 22 cm Ø... -
Page 9: Visual Flame Control
GAS CYLINDERS / BOTTLES NEVER OPERATE THE APPLIANCE WITH GAS AND OR AT GAS PRESSURES DIFFERENT TO THOSE INDICATED BY SMEV AS THIS COULD CAUSE IRREGULAR AND INCORRECT OPERATION. SMEV DECLINES ALL RESPONSIBILITY FOR DAMAGE OR INJURY CAUSED BY AN INCORRECT OR IMPROPER USE OF THE APPLIANCE. -
Page 10: Cleaning
RAPID 0,75 Ø 77 mm SMEV ACCESSORIES GLASS LID (FIG. 6 - PG. 135) only for models PI8621A, PI8621S, PI8621R. This optional accessory has two functions: when closed it can be used as an additional work surface and when open, during cooking, it protects the wall behind the appliance from food splashes. - Page 11 OPOMBE...
- Page 12 F I G .
-
Page 13: 8103 Vd
F I G . MOD. X mm Y mm 7103 445,89 7123 SEZ. B- B 304,65 mm 57,69 mm 170,35 mm 8,5 mm 60° 31,6 mm 31,6 mm SEZ. A- A 8,5 mm 90° 12 mm 57,91 mm 176,73 mm MOD. -
Page 14: Mo8302
MOD. X mm Y mm MO8302 MO8322 MO8303 MO8323 MO8342 MO8362 339,67 mm 300,25 mm 11 mm 11 mm 314 mm 19 mm 232,5 mm 222,36 mm 11 mm SEZ. A-A MOD. X mm Y mm PI8802D PI8822D PI8842D 511,02 PI8862D MO8801D 212,4... -
Page 15: Mo8821S
MOD. X mm Y mm PI8802S PI8822S 212,4 PI8842S 511,02 89,07 113,95 201,95 106,05 PI8862S MO8801S SEZ. A-A MO8821S 158,3 241,26 MOD. X mm 6 mm MO9122 316,6 322,7 SEZ. A-A 13,8 mm 18 mm 7,5 mm 135° 316,7 mm 135°... -
Page 16: Mo9202D
MOD. X mm Y mm MO9202D MO9222D 67,2 mm 67,2 mm 748,6 mm 158,9 mm 150,7 mm 439 mm 65,8 mm 65,8 mm 36,4 mm 100 mm 100 mm 36,4 mm 7 mm 49 mm 211,2 mm 79,3 mm 494,5 mm 49 mm SEZ. -
Page 17: Pi7203
228,1 mm 228,1 mm MOD. X mm Y mm 7003 456,2 466,1 7023 193,1 mm 193,1 mm 2 mm SEZ. A-A 228,1 mm 228,1 mm MOD. X mm PI7203 PI7223 PI7703 PI7723 SEZ. A-A 173 mm 278 mm... -
Page 18: Pi8002
X mm MOD. Y mm PI8002 PI8022 PI8042 PI8062 PI8502 PI8522 PI8542 PI8562 233 mm 233 mm 233 mm 233 mm X mm MOD. Y mm 273 mm 273 mm PI8003 PI8023 PI8043 PI8063 PI8503 PI8523 PI8543 PI8563 273 mm 273 mm... - Page 19 X mm MOD. Y mm 8203 8203 M 8223 8223 M 446 mm 393,3 mm SEZ. B-B MOD. X mm Y mm PI8403 PI8423 PI8443 PI8463 220 mm 205 mm 76 mm 135° 90° 199 mm 202 mm 70 mm SEZ.
-
Page 20: Pi8621A
MOD. X mm Y mm PI8621A PI8621S PI8621R SEZ.A-A 224 mm 46 mm 54 mm 4 mm MOD. X mm Y mm PI9003 PI9023 235 mm 235 mm 160,14 mm 228,1 mm 101,6 mm 135° 135° 140 mm 177,48 mm 259,47 mm 143,24 mm 119,12 mm... -
Page 21: Pi8621S
FIG. 3 MOD: 7003 PI7203 7023 PI7223 7103 PI7703 7123 PI7723 MO8302 PI8403 MO8303 PI8423 MO8322 PI8443 MO8323 PI8463 MO8342 PI8802D MO8362 PI8802S MO8801D PI8822D MO8801S PI8822S MO8821D PI8842D MO8821S PI8842S MO9202D PI8862D MO9202S PI8862S MO9222D PI9003 MO9222S PI9023 MOD:... - Page 22 MOD: 8103 VD 8103 VDM 8123 VD 8123 VDM ≥21 mm ≤25 mm 8203 8203 M 8223 8223 M ≥16 mm ≤21 mm MOD: PI8002 PI8003 PI8022 PI8023 ≥ 21 mm PI8042 ≤ 25 mm PI8043 PI8062 PI8063 PI8502 PI8503 PI8522 PI8523 ≥...
- Page 23 MOD: MO9122 FIG. 4...
- Page 24 FIG. 5...
- Page 25 FIG. 6...
