- Page 1 Dishwasher Instruction Manual Instruction Manual Instruction Instruction Manual Manual DW12V-ABB-4...
-
Page 2: Table Of Contents
CONTENTS Getting familiar with your machine ………………………………………………………. Technical specifications ……………………………………………………………… • Conformity with the standards and Test data ………………………………………... • Safety information and Recommendations………………………........ Recycling ..………………………................• Safety information ………………………………………………………………………. • Recommendations …...…………………………………………………………………. • Items not suitable for dishwashing ……………………………………………………. •... - Page 3 Loading your dishwasher .…………………………………………………………………….. Top basket…..……………………………………………………………………………….. • Alternative basket loads …………………………………………………......• Standard loading and Test data …………………………………………………………... • Programme descriptions .……………………………………………………………………... Programme items …………………………………………………………………………... • Switching on the machine and selecting a programme……………....... Switching on the machine………………………………………………………………….. • Programme follow-up……………………………………………………………………….. •...
- Page 4 Upper basket with racks Control Panel Upper spray arm Detergent and rinse-aid dispenser Lower basket Cutlery basket Lower spray arm Salt dispenser Filters Upper basket track latch Rating plate...
-
Page 5: Getting Familiar With Your Machine
GETTING FAMILIAR WITH YOUR MACHINE 1.) Power On/Off Button When the Power On/Off button is pressed, end of program Rinse aid Lack Warning indicator indicator starts lighting. In order to check that there is sufficient rinse aid in your machine check 2.) Programme selector button rinse aid lack warning light on the display.When rinse aid lack warning light starts coming on , fill in rinse aid chamber. -
Page 6: Technical Specifications
Technical specifications Capacity ………………………… 12 place settings Height……………………………. 815 mm – 870 mm Width …………………………….. 596 mm Depth ……………………………. 550 mm Net Weight ……………………... 38 kg Electricity input ……………..220-240 V, 60 Hz Total Power …………………….. 2200 W Heating Power ………………….. 2000 W Pump Power ……………………. - Page 7 Only original spare parts should be used with the machine. • Before installing, be sure that the machine is unplugged. • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. •...
-
Page 8: Recommendations
Prior to any repair work on the machine, be sure that the machine is cut off from the mains. • Switch off the fuse or unplug the machine. Do not pull by the cable when unplugging. Make sure to turn off the water tap. Recommendations For energy and water saving, remove coarse residues on your dishes before placing the dishes •... -
Page 9: Water Connections
Water connection Be sure that the indoor plumbing is suitable for installing a dishwasher. Also, we recommend that you fit a filter at the entrance of your place or apartment so as to avoid any damage to your machine because of any contamination (sand, clay, rust etc.) that might be occasionally carried in through the mains water supply or the indoor plumbing, and to forestall such complaints as yellowing and formation of deposits after washing. -
Page 10: Electrical Connection
Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur. -
Page 11: Prior To Using The Machine
Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the • installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •... -
Page 12: Testing Strip
Testing strip The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply. The washing effectiveness will increase when the system is correctly set. To find out the water hardness level of water in your area, contact your local water board or determine water hardness level by using the test strip(if available). - Page 13 Adjusting salt consumption Adjust the water softener according to how hard your tap water After resetting your machine, press the program selector button and keep it pressed down. Meanwhile, energise the machine by pressing the Power On/Off button. Keep the program selection button pressed until the leds” P1-P2-P3-P4-end of program indicator “...
-
Page 14: Detergent Usage
Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children. -
Page 15: Filling With Rinse Aid And Making The Setting
They produce good results for certain types of usage only. If you are using this type of • detergents, you need to contact the manufacturers and find out about the suitable conditions of use. When the conditions of use of such products and the machine settings are appropriate, •... -
Page 16: Loading Your Dishwasher
Warning: Use only those rinse aid materials which are allowed for use in the machine. As rinse aid residues left as a result of overflowing will create extremely high amounts of foam and thus reduce the washing performance, remove the excess amount of rinse aid by wiping it with a rag. LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance. -
Page 17: Top Basket
Alternative basket loads Lower Basket Top basket Faulty loads... -
Page 18: Standard Loading And Test Data
Standard loading and test data Capacity: Upper and lower baskets: 12 place settings. The upper basket should be adjusted to high position Cups should be placed on to the dish rack pins. Detergent / Rinse aid 5+25 cm , in accordance with EN50242-DIN 44990 IEC 436 (international norms) / Rinse aid dosage adjustment: 4 Programme test Economic 50°... -
Page 19: Programme Descriptions
PROGRAMME DESCRIPTIONS Programme items Programme No Reference Programme Intensive ( P1 ) Economic ( P2 ) Quick ( P3 ) Prewash ( P4 ) names and 65° C 50° C 40° C No Heat temperatures Type of food soups, sauces, coffee, milk, tea, coffee, milk, tea, Pre-wash to... -
Page 20: Switching On The Machine And Selecting A Programme
SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Switching on the machine When you select a program with the program selection button, the light of the selected program When you select a program with the program turns on and the end of program indicator turns off. selection button, the light of the selected program turns on and the end of program indicator turns off. -
Page 21: Changing A Programme With Resetting
Changing a programme with resetting If you would like to cancel a program while a washing program is resumed. Open the door of your machine. Light of the last selected program will turn on. Keep the program selection button pressed for 3 seconds. -
Page 22: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. -
Page 23: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. -
Page 24: Failure Codes And What To Do In Case Of Failure
FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE If the programme won’t start Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on. • Be sure that you have closed the machine door. •... - Page 25 Filters clogged. • Filters incorrectly fitted. • Water drain pump clogged. • If there are white looking stains on the dishes A very small amount of detergent is being used. • Rinse aid dosage setting at a very low level. •...
-
Page 26: Practical And Useful Information
PRACTICAL AND USEFUL INFORMATION Whenever you will not be operating your machine Unplug the machine and then turn the water off. • Leave the door slightly ajar in order to prevent the formation of unpleasant smells. • Keep the machine interior clean. •... - Page 27 52XXXX03...
