Mi TV Bar
user`s manual
Accessories
Power cable
MI PORT cabel
AV Cabel-adaptor
Batteries (№7) х2
Remote control strap*
Remote control
Components marked with * are optional accessories, that you can purchase separately
Installation
Connect Mi Bar to Mi TV
One end of the cable connect to Mi PORT socket of
Mi Bar, and the second - to HDMI socket of TV.
For maximum productivity of Mi Bar, do not put it on
the floor or on metal surface.
Connect to power
a: Connect Mi stereo subwoofer * to Power
b: Plug Mi Bar to Power. Connect the power cable
to the adapter and insert the adapter into the DC IN
19V Mi Bar port.
Switch on
Press the Power button. In a first start you must
follow instructions to complete all settings of Mi
Bar.
First, turn on the TV.
Advertisement
Related Manuals for Xiaomi MI
Summary of Contents for Xiaomi MI
- Page 1 Installation Connect Mi Bar to Mi TV One end of the cable connect to Mi PORT socket of Mi Bar, and the second - to HDMI socket of TV. For maximum productivity of Mi Bar, do not put it on the floor or on metal surface.
- Page 2 The Main Unit sockets Indicator Power button Volume up Start/Stop Previous Next Volume down Switching of music channels subwoofer port Internet HD player TV screen Blu-ray Antenna TV-antenna port Computer Computer Console TV box AV cable Blu-ray DVD adapter When you need to connect a wired / wireless port, or install a device in the port F, for connecting a coaxial line, you can choose an antenna adapter.
-
Page 3: Remote Control
Remote control Wheel of options Power Bluetooth console marked only with this symbol… Voice operated console marked with this Back symbols… Home Menu Volume Batteries Using the strap for the remote control 1. Thread the strap through the hole at the bottom of the battery compartment; 2. - Page 4 Power: port DC IN 19V Input: port HDMI 2.0 x3; AV x1; VGA x1 analog / digital TV (DTMB) x1 Output: Port MI PORT Audio out x1 (Mi subwoofer connection only) Data interface: USB 2.0 x1; USB 3.0 x1; Ethernet x1 Connecting antennas Wifi dual 2.4 GHz, 5GHz, 802.11 a / b / g / n / ac, (support for Beamforming, TWIN ANTENNA 2x2 MIMO)
-
Page 5: Warranty
30 days. In case of return or exchange goods if there is some damage to the packaging or you lost or utilized it, Xiaomi may require reimburse the cost of packaging. Thanks for...
