Cobra CPI190 Operating Instructions Manual

Traveler power inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
RECHARGEABLE APPLIANCES
CAUTION
Certain rechargers for small
nickel cadmium batteries
can be damaged if connected
to the unit. Two types of
equipment are particularly
prone to this problem:
1. Small battery operated
appliances that can be
plugged directly into
an AC receptacle for
recharging, including
flashlights, razors, and
night lights.
2. Certain battery chargers for
battery packs used in hand
power tools, specifically
those that have a
WARNING label stating
that dangerous voltages
are present at the battery
terminals.
1
Problems do not occur with
the vast majority of battery
operated tools, most of which
use a separate charger or
transformer that plugs into
an AC receptacle and produces
a low voltage output. If the
label on your tool's AC adapter
or charger states that is
produces a low voltage AC or
DC output (less than 30 volts)
you can safely power the
charger.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPI190 and is the answer not in the manual?

Questions and answers

Related Manuals for Cobra CPI190

Summary of Contents for Cobra CPI190

  • Page 1 RECHARGEABLE APPLIANCES Problems do not occur with CAUTION the vast majority of battery operated tools, most of which Certain rechargers for small use a separate charger or nickel cadmium batteries transformer that plugs into can be damaged if connected an AC receptacle and produces to the unit.

  • Page 2: Connecting To The Power Source

    BEFORE USING YOUR INVERTOR Connecting to the In order to check the Power Source performance of your unit before using it, please Your unit connects have the following directly into the cigarette on hand: lighter socket of your car. 1. A 12 volt DC power source (such as a vehicle battery).

  • Page 3: Quick Checkout

    QUICK CHECKOUT Testing Quick Checkout (continued) To connect your inverter The inverter will come on to the power source: automatically. It should supply power to the load. If the 1. If the power source is a DC inverter does not appear to power supply, switch it off.

  • Page 4: Operation

    OPERATION The location where you should CAUTION use your unit must be: The inverter must only • dry–Do not use the unit be connected to batteries where water can drip or with a nominal output splash on it. voltage of 12 volts. •...

  • Page 5: Controls And Indicators

    CONTROLS & INDICATORS Powering Up Power/Fault Indicator To apply power to the CPI190, The “fault” indicator of your simply plug in to 12 Volt DC CPI190 will light whenever source (cigarette lighter). the unit detects excessively high or low input voltage, or begins to overheat.

  • Page 6: Power Output

    The inverter will also shut down if the input voltage Input Voltage increases to 15.5 ± 0.5 volts. Your CPI190 will operate from This helps protect the unit input voltage ranging from from damage due to excessive 10.4 to 14.4 volts. Optimum input voltage.

  • Page 7: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Problem/ Possible Solution Symptom Causes Low output voltage Overload Reduce the load. No output voltage Low input Recharge battery. voltage No output voltage Thermal Allow inverter to cool down when load is in shutdown Improve ventilation— excess of 130 watts make sure ventilation or 1.3 amperes openings in the inverter...

  • Page 8: Power Consumption

    POWER CONSUMPTION For each piece of equipment Calculate the total watt- you will be powering with hours of energy consumption your CPI190, you must (power X operating time), determine the battery’s then divide the watt-hours capacity (how long the by 10 to determine how may...

  • Page 9: Specifications

    SPECIFICATIONS Specifications Continuous output power 130w Surge rating (0.1second) 260w Peak efficiency (12V—1/2 load) Efficiency (full load, 12V) >78% No load current draw < 0.45 A (12.6 VDC) Output waveform (resistive load) Modified sine wave Output frequency 60Hz ± 2Hz Output voltage 115V +/- 10% USB output...

  • Page 10: Power Inverter

    Operating Instructions for Your Cobra 130 Watt ® POWER INVERTER 1 9 0 M O D E L C P I Nothing Comes Close to a Cobra Nothing Comes Close to a Cobra ® ®...
