- Page 1 CAR RADIO MANCHESTER 1 011 451 011 001 Enjoy it. Operating and installation instructions Mode d'emploi et de montage Instrucciones de manejo e instalación Instruções de serviço e de montagem Petunjuk Pengoperasian dan Pemasangan...
- Page 2 LOCATION OF BUTTONS 1. SRC source button. 14. 6 DIR+ (directory) button. Select memory bank or audio source 15. 5 DIR- (directory) button. 16. 4 RDM (random) button / MUTE” Power ON/OFF button. 3. TS (travel store) button. 17. 3 RPT (repeat) button. 4.
-
Page 3: Table Of Contents
CONTENTS Safety notes ........3 Symbols used ........3 Road safety ......... 3 General safety notes ......3 Declaration of conformity ....4 Cleaning notes ........5 Disposal notes ........5 Scope of delivery ......5 Optional equipment ......6 Placing the device in operation .. -
Page 4: Safety Notes
SAFETY NOTES SAFETY NOTES ROAD SAFETY Observe the following notes about road The car sound system was manufactured safety: according to the state of the art and • Use your device in such a way that established safety guidelines. Even so, you can always safely control your dangers may occur if you do not observe vehicle. -
Page 5: Declaration Of Conformity
For this purpose, observe the installation instructions at the end of this manual. DECLARATION OF CONFORMITY The Blaupunkt Technology GmbH declares that the car sound system complies with the basic requirements and the other relevant... -
Page 6: Cleaning Notes
1 Case for the control panel 1 Support frame 2 Disassembly tools 1 Remote control OPTIONAL EQUIPMENT (not part of the scope of delivery) only accessories approved Blaupunkt. Information is available from your Blaupunkt specialized dealer or on the Internet under www.blaupunkt.com. -
Page 7: Placing The Device In Operation
PLACING THE DEVICE IN OPERATION PLACING THE DEVICE IN • Removing the control panel Press the button to unlock the (24) OPERATION control panel. ATTENTION The left side of the control panel TRANSPORT SECURING SCREWS detaches from the device and is Before the startup of the car sound system, secured by the bracket against falling ensure that the transport securing screws... -
Page 8: Operation
OPERATION LOC ON/OFF: Rotate the audio knob (21) OPERATION to turn local function on/off. In LOC ON TURN THE UNIT ON/OFF mode, the unit reduces the receiving Turn on the unit by pressing the button. sensitivity when you search for stations. When the system is on, press and hold the That means, stations with strong signals button (2) for 2 seconds to turn off the... -
Page 9: Loudness
OPERATION LOUDNESS RADIO OPERATION Press and hold the EQ button for 2 seconds SWITCHING TO RADIO MODE to activate the LOUD function. Press and Press the SRC button (1) to select radio hold it again to cancel the function. mode, which appears in the display DISPLAYING INFORMATION together with the memory bank and frequency. -
Page 10: Automatic Storing
OPERATION AUTOMATIC STORING & PROGRAM (RADIO DATA SYSTEM) SCANNING OPERATION y Setting RDS mode - Automatic storing Press the TS button (3) for 2 seconds Press the AF button (22) to switch the the radio starts searchings from 87.5 AF function on or off. MHz frequency and checks the signal Whenever AF is on, the “AF”... - Page 11 (min. TA volume level), it will be set to • To ensure proper functioning, use only the last level. CDs with the Compact-Disc logo. • Blaupunkt cannot guarantee TA interruption function flawless function of copy-protected CDs The current traffic announcement is and all CD blanks, USB data carriers cancelled by pressing this key.
-
Page 12: Changing To Cd/Mp3/Wma Mode
OPERATION – MP3: 32 to 320 kbps SELECTING TRACKS/FILES – WMA: 64 to 192 kbps Press the button (11) or • Maximum number files button (6) to move to the previous or the directories: 20,000 entries next track/file. The track/file number is depending on the data structure shown on the display. -
Page 13: Selecting Files By Button
OPERATION z USB MP3 player is not a standard y SELECTING FILES WITH which means different models have BUTTON their own standard. Therefore, not is assigned as selection button (20) every MP3 player is supported. in MP3/WMA operation. z When connecting an MP3 player which has a regular battery (non rechargeable battery), you should remove the battery Search From Folder... -
Page 14: Remote Control Handset
REMOTE CONTROL HANDSET FUNCTION KEY & CONTROL Power ON/OFF Button. 2. VOL+: Volume up button. 3. BAND: To select FM1/FM2/FM3/ /MW1/MW2 band in RADIO mode. In RADIO mode: Press briefly for seek down function. Press and hold it for manual seek down. -
Page 15: Specification
GENERAL Power Supply Requirements : DC 12 Volt, Negative Ground Dimensions : 178 (W) x 160 (D) x 50 (H) Tone Controls - Bass (at 100 Hz) : ±10 dB - Treble (at 10 kHz) : ±10 dB Maximum Output Power : 4x50 watts Current Consumption : 10 Ampere (max.) - Page 16 Available as an optional accessory Supplied mounting hardware Disponible en option Materiel de montage fourni De venta como accesorios especiales Ferretería de montaje suministrada Disponíveis como acessórios opcionais Elementos de fi xação fornecidos Tersedia sebagai aksesori tambahan Komponen pemasangan dan penghubung yang disertakan 7607 621 …...
- Page 17 1-20 1 2 V 0° - 30° +/– 10° +/– 10°...
- Page 18 5. Removal • Démontage • Desmontaje • Desmontagem • Pelepasan 1 2 V...
- Page 19 Wiring connection • Schéma de raccordement • Esquema de conexiones • Esquema de ligações • Speaker out RR+ Speaker out RR– Speaker out RF+ Permanent +12V Speaker out RF– Auto antenna* Speaker out LF+ Speaker out LF– Tl.15/Ignition Speaker out LR+ Ground Speaker out LR–...
- Page 20 Relais 1 3 5 Telephone Mute 4 ohms 4 ohms 4 ohms 4 ohms Subject to changes! • Sous réserve de modifi cations ! • ¡Modificaciones reservadas! • Sob reserva dealterações! • Informasi dapat berubah sewaktu-waktu!
-
Page 21: Fcc Statement
FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 22 Blaupunkt Technology GmbH Robert-Bosch-Straße 200 D-31139 Hildesheim http://www.blaupunkt.com 5 101 510 001 06/14 gb, fr, es, pt, id...
