SERVICE
LED TV
UE**ES4****/UE**EH4****
UE**ES5****/UE**EH5****
LED TV
Chassis : U71A
Model
: UE32EH5****
UE37EH5****
UE40EH5****
UE46EH5****
UE26EH4****
UE32EH4****
Manual
U71B
UE22ES5****
UE19ES4****
Contents

Advertisement

   Summary of Contents for Samsung UE32EH5 SERIES

  • Page 1

    LED TV Chassis : U71A U71B Model : UE32EH5**** UE22ES5**** UE37EH5**** UE19ES4**** UE40EH5**** UE46EH5**** UE26EH4**** UE32EH4**** SERVICE Manual LED TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram UE**ES4****/UE**EH4**** UE**ES5****/UE**EH5****...

  • Page 2: Table Of Contents

    Contents 1. Precautions ........................1-1 1-1. Safety Precautions ......................1-1 1-2. Servicing Precautions ......................1-3 1-3. Static Electricity Precautions ....................1-4 1-4. Installation Precautions .......................1-5 2. Product Specifications....................2-1 2-1. Product Information ......................2-1 2-2. Detail Factory Option ......................2-26 2-3. Accessories ........................2-28 3. Disassembly and Reassembly ..................3-1 3-1.

  • Page 3

    This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2012 Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable All rights reserved. International and/or domestic law. Printed in Korea...

  • Page 4: Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.

  • Page 5

    1. Precautions 1-1-4. Product Safety Notices Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage, wattage, etc.

  • Page 6: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions An electrolytic capacitor installed with the wrong polarity might explode. WARNING Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. CAUTION If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 7: Static Electricity Precautions

    1. Precautions 1-3. Static Electricity Precautions Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your body by touching a known earth ground.

  • Page 8: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than a people are required for carrying the product. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 9: Product Specifications

    2. Product specifications 2. Product Specifications 2-1. Product Information 2-1-1. Model Comparison Model UE**EH5**** Front View * W : Width H : High D : Depth Detail View Front Color Black (Panel) Set with 738.3 x 498.1 x 191.6 mm / 29.1 x 19.6 x 7.5 inches Stand 32"...

  • Page 10

    2. Product specifications Set with 6.4 kg / 14.11 lbs Stand 32" Set without 5.7 kg / 12.57 lbs Stand Set with 9.9 kg / 21.83 lbs Stand 37" Set without 8.0 kg / 17.64 lbs Stand Weight Set with 11.0 kg / 24.25 lbs Stand 40"...

  • Page 11

    2. Product specifications Model UE**EH4**** Front View * W : Width H : High D : Depth Detail View Front Color Black (Panel) Set with 615.1 x 419.2 x 180.7 mm / 24.2 x 16.5 x 7.7 inches Stand 26" Set without 615.1 x 365.6 x 93.3 mm / 24.2 x 14.4 x 3.7 inches Stand...

  • Page 12

    2. Product specifications Model UE22ES5**** Front View * W : Width H : High D : Depth Detail View Front Color Black (Panel) Set with Stand 513.4 x 364.4 x 161.0 mm / 20.2 x 14.3 x 6.3 inches Dimensions 22"...

  • Page 13

    2. Product specifications Model UE19ES4**** Front View * W : Width H : High D : Depth Detail View Front Color Black (Panel) Set with 446.8 x 326.9 x 161.0 mm / 17.6 x 12.9 x 6.3 inches Stand Dimensions 19"...

  • Page 14

    2. Product specifications 2-1-2. Feature & Specifications Model UE32EH5**** Feature • Digital-TV, RF, 2-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 8 ms • CMR : 100 Specifications Item Description LCD Panel 32 inch FHD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic)

  • Page 15

    2. Product specifications Specifications Item Description Environmental Considerations Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 10 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 16

    2. Product specifications Model UE37EH5**** Feature • Digital-TV, RF, 2-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 8 ms • CMR : 100 Specifications Item Description LCD Panel 37 inch FHD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic) Display Colors...

  • Page 17

    2. Product specifications Specifications Item Description Environmental Considerations Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 10 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 18

    2. Product specifications Model UE40EH5**** Feature • Digital-TV, RF, 2-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 8 ms • CMR : 100 Specifications Item Description LCD Panel 40 inch FHD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic) Display Colors...

  • Page 19

    2. Product specifications Specifications Item Description Environmental Considerations Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 10 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 20

    2. Product specifications Model UE46EH5**** Feature • Digital-TV, RF, 2-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 8 ms • CMR : 100 Specifications Item Description LCD Panel 46 inch FHD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic) Display Colors...

  • Page 21

    2. Product specifications Specifications Item Description Environmental Considerations Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 10 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 22

    2. Product specifications Model UE26EH4**** Feature • Digital-TV, RF, 1-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 4 ms • CMR : 100 Specifications Item Description LCD Panel 26 inch HD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic) Display Colors...

  • Page 23

    2. Product specifications Specifications Item Description Environmental Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Considerations Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 5 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 24

    2. Product specifications Model UE32EH4**** Feature • Digital-TV, RF, 1-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 4 ms • CMR : 100 Specifications Item Description LCD Panel 32 inch HD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic) Display Colors...

  • Page 25

    2. Product specifications Specifications Item Description Environmental Considerations Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 10 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 26

    2. Product specifications Model UE22ES5**** Feature • Digital-TV, RF, 1-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 8 ms • CMR : 100 Specifications Item Description LCD Panel 22 inch FHD 60 Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic) Display Colors...

  • Page 27

    2. Product specifications Specifications Item Description Environmental Considerations Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 3 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 28

    2. Product specifications Model UE19ES4**** Feature • Digital-TV, RF, 1-HDMI, 1-Component, 1-A/V, 1-USB2.0 • High Contrast Ratio : MEGA • Response Time : 4 ms • CMR : 100 Specifications Item Description LCD Panel 19 inch HD 60 Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 47 Hz ~ 63 Hz (Automatic) Display Colors...

  • Page 29

    2. Product specifications Specifications Item Description Environmental Considerations Operating Temperature : 32˚F ~ 122˚F (0˚C ~ 50˚C) Operating Humidity : 20% ~ 90% Storage Temperature : -4˚F ~ 140˚F (-20˚C ~ 60˚C) Storage Humidity : 10% ~ 90% Audio Specifications MAX Internal Audio Output Power : Each 3 W(Left/Right) Equalizer : 5 Band Output Frequency :...

  • Page 30

    2. Product specifications 2-1-3. Specification Comparison to Old Models Model UE5L(UE**E*5****) UD5R(UE**D5500R*) Design Diplay Type LED TV LED TV Built-in Tuner Resolution 1920 x 1080 1920 x 1080 LCD Panel TFT LCD Panel 60 Hz TFT LCD Panel 60 Hz Screen Size 22"/32"/37"/40"/46"...

  • Page 31

    2. Product specifications Model UE5L(UE**E*5****) UD5R(UE**D5500R*) Wide Color Wide Color Enhance Plus Wide Color Enhance Plus Enhance Plus Equalizer 5 Band 5 Band Auto Volume Control Surround Dolby Digital Plus / Pulse Dolby Digital plus Sound 22" 3 W x 3 W 32"...

  • Page 32

    2. Product specifications Model UE4J(UE**E*4****) UD4N(UE32D4000NW) Design Diplay Type LED TV LED TV Built-in Tuner Resolution 1366 x 768 1366 x 768 LCD Panel TFT LCD Panel 60 Hz TFT LCD Panel 60 Hz Screen Size 19"/26"/32" 19"/32" Picture ratio 16 : 9 16 : 9 19"...

  • Page 33

    2. Product specifications Model UE4J(UE**E*4****) UD4N(UE32D4000NW) Caption Game Mode Energy Saving Network Anynet+ Antenna 1(Cable/Air) 1(Cable/Air) 2-25...

  • Page 34: Detail Factory Option

    2. Product specifications 2-2. Detail Factory Option NOTE If you replace the main board with new one, please change the factory option as well. The options you must change are "Type". 5000 „ Model Name UE32EH5**** UE37EH5**** UE40EH5**** UE46EH5**** CHILIN Vendor SHARP BN07-01096A...

  • Page 35

    2. Product specifications 4000 „ Model Name UE26EH4**** UE32EH4**** Vendor CHILIN CSOT BN95-00585A Panel Code BN07-01094A BN07-01112A BN07-01245A LTJ320AP03-V Spec. DE260AGM-C1 DE320BGA-B1 Vendor SMPS Code BN44-00491A BN44-00492A Spec. PD26AV0_CSM PD32AV0_CSM Byte Item Chassis Ass'y BN91-06356R BN91-06356E Factory Reset PBA Ass'y code BN94-05546R BN94-05546E 32A1AH0D...

  • Page 36: Accessories

    2. Product specifications 2-3. Accessories Product Description Code. No Remark Remote Control AA59-00602A Batteries (AAA x 2) 4301-000121 Samsung Electronics Power Cord 3903-000603 Service center BN68-03955A Owners Manual BN68-03951A 2-28...

  • Page 37: Disassembly And Reassembly

    3. Disassembly and Reassemble 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LED TV. This LED TV contains electrostatically sensitive devices. Use caution when handling these components. WARNING 3-1. Disassembly and Reassembly Disconnect the LED TV from the power source before disassembly.

  • Page 38

    3. Disassembly and Reassemble Description Picture Description Screws Remove 1 screw of Cover-Jack. 6003-001782 6003-002755 Remove 11 screws of Rear-Cover. Remove the Cover-Jack. Remove the Rear-Cover.

  • Page 39

    3. Disassembly and Reassemble Description Picture Description Screws Disconnect the Function Ass'y Cable. Remove the screws of Rear-Cover. • 32" / 37" : 12 EA 6003-001782 • 40" : 13 EA 6003-002755 (Machine) • 46" : 15 EA...

  • Page 40

    3. Disassembly and Reassemble Description Picture Description Screws Remove the Rear-Cover.

  • Page 41

    3. Disassembly and Reassemble Description Picture Description Screws Remove the 13 screws of Main Board and SMPS Board and Panel. 6001-002756...

  • Page 42

    3. Disassembly and Reassemble Description Picture Description Screws Remove the Speakers and Power Cables. Remove the LVDS Cable and Panel Drive Cable. Completed disassembly. NOTE Reassembly procedures are in the reverse order of disassembly procedures.

  • Page 43

    3. Disassembly and Reassemble 4000 „ Description Picture Description Screws Place TV face down on cushioned table. Remove 4 screws from the Stand. 6003-001782 Remove Stand. Remove 1 screw of Cover-Jack. 6003-001782 Remove the Cover-Jack. Disconnect the Function Ass'y Cable.

  • Page 44

    3. Disassembly and Reassemble Description Picture Description Screws Remove the screws of Rear-Cover. • 26" : 8 EA 6003-001782 • 32" : 12 EA 6003-002755 (Machine) Remove the Rear-Cover. Remove the screws of Main Board and SMPS Board and Panel. •...

  • Page 45

    3. Disassembly and Reassemble Description Picture Description Screws Remove the Speakers and Power Cables. Remove the LVDS Cable and Panel Drive Cable. Completed disassembly. NOTE Reassembly procedures are in the reverse order of disassembly procedures.

  • Page 46

    3. Disassembly and Reassemble UE19ES4000*_UE22ES5000* „ Description Picture Description Screws Place TV face down on cushioned table. Remove 3 screws from the Stand. Remove Stand. NOTE If you want to remove the only rear 6003-001782 cover, you don`t need to remove the stand) Remove 5 screws of Rear-Cover.

  • Page 47

    3. Disassembly and Reassemble Description Picture Description Screws Remove the screws of Main Board and SMPS Board. • Remove the 4 screws of Main Board. • Remove the 3 screws of SMPS Board. 6001-002756 NOTE (Machine) • If you need, Side Bracket also. •...

  • Page 48

    3. Disassembly and Reassemble Screw Size „ Code No. COLOR A (mm) B (mm) C (mm) Q'ty 5K - 32" : 13EA, 37" : 13EA, 40" : 14EA, 46" 6003-001782 BLACK 7.80~8.30 11.20~12.00 3.81~3.91 :18EA 4K - 26" : 11EA, 32" : 13EA 5K - 32"...

  • Page 49: Assy Board P-jog Switch & Ir

    3. Disassembly and Reassemble 3-2. Assy Board P-Jog Switch & Ir How to disassembly „ Description Picture Description Refer Check the 2 Locking Holders. Press both holders. Remove the Function Assy. 3-13...

  • Page 50

    3. Disassembly and Reassemble How to assembly „ Description Picture Description Refer Check the locking hole. Combine the function assy to locking hole. Press the function assy to TV. When you want to ignore the funtion key actions Option 0 : New Function (Naviagtion) Key Control Config Option Navigation Key Func...

  • Page 51: Disassembly(ptc)

    3. Disassembly and Reassemble 3-3. Disassembly(PTC) How to disassembly „ Description Picture Description Refer Place TV face up on cushioned table. Remove the ASSY Function assy. Spread the both sides of PTC upper (marked "▼") by use the tool. CAUTION Do not scratch on both side by use tool. Gate Cof will be damaged.

  • Page 52

    3. Disassembly and Reassemble Description Picture Description Refer Separate the left and right side of the PTC as shown. Separate the Bottom of the PTC as shown Raise up the PTC Bottom. Disassembly is complete. 3-16...

  • Page 53

    3. Disassembly and Reassemble How to reassembly „ Description Picture Description Refer Attach the PTC Bottom first to the Panel. Secure the plastic latch on the left and right side of the PTC as shown. 3-17...

  • Page 54

    3. Disassembly and Reassemble Description Picture Description Refer Visually inspect the spacing between the PTC and the Panel for equal clearance. CAUTION Combine to stick the PTC Rib into the middle mold. 3-18...

  • Page 55

    3. Disassembly and Reassemble Description Picture Description Refer Assembly is complete. 3-19...

  • Page 56: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1. Troubleshooting Previous Check „ Check the various cable connections first. Check to see if there is a burnt or damaged cable. Check to see if there is a disconnected or loose cable connection. Check to see if the cables are connected according to the connection diagram. Check the power input to the Main Board.

  • Page 57

    4. Troubleshooting How to know it is from Main Board or T-Con when some problems happen „ No Picture : Backlight is on, but there is no picture and LED indicator in front of TV is blinking. Check the LVDS Cable connection. If still problems, change the T-Con Board and then Main Board step by step. Picture distortion : Enter the service mode ⇢...

  • Page 58

    4. Troubleshooting Power-Tree „...

  • Page 59

    4. Troubleshooting Simple flow chart of malfunction „ Does the TV turn Can you see anything on the screen? Can you see OSD menu running on the screen? Can you see Digital Channel broadcast ? Check LVDS cable connected to Main Board. Check the Power Cord.

  • Page 60: How To Check Fault Symptom

    4. Troubleshooting 4-2. How to Check Fault Symptom NO Power and No Video „ • The LEDs on The front panel do not work when connecting The power cord. Symptom • The SMPS relay does not work when connecting The power cord. •...

  • Page 61

    4. Troubleshooting Change the LVDS cable ? Change the Panel. Caution Make sure to disconnect the power before working on the IP board.

  • Page 62

    4. Troubleshooting Location of Parts „ Main Board_Front HDMI1 HDMI2 Debug CN201 POWER CNT IC1101 DDR IC1201 Sub Micom IC1102 DDR USB1 Head Phone Optical IC1001 X9 Scaler IC901 Flash IC301 AUDIO AMP COMP/AV CN702 CN302 TUNER FUNCTION SPEAKER CN201 POWER CNT PIN 13 PIN 12 PIN 11...

  • Page 63: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : • If you do not have Factory remote control Power OFF Info MENU MUTE Power On • If you have Factory remote control INFO Factory...

  • Page 64: Factory Data

    4. Troubleshooting 4-3-2. Factory Data Note • Version of the software is written in 0002. • : I should not be possible to adjust or change that does not require a change item Black : Adjustment Services for the corresponding Blue : Items that are secured Option...

  • Page 65

    4. Troubleshooting Factory Menu Name Data Range Remark Spread Spectrum Spread Spectrum On/Off Period 40K/50K/60K Amplitude 0/0.5/1/1.5/2 DDR Spread Off/1%/2% Auto Power Mirror ON/ OFF HDMI EQ1 Middle Low/Middle/High/Strong HDMI EQ2 Middle Low/Middle/High/Strong use to solve HDMI Noise HDMI EQ3 Middle Low/Middle/High/Strong HDMI EQ4...

  • Page 66

    4. Troubleshooting Factory Menu Name Data Range Remark Hotel Option Shop Option Shop Mode ON/OFF USB DEMO ON(SEC) USB DEMO OFF(SEC) Exhibition Mode ON/OFF Sound Audio Amp NTP7412s NTP7412s/NTP7411s do not change Volume Curve NT/EU/EA do not change A2K Prescale 0~40 BTSC Mono Prescale 0~40...

  • Page 67

    4. Troubleshooting Factory Menu Name Data Range Remark Num of AV Num of PC Num of Comp Num of HDMI Num of SCART DVI Sound Number of HeadPhone Num of USB Port Num of SPDIF OUT LNA SUPPORT On/Off Navigation Key Func 0 : New function (Navigation jog) Key 1 : Old function (Touch) Key...

  • Page 68

    4. Troubleshooting Factory Menu Name Data Range Remark 2nd_Low 0~255 2nd_High 0~255 2nd_Delta 0~255 ADC Result 1st_AV_Gain 1st_AV_Offset 1st_Comp_Gain 1st_Comp_Gain_Cb 1st_Comp_Gain_cr 1st_Comp_Offset 1st_Comp_Offset_Cb 1st_Comp_Offset_Cr 1st_PC_R_Gain 1st_PC_G_Gain 1st_PC_B_Gatin 1st_PC_R_Offset 1st_PC_G_Offset 1st_PC_B_Offset 2nd_R_Offset 0~255 2nd_G_Offset 0~255 2nd_B_Offset 0~255 2nd_R_Gain 0~255 2nd_G_Gain 0~255 2nd_B_Gain 0~255 Sub Brightness...

  • Page 69

    4. Troubleshooting Advanced „ Factory Menu Name Data Range Remark WB Movie Mode On/Off Color Mode Movie Color Tone Cool Msub Brigh Msub Contr W1_RGAIN W1_BGAIN W1_ROFFS W1_BOFFS W2_RGAIN W2_BGAIN W2_ROFFS W2_BOFFS W3_RGAIN W3_BGAIN W3_ROFFS W3_BOFFS N_RGAIN N_BGAIN N_ROFFS N_BOFFS Movie Countr Movie Brigh Movie Color...

  • Page 70

    4. Troubleshooting Factory Menu Name Data Range Remark Std Tint 0~100 Std Backight 0~10 ADJUST Dynamic Dimming On/Off Power Key Protects On/Off UART Select Auto Wall Auto Wall/Debug/MDC/On1/ Debug Mode Debug Off Debug Off/Debug Smart/Debug RunTime Back End Mute PDP FRC VisualTEST Plus Disable Standby Mode Time...

  • Page 71

    4. Troubleshooting Factory Menu Name Data Range Remark 7.5 IRE NTSC ON/OFF 7.5 IRE OFFSET 0~60 YC_Delay PAL BG PAL DK PAL I SECAM BG SECAM DK SECAML NTSC 358 NTSC 443 AV PAL AV SECAM AV NT358 AV NT443 AV PAL60 EEPROM RESET EEPROM RESET...

  • Page 72: White Balance

    4. Troubleshooting 4-4. White Balance 4-4-1. Calibration Into the Factory Mode. Select Menu. Select ADC/WB menu. Select menu. Option Control Expert AV Calibration ADC/WB Comp Calibration Advanced PC Calibration HDMI Calibration 4-4-2. Service Adjustment You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration „...

  • Page 73

    4. Troubleshooting Method of Color Calibration (AV) „ Apply the NTSC Lattice (N0. 3) pattern signal to the AV IN 1 port. Press the Source key to switch to “AV1” mode. Enter Service mode. Select the “ADC” menu. Select the “AV Calibration” menu. In “AV Calibration Off”...

  • Page 74

    4. Troubleshooting 4-4-3. Adjustment Into the Factory Mode. Select Menu. ADC/WB Select menu. Select White Balance menu. Option Control (low light) (hight light) Expert Sub Bright Sub Contrast White Balance ADC/WB R offset R gain Advanced G offset G gain B offset B gain 4-19...

  • Page 75: White Ratio (balance) Adjustment

    4. Troubleshooting 4-5. White Ratio (Balance) Adjustment You can adjust the white ratio in factory mode (1:Calibration, 3:White-Balance). Since the adjustment value and the data value vary depending on the input source, you have to adjust these in CVBS, Component 1 and HDMI 1 modes. The optimal values for each mode are configured by default.

  • Page 76: Rs-232c

    4. Troubleshooting 4-6. RS-232C RS232C Control Port : COM#(Serial) Bit rate : 38400 Data Bit : 8 bit Parity : None Stop Bits : 1 Flow Control : None Description of RS232C Pin# Name Full Name Carrier Detect Received Data Transmitted Data Data Terminal Ready Signal Ground...

  • Page 77: Software Upgrade

    4. Troubleshooting 4-7. Software Upgrade Software Upgrade can be performed by downloading the. latest firmware from samsung.com to a USB memory device. • Current Version - The software already installed in the TV. Software is represented as ‘Year/Month/Day_Version’. 4-7-1. How to Check the Software Version Use the Main Menu „...

  • Page 78

    4-7-2. How to Upgade Software and Micom Insert a USB drive containing the firmware upgrade downloaded from samsung.com into the TV. Please be careful not to disconnect the power or remove the USB drive while upgrades are being applied. The TV will turn off and turn on automatically after completing the firmware upgrade.

  • Page 79: Cover-middle Rear Dimension

    4. Troubleshooting 4-8. Cover-Middle Rear Dimension UE32EH5**** „ 738.3 269.2 200.0 269.2 189.9 444.9 200.0 150.0 23.6 128.6 116.5 105.1 166.0 113.1 142.9 31.6 195.9 88.9 UE37EH5**** „ 866.5 164.0 223.0 333.25 200.0 333.25 200.0 519.2 150.0 23.2 155.2 146.2 158.5 166.0 259.2...

  • Page 80

    4. Troubleshooting UE40EH5**** „ 927.6 180.1 244.2 363.8 200.0 363.8 551.0 200.0 150.0 23.2 170.9 156.9 174.1 166.0 149.3 142.9 31.2 289.8 148.5 UE46EH5**** „ 1059.8 134.2 329.9 400.0 329.9 296.6 625.6 200.0 134.2 23.2 208.6 194.9 91.5 134.3 168.2 227.4 247.9 31.2...

  • Page 81

    4. Troubleshooting UE26EH4**** „ 738.8 96.6 257.6 100.0 257.6 100.0 365.6 169.0 34.7 81.3 57.3 14.6 UE32EH4**** „ 738.8 116.6 269.4 200.0 269.4 436.7 200.0 34.8 119.7 102.4 57.8 190.5 4-26...

  • Page 82

    4. Troubleshooting UE19ES4**** „ 445.8 28.7 185.4 75.0 185.4 75.0 273.3 173.8 28.5 66.6 124.2 58.5 UE22ES5**** „ 512.4 66.0 218.7 75.0 218.7 75.0 310.6 174.1 28.4 66.5 157.5 58.4 4-27...

  • Page 83: Wiring Diagram

    5. Wiring Diagram 5. Wiring Diagram 5-1. Wiring Diagram U71A_FHD „...

  • Page 84

    5. Wiring Diagram U71B_HD „...

  • Page 85: Connector

    5. Wiring Diagram 5-2. Connector CN1602_FHD (to Panel)_U71A CN302 (SPEAKER) EVEN[0]- ODD[4]+ CN503_FPC(DEBUG) ODD[4]- DEBUG_TX ODD[3]+ DEBUG_RX DEBUG_TX ODD[3]- DEBUG_TX FORMAT CN502(COMPONETN) SDA_Panel ODDCLK+ TCON_WP ODDCLK- COMP1_Y IDENT_AV SDA_Panel ODD[2]+ SCL_Panel ODD[2]- ODD[1]+ IDENT_COMP EVEN[4]+ ODD[1]- EVEN[4]- ODD[0]+ EVEN[3]+ ODD[0]- EVEN[3]- CN501 (HDMI1) HDMI1_RX2+...

  • Page 86

    5. Wiring Diagram CN1201 (USB1) CN1601_HD (to Panel)_U71B USB_VCC USB_DP PANEL_VCC ODD_CLK+ USB_DM PANEL_VCC ODD_CLK- PANEL_VCC CN1201 (USB1) PANEL_VCC ODD2+ SPDIF_OUT PANEL_VCC ODD2- CN301(MONITOR OUT) ODD1+ ODD1- SR_OUT WP_PANEL SL_OUT LVDS FORMAT ODD0+ ODD0- ODD3+ ODD3-...

  • Page 87: Connector Functions

    5. Wiring Diagram 5-3. Connector Functions U71A_FHD „ Connector Function CN201  IP CNM803 Supply main power and dimming signal from IP board to Main Board. CN1301_FHD  T-CON CNF1 The LVDS signal transfered from Main Board to Panel. U71B_HD „...

  • Page 88: Cables

    5. Wiring Diagram 5-4. Cables 5000 „ LEAD (Main-IP 14P) LVDS CALBE (Main - Panel 30P) 22" : BN39-01449T 22" : BN96-20370B 32" : BN39-01449C 32" : BN96-17116V Code No. 37" : BN39-01449B 37" : BN96-23839F 40" : BN39-01449Q 40" : BN96-17116W 46"...

  • Page 89

    Exploded Views and Parts List 1. Exploded View & Part List Exploded View Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 90

    ASSY PCB MAIN; UE40EH5020WXXH BN61-07946A HOLDER-SIDE, AV; UE4000,26/32/40,EO,HIPS, CB20 BN61-07952A BRACKET-WALL; UE5000 40",EGI-SECC PL,T1.2 BN96-24871A ASSY COVER P-MIDDLE REAR; UE40EH5000,,PC+ FC05 BN63-09202G COVER-JACK; 5000,40,ABS+PC,-,-,-,-,-,-,-, SB04A BN96-21736G ASSY STAND P-BASE; UE5300,40/46,EO,PC/ABS SG01A BN96-21742C ASSY GUIDE P-STAND; UE5000,40/46/55,W/W,P Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 91

    ASSY SHIELD;UE5L,E5000 6001-002756 SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 BN02-00102B TAPE FILAMENT;UE7000,#893,0.15,25,50,WHI EC13 BN39-01449Q LEAD CONNECTOR;UN32D5000FXZA,Falt Connec P001A BN44-00496A DC VSS-LED TV PD BD;PD40AVF_CSM,PSLF760C CB20 BN61-07952A BRACKET-WALL;UE5000 40",EGI-SECC PL,T1.2 FL06 BN96-17116W ASSY CABLE P-FFC;UN40EH5000,FFC,324mm,51 SP01A BN96-21669B ASSY SPEAKER P;6ohm,4pin,10W,Enclosure t Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 92

    BN60-00452A SPACER-TOP (LR);Full-LED 40'',FG200A,L52 ...4 BN60-00473B SPACER-BLOCK;F-LED 40'',MTU-R,889,BLK,T ...4 BN63-07229T COVER-SHEET;Y12 F-LED,SILICONE,T0.052,W ...4 AC157 BN64-01901B CHASSIS-TOP;Y12 F-LED 40",PC+ABS+G/F15%, BN96-23705A ASSY OPEN CELL;LK400D3HB7K,0.46125(H)X0..4 BN81-07744A A/S PART-SOURCE IC;DRIVER IC,VHIS6C277G2 ...4 BN81-07745A A/S PART-GATE IC;GATE IC,VHILH163Y02-1L, Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 93

    IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9 ...4 T0087 1203-006109 IC-POSI.FIXED REG.;S-1206B33-M3T1G,SOT-2 ...4 T0087 1203-006130 IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8 ...4 T0087 1203-006135 IC-POSI.FIXED REG.;AP1117D-33-GZ-13-89,T ...4 T0087 1203-006136 IC-POSI.FIXED REG.;AP1117D-18-GZ-13-89,T ...4 IC012 1203-006138 IC-POSI.ADJUST REG.;AP1117DGZ-13-89,TO-2 ...4 1203-006710 IC-DC/DC CONVERTER;RT8016L-GQW,WQFN,8P,1 ...4 1203-007080 IC-DC/DC CONVERTER;AOZ1051PI,SO-8,8P,4.9 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 94

    2007-002970 R-CHIP;56ohm,5%,1/16W,TP,1005 ...4 HDR8 2007-007095 R-CHIP;390ohm,5%,1/16W,TP,1005 ...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 ...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 ...4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 ...4 2007-007313 R-CHIP;6.8Kohm,1%,1/16W,TP,1005 ...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 ...4 2007-007352 R-CHIP;130Kohm,1%,1/10W,TP,1608 ...4 2007-007463 R-CHIP;1.1Kohm,1%,1/16W,TP,1005 ...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 ...4 MR11 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 95

    C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 ...4 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 ...4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 ...4 T0052 2703-002238 INDUCTOR-SMD;1uH,5%,2012,2.38Ohm,23,Wire ...4 T0052 2703-003149 INDUCTOR-SMD;2.2uH,20%,5050,0.055Ohm,300 ...4 2703-003343 INDUCTOR-SMD;2.2uH,20%,2520,0.104Ohm,130 ...4 2703-003930 INDUCTOR-SMD;4.7uH,20%,5050,0.072Ohm,245 ...4 X202 2801-003326 CRYSTAL-SMD;24MHz,30ppm,28-ABX,20pF,50oh ...4 X202 2801-003948 CRYSTAL-SMD;12MHz,30ppm,28-AAN,12pF,60oh Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 96

    BAND PP;PP,T0.8,W18,L1650M,TRP,DA69-9014 BN68-02422B LABEL-WARNING SHIPPING;ALL MODEL,A/P 100 BN69-00257X PACKING-SHEET PALLET;PACKING SHEET PALLE BN69-03982M PAD PACKING-EDGE;EDGE,PAPER,-,T5,W120,L2 BN69-05418A PACKING-BAG WRAPPING;-,LDPE,-,0,019,500, BN69-06640A PACKING-PAD;PAD,PAPER,-,-,CB-SW4,1120,95 BN69-06680A PACKING-BAG SHEET ROLL;-,CB,-,FOAM 0,5mm BN69-07019A CUSHION-SET;UE5000 40",EPS,square stand BN69-07609A PALLET;UE40EH5000,WOOD,-,1140,1100,135,- BN74-00008D TAPE-OPP MASKING;OPP,T0.05,W75,L800M,CLR Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 97

    4301-000121 BATTERY-MN;1.5V,R03,10.5x44.5m,HOLDER,7. 6902-001340 BAG PE;LDPE,T0.05,W250,L350,TRP,RECYCLE REMO2 AA59-00602A REMOCON;TM1240,44,3V,Europe,E6000 BN61-05491A HOLDER-WIRE STAND;UB7000 46inch,NYRON ACCE4 BN96-24943Y ASSY ACCESSORY-MANUAL;UE32EH5020WXXH,40 6902-000476 BAG PE;LDPE,T0.03,W250,L350,TRP,Recycle, T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, BN68-03019A LEAFLET-02,SAFETY GUIDE;ALL,SAMSUNG,28LE BN68-03548J LEAFLET-02,WARRANTY CARD;comm,Samsung,17 BN68-04524A LEAFLET-5400_50"65";ALL,SAMSUNG,ENG,EURO BN68-04696A MANUAL USERS;UEH5020,SAMSUNG,ENG/POL/SLV Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 98

    Exploded Views and Parts List 1. Exploded View & Part List Exploded View Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 99

    ASSY PCB MAIN; UE40EH5020WXXH BN61-07946A HOLDER-SIDE, AV; UE4000,26/32/40,EO,HIPS, CB20 BN61-07952A BRACKET-WALL; UE5000 40",EGI-SECC PL,T1.2 BN96-24871A ASSY COVER P-MIDDLE REAR; UE40EH5000,,PC+ FC05 BN63-09202G COVER-JACK; 5000,40,ABS+PC,-,-,-,-,-,-,-, SB04A BN96-21736G ASSY STAND P-BASE; UE5300,40/46,EO,PC/ABS SG01A BN96-21742C ASSY GUIDE P-STAND; UE5000,40/46/55,W/W,P Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 100

    ASSY SHIELD;UE5L,E5000 6001-002756 SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 BN02-00102B TAPE FILAMENT;UE7000,#893,0.15,25,50,WHI EC13 BN39-01449Q LEAD CONNECTOR;UN32D5000FXZA,Falt Connec P001A BN44-00496A DC VSS-LED TV PD BD;PD40AVF_CSM,PSLF760C CB20 BN61-07952A BRACKET-WALL;UE5000 40",EGI-SECC PL,T1.2 FL06 BN96-17116W ASSY CABLE P-FFC;UN40EH5000,FFC,324mm,51 SP01A BN96-21669B ASSY SPEAKER P;6ohm,4pin,10W,Enclosure t Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 101

    0202-001477 SOLDER-CREAM;LST309-M,D20~45um,96.5Sn/3A ..5 D0254 0404-001314 DIODE-SCHOTTKY;B260A,60V,2000mA,SMA,TP ..5 D0254 0404-001373 DIODE-SCHOTTKY;PD3S160,60V,1000mA,PowerD ..5 T0139 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 ..5 0406-001317 DIODE-TVS;SMAJ14A,15.6/-/17.2V,400W,SMA ..5 0406-001445 DIODE-TVS;RClamp7512N,2.7/2.8/2.9,300W,S ..5 Q613 0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350mW,SOT-2 ..5 0502-001331 TR-POWER;NSS30100LT1G,PNP,310mW,SOT-23,T ..5 0502-001345 TR-POWER;FCX491A,NPN,1000mW,SOT89,TR,900 ..5 0502-001346 TR-POWER;FCX591A,PNP,1000mW,SOT89,TR,30/ Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 102

    2007-002768 R-CHIP;6.2Kohm,1%,1/10W,TP,1608 ..5 2007-002900 R-CHIP;11Kohm,1%,1/10W,TP,1608 ..5 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 ..5 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 ..5 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 ..5 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,0.35 ..5 2007-007310 R-CHIP;8.2Kohm,1%,1/16W,TP,1005 ..5 2007-007645 R-CHIP;51.1ohm,1%,1/10W,TP,1608 ..5 V8642 2007-007768 R-CHIP;13Kohm,1%,1/10W,TP,1608 ..5 2007-007798 R-CHIP;10ohm,1%,1/16W,TP,1005 ..5 S0F1352 2007-008596 R-CHIP;0.1ohm,1%,1/4W,TP,3216 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 103

    ASSY MICOM;J400HM050K,24C128,2012.01.30, ..6 1103-001321 IC-EEPROM;24WC128,128Kbit,16Kx8,SOP,8P,5 ..5 BN97-06450A ASSY MICOM;LSJ400HM05,400HM05,2011.10.10 ..6 1103-001254 IC-EEPROM;24C02,2Kbit,256x8,TSSOP,8P,4.4 BN96-21517A ASSY OPEN CELL;LSJ400HM05-E,8bit,40 INCH ...4 BN81-07433A A/S-ADHESIVE-A.C.F(CF);ADHESIVE-A.C.F,1- ...4 BN81-07435A A/S-ADHESIVE-A.C.F;ADHESIVE-A.C.F,2-ADHE ...4 BN81-07440A A/S-ASSY PCB-SOURCE LEFT;ASSY PCB-SOURCE ...4 BN81-07453A A/S-ASSY PCB-SOURCE RIGHT;ASSY PCB-SOURC Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 104

    IC-CMOS LOGIC;74LCX245,TRANSCEIVER,DQFN, ...4 IC112 1103-001310 IC-EEPROM;2Kbit,256x8,SOIC,8Z30,5x4mm,2..4 1103-001531 IC-EEPROM;S-24C256CI-J8T1U4,256Kbit,32Kx ...4 1105-002194 IC-DDR3 SDRAM;K4B1G1646G-BCH9,DDR3 SDRAM ...4 1201-003183 IC-AUDIO AMP;DRV612,HTSSOP,14P,5x4.4mm,D ...4 1201-003333 IC-POWER AMP;NTP-7412S,MLF,48P,7x7mm,DUA ...4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, ...4 1203-006017 IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9 ...4 T0087 1203-006109 IC-POSI.FIXED REG.;S-1206B33-M3T1G,SOT-2 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 105

    ...4 DR43 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 ...4 2007-001301 R-CHIP;68ohm,5%,1/16W,TP,1005 ...4 2007-001313 R-CHIP;330ohm,5%,1/16W,TP,1005 ...4 R326 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 ...4 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 ...4 PR24 2007-002970 R-CHIP;56ohm,5%,1/16W,TP,1005 ...4 HDR8 2007-007095 R-CHIP;390ohm,5%,1/16W,TP,1005 ...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 ...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 ...4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 106

    ...4 VC37 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 ...4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,TP,1005 ...4 JC10 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,TP,1608 ...4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ...4 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,2012 ...4 HDC11 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 ...4 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 ...4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 ...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 107

    KEY CODE-CERTIFI;CI+,TV,2012X,Euro T0066 BP62-00017A HEAT SINK-ES;SP-50L2HX,A6063S,T2.0,26.2, BN92-08038G ASSY LABEL;UE5L,E5000 T0527 BP68-00052B LABEL-00,RATING;FPTV,PET,T0.05,93,73 BN92-10016A ASSY P/MATERIAL;UEH5000,40 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 M040 6922-000003 BAND PP;PP,T0.8,W18,L1650M,TRP,DA69-9014 BN68-02422B LABEL-WARNING SHIPPING;ALL MODEL,A/P 100 BN69-00257X PACKING-SHEET PALLET;PACKING SHEET PALLE BN69-03982M PAD PACKING-EDGE;EDGE,PAPER,-,T5,W120,L2 Copyright© 1995-2012 SAMSUNG. All rights reserved.

  • Page 108

    4301-000121 BATTERY-MN;1.5V,R03,10.5x44.5m,HOLDER,7. 6902-001340 BAG PE;LDPE,T0.05,W250,L350,TRP,RECYCLE REMO2 AA59-00602A REMOCON;TM1240,44,3V,Europe,E6000 BN61-05491A HOLDER-WIRE STAND;UB7000 46inch,NYRON ACCE4 BN96-24943Y ASSY ACCESSORY-MANUAL;UE32EH5020WXXH,40 6902-000476 BAG PE;LDPE,T0.03,W250,L350,TRP,Recycle, T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, BN68-03019A LEAFLET-02,SAFETY GUIDE;ALL,SAMSUNG,28LE BN68-03548J LEAFLET-02,WARRANTY CARD;comm,Samsung,17 BN68-04524A LEAFLET-5400_50"65";ALL,SAMSUNG,ENG,EURO BN68-04696A MANUAL USERS;UEH5020,SAMSUNG,ENG/POL/SLV Copyright© 1995-2012 SAMSUNG. All rights reserved.
