- Page 1 Model type: AWD121NA Commercial code: 35356...
-
Page 2: General Notes
6. Some notices, into a same section are generic therefore cannot be directly linked to a spare part. In order to assist a model in the best way as possible, it is helpful to pay attention to all notices and constantly verify documentation updates 7.Technical documentation cover shows model name and its commercial codes mod.AWD121NA page 2... - Page 3 1140110A Exploded views mod.AWD121NA page 3...
-
Page 4: Spare Parts
80353560900 C00064507 pushbutton white n1040359 80353560000 C00116625 pushbutton white 0/i 80353560900 C00116105 control panel + handle awd121na 80353560000 C00116805 control panel + handle pw 80353560900 C00082825 1 x C00116624 door frame assy C00065250 1 x C00116580... - Page 5 Code From To S/N Substitute Description Notice Industrial C00084817 blanking plate-rear(test plug) C00112436 1 x C00116618 top white + plate ariston n1040359 80353560000 C00116618 worktop - white pw aw121na 80353560900 C00046667 wiring stop C00064550 drain hose holder C00091904 cable clamp hose...
-
Page 6: Exploded Views
1180240 Exploded views mod.AWD121NA page 6... - Page 7 120 n 8,15 mm C00064789 wash paddles (extractable) 46 l C00094281 1 x C00094275 outer- set 46 l. evo ii n1040300 1 x C00094280 n1040371 C00093750 bolt zink m8x40 C00092273 hose dispenser to tank C00096077 bearing spider assembly n1040300 mod.AWD121NA page 7...
-
Page 8: Spare Parts List
Spare parts list Ref. Code From To S/N Substitute Description Notice Industrial C00074211 drum pulley d=210 mm h=20 mm C00074218 belt l=1046 - 1051 mm h8 (hl) C00001109 loctite 270 10 gr. C00033026 ambljgon grease ta 100 gr. mod.AWD121NA page 8... - Page 9 1180320A Exploded views mod.AWD121NA page 9...
- Page 10 C00145001 1 x C00196554 brush motor ceset eame 6170 C00110422 hole for heating element C00091054 coil to protect module 2002 C00116123 eeprom evoi awd121na sw C00109898 module (less eeprom) wd usa mdl C00066292 insulated tweezers C00095669 hardware key mk1 n1040317...
- Page 11 C00005781 inlet hose filter C00112930 inlet hose with usa C00066514 electrovalve support 2 ev C00116106 wiring awd121na C00092348 self-scraping screw 3,5x8 C00099625 reading desk awd120na pr47 C00065733 support - programme guide tbc C00058523 pillar retainer-heating element...
- Page 12 1180410 Exploded views mod.AWD121NA page 12...
- Page 13 (dry loc) C00032972 blower fixing nut C00080658 blower fan for motor (087920- C00054790 screw trilob m5 x 16 tcb t.e. st C00087919 blower manifold kit C00110434 dryer fan motor 115v.60hz C00114390 fixing screw for blower manifold mod.AWD121NA page 13...
- Page 14 · loads the wash electrovalve and pre-wash electrovalve at the same time until the pressure switch is on full · heats up to 30° and moves the motor in both directions · selector moves on for 9 notches · drains and spins · the selector knob stops on one of the reset positions · STOP mod.AWD121NA page 14...
- Page 15 F06: Selector Error (a part no. cannot be found) Overhaul CND (selector connector) Overhaul Selector Connector Control Selector/CND Continuity Control Selector Motor Replace Selector Replace Card F07: Resistance Relay Stuck Overhaul CN1 Overhaul CN1 Overhaul Resistance Connection Replace Card mod.AWD121NA page 15...
- Page 16 4. Replace the board.Merloni Elettrodomestici F15: Dryer connector is always active 1. Check the efficiency of the terminals on the CNI connector board 2. Overhaul connector connection 3. Overhaul the pressure sensor connection 4. Replace the connector mod.AWD121NA page 16...
- Page 17 5. Replace card N.B.From Fault F01 to fault F11 These are shown by LEDs in stand by/on in LVB2000 machines Ariston/Indesit. From fault F01 to fault F12 These are shown in a display located on the instrument panel of LVB2000 ma-chines Evolution Indesit.
- Page 18 ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- From serial no. 50207.0001, all Ariston models produced in the Teverola factory (see table 001 attached) with industrial code (given on the rating plate) starting with 46, have been equipped with a Zamac hinge with 150° opening angle, code C00115666 (see Fig.001).
- Page 19 Models “Evizzati “ Serial number > 30312.0001 and < 30616.0001 SAT code 094279 TUB 46L.B5 CV5 EVO II 1200 rpm; SAT code 094281 TUB 46 L. B5-CV5 LD EVO II 1200 rpm LD; SAT code 094287 Tub 40 litres b5-cv5 40 litres 1200-1400 rpm;. mod.AWD121NA page 19...
- Page 20 2) Position the balancing springs inside the support holes found further back than the previous position on the cabinet (see fig.001); 3) Affix the shock absorbers on the support holes positioned on the back part of the cabinet (see fig.002). mod.AWD121NA page 20...
- Page 21 Electric schemes and links Cod. 16001592200 mod.AWD121NA page 21...
- Page 22 Legend Legend: 16001592200 mod.AWD121NA page 22...
- Page 23 Electric schemes and links Cod. 16001813303 mod.AWD121NA page 23...
- Page 24 Legend Legend: 16001813303 mod.AWD121NA page 24...
