Brocade 8Gb SAN Switch for HPE BladeSystem c-Class
The Brocade 8Gb SAN Switch for HPE BladeSystem c-Class delivers an easy to manage embedded Fibre Channel switch with 8
Gbps performance. The Brocade 8Gb SAN Switch hot-plugs into the back of the HPE BladeSystem c-Class Enclosure. The
integrated design frees up rack space, enables shared power and cooling, and reduces cabling and small form-factor pluggables.
Enhanced trunking support with external switches provides higher bandwidth to enable demanding applications such as server
virtualization. New features in the Power Pack+ option enable you to manage data flow to maintain optimized application
performance. The 12 or 24 auto-sensing ports support lower bandwidth components for investment protection and an upgrade
license enables you to 'pay as you grow'. The Brocade 8Gb SAN Switch saves space and cost, significantly simplifies the SAN
environment, enables easier deployment and management, and delivers the performance required for emerging higher throughput
applications.
Integrated SAN
connectivity
8 Gbps storage
networking
Non-blocking
architecture
ISL Trunking
performance
enhancements
Adaptive Networking
Services
Brocade 8Gb SAN Switch
Enables data center consolidation with HPE BladeSystem c-Class through a state-of-the-art
zero-footprint design while lowering cost through shared power and cooling, fewer cables and
SFPs, and a reduction in space.
Enables support of virtualized environments and other emerging technologies through high-
speed technology that doubles the performance of the storage network. Both internal and
external facing ports auto-sense lower bandwidth components for flexibility and investment
protection (2, 4, or 8 Gb).
Includes connection speed support for all ports to provide a high-performance system with
aggregate bandwidth of up to 192 Gbps (24 ports x 8 Gbps at full duplex).
Now providing support for up to a single trunk made up of all eight SAN ports for a total of up
to 64 Gbps balanced throughput. Trunking of the SAN-facing ports with external Brocade or
HPE B-series switches provides a high-bandwidth solution while lowering costs through fewer
SFPs and cables. F-Port Trunking supported in Access Gateway mode.
Enables organizations to better manage data flows and meet service level agreements while
maintaining optimized application performance in virtual environments with new Adaptive
Brocade 8Gb SAN Switch for HPE BladeSystem c-Class
Page 1

Advertising

   Also See for HP Brocade 8Gb SAN

   Related Manuals for HP Brocade 8Gb SAN

   Summary of Contents for HP Brocade 8Gb SAN

  • Page 1

    The 12 or 24 auto-sensing ports support lower bandwidth components for investment protection and an upgrade license enables you to 'pay as you grow'. The Brocade 8Gb SAN Switch saves space and cost, significantly simplifies the SAN environment, enables easier deployment and management, and delivers the performance required for emerging higher throughput applications.

  • Page 2

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Overview Networking services, including Adaptive Fabric Quality of Service, Traffic Isolation, and Ingress Rate Limiting. Access Gateway mode • Employs N_Port ID Virtualization (NPIV), an ANSI T11 standard, to enable interoperability with other SAN fabrics and eliminate domain considerations while improving SAN scalability.

  • Page 3: Product Highlights

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Product Highlights Advanced Fabric • Hardware Enforced Zoning (included)* Services • Dynamic Path Selection (included)* • WebTools (included) • Enhanced Group Management (EGM) • Power Pack+ fabric services software bundle (optional)

  • Page 4

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Product Highlights enforcement enables the highest level of zoning enforcement without any impact to performance. Administrators can organize a physical fabric into logical groups and prevent unauthorized access by devices outside the Zone.

  • Page 5

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Product Highlights Power Pack+ Software The Power Pack+ Software Bundle includes: Bundle • Fabric Vision • Fabric Watch** • Advanced Performance Monitoring** • Extended Fabrics* • ISL Trunking * Not supported in Access Gateway mode **Partial support in Access Gateway mode (See the Access Gateway Administrator´s guide for full...

  • Page 6

    BladeSystem compatibility The Brocade 8Gb SAN Switch for HPE BladeSystem c-Class must be deployed within the HPE BladeSystem c-Class infrastructure and is compatible only with HPE BladeSystem c-Class Enclosures. HPE ProLiant Servers...

  • Page 7: Switch Interoperability

    10/24 Blade for DC SAN Directors • 1606 Extension SAN Switch • 2408 FCoE Converged Network Switch • • SN4000B * Supported in the same fabric with Brocade 8Gb SAN Switch for HPE BladeSystem c-Class, but not directly connected. Page 7...

  • Page 8

    IT and business. Connect your devices: Unlock all of the benefits of your technology investment by connecting your products to HP Enterprise. Achieve up to 77% reduction in down time, near 100% diagnostic accuracy and a single consolidated view of your environment.

  • Page 9

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Warranty, Service and Support Information Standard Care HPE Proactive Care with 24x7 coverage, three year Support Service HPE Proactive Care gives customers an enhanced call experience plus helps preventing problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice when your products are connected to HPE.

  • Page 10: Configuration Information

    AJ716B HP 8Gb Long Wave B-series 10km Fibre Channel 1 Pack SFP+ Transceiver AJ717A HP B-series 8Gb Extended Long Wave 25km Fibre Channel SFP+ Transceiver 1 Pack AW538A 4 Gb Optical HP 4Gb Short Wave B-series Fibre Channel 1 Pack SFP Transceiver...

  • Page 11

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Configuration Information * AJ716A is End of Life (EO)L, and is replaced by AJ716B because of RoHS compliance; however, the SKU is still orderable until supplies are diminished. Software: Power Pack+ Software...

  • Page 12

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Configuration Information software from HPE's Product Download web site. Page 12...

  • Page 13

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Family Comparison Features 8/8 SAN Switch 8/24 SAN Switch SN3000B 16Gb FC SN6000B 16Gb FC Base and 8/8 SAN Base Switch and Switch and Switch SN3000B 16Gb FC SN6000B 16Gb FC...

  • Page 14

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Family Comparison 16 Max Ethernet Ports 2 or 6 Enabled 6 Max B-series Advanced Included with Power Pack+ or Optional Upgrade Trunking Adaptive Included Networking Form factor Zoning Software Yes (Included)

  • Page 15

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Family Comparison or 10 Gbit/sec Aggregate device 448 Gbit/sec 192 Gbit/sec full duplex full duplex bandwidth OS Support NOTE: Please Refer to SAN Design Guide http://www.hp.com/go/sandesign or http://www.hp.com/go/sandesignguide Storage system MSA3PAR StoreServ, StoreVirtual 4000, P9000/XP, P6000/EVA, P2000/MSA...

  • Page 16: Technical Specifications

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Technical Specifications Fibre Channel ports Brocade 8/12c SAN Switch model: 12 - 8 Gb ports in any internal/external port combination (ships with two 8 Gb short wave SFP+s) Brocade 8/24c SAN Switch models:...

  • Page 17

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Technical Specifications maximum wet bulb temperature, non- condensing. Non-operating 5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non- condensing. Altitude Operating 3050 m (10,000 ft). This value may be limited by the type and number of options installed.

  • Page 18

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Technical Specifications FC-BB-2 INCITS 372: 2003 • FC-SB-3 INCITS 374: 2003 (replaces FC-SB ANSI X3.271: 1996; FC-SB-2 INCITS 374: 2001) • RFC 2625 IP and ARP Over FC • RFC 2837 Fabric Element MIB •...

  • Page 19

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Summary of Changes Date Version History Action Description of Change: 31-Mar-2016 From Version 24 to 25 Changed Changed made to the Overview, Sevice and Support and Family Comparison Sections. Descriptions Updated.

  • Page 20

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Summary of Changes 27-Sep-2010 From Version 6 to 7 Added PremierFlex OM3+ type cables were added to Step 2. 18-Jun-2010 From Version 5 to 6 Changed Updated the following sections: Advanced Fabric Services;...

  • Page 21

    QuickSpecs Brocade 8Gb SAN Switch for HPE BladeSystem c-Class Summary of Changes Sign up for updates Rate this document © Copyright 2016 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services.
