SmartNode 4400 Quick Start Guide
Connecting a PC, logging in, and configuring the LAN IP address
Connecting power and configuring the default IP address
Connect the SmartNode to the mains power supply using the included power supply and cable. When the
RUN LED stops blinking and remains lit, the SmartNode is ready.
The factory default IP settings are listed in
be changed. Contact your network administrator if you are not sure which IP address to use in
your installation.
Table 1. Factory default IP address and network mask configuration
WAN interface Ethernet 0 (ETH 0/0)
LAN interface Ethernet 1 (ETH 0/1)
DHCP server address range
Note
Connecting to a PC and logging in
1. To access the SmartNode configuration, connect a PC equipped with an RS-232 console port to the Con-
sole port on the front of the SmartNode. Use the included black Ethernet cable and RJ45 to DB-9 adapter
for this purpose (Model 16F-561).
2. Open a Terminal connection to the SmartNode. Use the Terminal program included with most PC operat-
ing systems (e.g. Hyper Terminal on Windows).
Connecting a PC, logging in, and configuring the LAN IP address
table 1. If these addresses do not work with your network they must
Item
The DHCP server is running on the ETH 0/1 of the SN4400 Series
models. All Ethernet ports are pre-configured and active.
Figure 2. Connecting to the PC
IP Addresss(es)
DHCP
192.168.1.1
192.168.1.10-192.168.1.19
rt s
P o
lc o
T e
5 0
o le
n s
C o
t
s e
R e
Console port
0 /0
E T H
0 /1
E T H
Model 16F-561
adapter and cable
Network Mask
DHCP
255.255.255.0
255.255.255.0
4 0 V
z )
0 -2
0 H
1 0
0 -6 M P
(5 1 A
Laptop PC
