2.12. Adding fuel.
Unscrew the fuel tank cap and carefully add a 2-stroke fuel/oil mixture as in section 2.10. DO
NOT overfill and allow a 25 mm gap at the top of the tank. Once full replace and correctly
tighten the fuel cap. Fuel tank capacity is 1200ml.
DO NOT use straight unleaded petrol.
2.13. Fitting replacing spool line.
Squeeze the bump head unit either side on the grooves and pull to remove the top of the
head. Remove the spool, spring and washer from the spindle.
