7
MENU MODE

SETTINGS group

■ FUNCTIONS

D CH SPACING

(May not be displayed, depending on the
transceiver's presettings.)
Select "8.33 kHz," "25 kHz," or "8.33 kHz/25 kHz"
channel spacing.
CAUTION: In Canada, use of 8.33 kHz Channel
Spacing of this radio is strictly prohibited and shall
not be used.

D PRIORITY CH

(May not be displayed, depending on the
transceiver's presettings.)
Select the Priority channel from the Memory channels
stored in the transceiver (p. 5-2).
• The channel set as the Priority channel is displayed.
• "OFF" is displayed if no channel is set as the Priority
channel.

D NOISE LIMITING

Set the noise limiting function for receiving and
transmitting.
 RX
• OFF: The Noise Limiting function is OFF.
• ANL: The Automatic Noise Limiter (ANL) is ON.
• LOW: Reduces the received signal noise level to 1/2
of normal.
• MID: Reduces the received signal noise level to 1/3
of normal.
• HIGH: Reduces the received signal noise level to
1/10 of normal.
 TX
• OFF: The Noise Limiting function is OFF.
• ON: The Noise Limiting function is ON.

D TIME OUT TIMER

(May not be displayed, depending on the
transceiver's presettings.)
The Time-out Timer (TOT) limits continuous
transmissions on the channel, to prevent occupying
the channel for a long time.
• OFF* 1 :
• 30 sec to 180 sec: Sets the Time-out Timer to
* 1 Except IC-A120E (AUS version).

D MIC KEY CUSTOMIZE

(May not be displayed, depending on the
transceiver's presettings.)
You can customize the key assignment for the
optional HM-217
speaker micrOphOne
 [P1]/[P2]
• VFO/MR MODE*
• PRIORITY CH:
• DUALWATCH:
• SCAN START/PAUSE: Push to start a scan. Push
• SQL
• VOL
• LOCK
• ---
* 2 For only USA, EXP and EUR versions.
 [UP]/[DOWN]
• UP/DOWN:
• VOL UP/DOWN:
• SQL UP/DOWN:
• ---

D LOCK FUNCTION

Select an option for the Key Lock function.
• All:
• Microphone Key:
• Panel Key:
7-5
The Time-out Timer is disabled.
between 30 seconds and 180
seconds.
(p. 9-3).
2 : Push to change the
operating mode.
Push to select the Priority
channel.
Push to check the Priority
channel while receiving
another channel.
again to pause the scan
Push to adjust the squelch.
(p. 2-3)
Push to adjust the volume.
Push to turn the Key Lock
function ON or OFF.
No function is assigned.
Push to select the channel.
Push to adjust the volume
level.
Push to adjust the squelch
level.
No function is assigned.
Locks all keys.
Locks the keys on the
microphone.
Locks the keys on the
transceiver.
