C o n t r o l t h e E l e me n t s
Ow n e r ' s Ma n u a l
F i n e F u r n i t u r e f o r F i n e Wi n e s

Advertisement

loading
Need help?

Need help?

Do you have a question about the cellarpro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LE CACHE cellarpro

Summary of Contents for LE CACHE cellarpro

  • Page 1 C o n t r o l t h e E l e me n t s Ow n e r ’ s Ma n u a l F i n e F u r n i t u r e f o r F i n e Wi n e s...
  • Page 2 Website: www.CellarProCoolingSystems.com Serial Number*: ____________________ *We recommend that you take a minute to fill-in your CellarPro serial number above. The serial number has seven-digits and can be found on the printed label on the left side of your cooling unit.
  • Page 3 [This page left blank]...

  • Page 4: Table Of Contents

    T a b l e o f C o n t e n t s Prior to Installation Overview III. Installation Instructions – Wine Cellars IV. Replacement Instructions – Wine Cabinets Operating Instructions VI. Troubleshooting VII. Limited Warranty...

  • Page 5: Prior To Installation

    I . P r i o r t o I n s t a l l a t i o n  Wait 24 hours before operating your CellarPro cooling unit.  Test the unit before installing it. 1. Remove the unit from the box. SAVE THE BOX AND PACKING MATERIALS.

  • Page 6: Overview

    To figure out whether a CellarPro unit will work in your space, make sure that the cooling unit’s BTUH for a given cellar temperature (at the top of the table) is equal or greater than the thermal load shown in the body of the table.
  • Page 7 45°F and 95°F. Except for the 1800XTSX cooling unit, they are designed for internal use only, and are not designed for exposure to the exterior. CellarPro cooling units do not have heating elements, so if temperatures inside the or outside the cellar drop below proper wine storage temperatures, the cooling unit cannot create heat inside the cellar.
  • Page 8 cellar. Please note: The R-values above are the MINIMUM recommended amounts of insulation. It is advisable to use as much insulation as possible inside your walls, ceiling and floor. It is critical that all walls, joints, doors and windows, electrical outlets and/or switches, pipes, vents and light fixtures be sealed to prevent air and moisture from entering the cellar.

  • Page 9: Installation Instructions - Wine Cellars

    CellarPro cooling units must always be mounted in the upright position and located as close to the ceiling as possible inside the cellar. As warm air rises to the top of the cellar, the cooling unit pulls the warm air through the evaporator coils and removes the heat from the warm air.
  • Page 10 Alternatively, the front of the cooling unit can be supported by a shelf and a diagonal brace. The shelf can be up to 13.25” inches wide, and should be positioned on the right side of the cooling unit so that it doesn’t restrict the exhaust vent below the cooling unit, as follows:...
  • Page 11 Proper ventilation is critically important for the proper operation of your CellarPro cooling unit. The CellarPro cooling unit blows a significant amount of hot air through the top or the rear of the cooling unit, and the hot air must be exhausted into a space that is at least as large as the wine cellar in order for the heat to properly dissipate.
  • Page 12 300 cubic feet.). WITH DUCTING We offer a duct kit that is designed to work with all CellarPro 1800 cooling units. The kit includes:  A duct hood that fits over the rear of the cooling unit and is designed to connect to two 6”...
  • Page 13 With our duct kit, CellarPro 1800 cooling units can be ducted up to 50 equivalent feet per duct. When calculating equivalent feet, each 90 degree turn in the ducting approximately equals 8’ of ducting. Be sure to use gradual turns to avoid restricting airflow inside the ducting.
  • Page 14 Summary Keep in mind the following guidelines before purchasing a wine cooling unit from CellarPro:  If the cellar it too large for the cooling unit, and/or if the cellar does not have adequate insulation, the cooling unit will be unable to maintain proper temperatures throughout the cellar.

  • Page 15: Replacement Instructions - Wine Cabinets

    5. Place a heavy towel or blanket on top of the wine rack for protection. 6. IF YOU HAVE A LE CACHE MODEL 2400 WITH A CENTER POST: Remove the center post by unscrewing the screws (two at the top and two at the bottom) that attach the post to the wine cabinet.
  • Page 16 Do not let the cooling unit drop on unprotected bottle racks. TO INSTALL NEW COOLING UNIT 1. Wait 24 hours before plugging in and operating your CellarPro cooling unit. 2. Carefully remove the new cooling unit from the packaging. You may reuse this packaging for shipping or storing the old cooling unit 3.
  • Page 17 8. Attach the mounting clips to the FRONT of the cooling unit so that the short side slides under the sheet metal fold near the top of the cooling unit. You may need to remove the front grill (attached with two screws on each side of the cooling unit) in order to slide the mounting clips under the sheet metal, then replace the front grill after the clips are in place.
  • Page 18 2. If your cellar comes with a grill(s), remove and discard the grill(s) behind the cellar. You do not need a grill with the CellarPro cooling unit. 3. Roll up cord and place in fan cavity at rear of cooling unit. If your cellar came with a hard-wired light, separate the lamp cord from black and white leads at the back of the cooling unit.
  • Page 19 Do not let the cooling unit drop on unprotected bottle racks. TO INSTALL NEW COOLING UNIT 1. Wait 24 hours before plugging in and operating your CellarPro cooling unit. 2. Carefully remove the new cooling unit from the packaging. You may reuse this packaging for shipping or storing the old cooling unit 3.
  • Page 20 9. Some cellars have three pieces of foam located on the bottom and on each side of the bracket that supports the back of the cooling unit. These foam pieces should be placed in their original locations 10. Follow the removal instructions described above in reverse. 11.

  • Page 21: Operating Instructions

    V . O p e r a t i n g I n s t r u c t i o n s Overview Please follow the instructions in Chapter I prior to turning on your CellarPro cooling unit. CellarPro cooling units are designed to maintain optimal conditions for wine storage and aging.
  • Page 22 Minimum Set Point to reduce the cycle “on” time. Most wine collectors store their wine in the range of 55 - 60°F. CellarPro cooling units are designed to maintain appropriate levels of humidity, ranging from 50 to 70 percent, inside wine cellars. In order to increase or decrease humidity inside the cellar, the Fon setting can be changed as described in the “Advanced Operation”...
  • Page 24 (anywhere from 3 to 9 months depending on the conditions in your location. When replacing the filter, the blue fibers should face the cooling unit, and the white fibers should face away from the cooling unit. Replacement filters may be purchased at www.cellarpro.com.
  • Page 25 Advanced Operation ...
  • Page 26 8 minutes. Optional Protection Mechanisms CellarPro cooling systems can be programmed to turn off the compressor and condenser fan in the event of an HA2 alarm, as described below. If you’d like to turn on this protection mechanism, please call us toll-free at 877.726.8496...
  • Page 27 The control panel also will flash a code for each alarm, as follows: Alarm Code What it means What to do P1, P3 Probe Failure Call CellarPro at 877.726.8496 The temperature inside Check seals; the cellar is too warm Check if door was left open; (above 70°F for more...

  • Page 28: Troubleshooting

    Hot weather conditions, insufficient insulation, inadequate ventilation, missized cellar capacity and/or dirty condenser coils can all cause the cooling unit to run continuously. If your CellarPro wine cooling unit runs constantly, try the following: Make sure that both fans are spinning ...
  • Page 29 125°F for more than 2 hours, the HA2 alarm will display on the control panel. If this alarm happens when you first receive and start operating your CellarPro cooling unit, check for appropriate installation and ventilation (Chapter II). Also, make sure that there aren’t any obstructions to the intake and/or exhaust vents.
  • Page 30  The LA2 Alarm has been triggered As noted above, the cooling unit is designed to measure the temperature of the condenser coils and, if the temperature drops below a certain point, the LA2 alarm will display on the control panel. To reduce the alarm temperature setting, do the following: 1.

  • Page 31: Limited Warranty

    All service provided by CellarPro under the above warranty must be performed by a designated repair center, unless otherwise specified by CellarPro. Purchaser is responsible for shipping the cooling unit to and from CellarPro or to and from a designated repair facility, and for removing and reinstalling the cooling unit from the wine cellar.
