FIELD SERVICE MODE SETTINGS

Items listed below are in order of display via the "Field Service Mode" on the BACnet FF Screen.
Service Object Default
Code Instance Value
UC AV-95 85
UH AV-96 55
CO AV-93 2
HO AV-94 1
CS AV-99 Calculated From AV-90
HS AV-100 Calculated From AV-90
AL AV-97 4
HI AV-91 78
LO AV-92 62
SP AV-90 70
AP AV-49 Set this to select the required Application
OE BV-2 Off
HC BV-21 Off
FC AV-17 1
CC AV-26 12
C0 AV-27 3
CF AV-18 3
Hc AV-28 3
h0 AV-29 1
hF AV-80 60
2C AV-37 3
2c AV-38 1
c5 AV-64 0
h5 AV-65 0
2P AV-34 1
FA BV-55 Off
cL AV-70 55
hL AV-72 62
P5 BV-47 Off
Sr BV-32 Off
F1 AV-46 20
F5 AV-5 0
F2 AV-85 0
F3 AV-89 0
uL BV-3 Off
50 AV-19 4
Range Purpose/Function
45.0 to 99.0 Unnoccupied Cooling Setpoint
45.0 to 84.5 Unnoccupied Heating Setpoint
0.0 to 20.0 Cooling Offset
0.0 to 20.0 Heating Offset
Occupied Cooling Setpoint
Occupied Heating Setpoint
0 to 9.5 Override Limit (hours)
0.0 to 127.0 Setpoint High Limit
0.0 to 89.5 Setpoint Low Limit
Restricted to range set by Occupant Selected Space Temperature Setpoint.
AV-92 & AV-91.
Application Selection range 0 to 18
Set to On after completing all Enable Outputs
other settings.
On = Heating. Off = Cooling. Reversing Valve Action Heating-Cooling.
1 = Fan runs continuous,
2 = Fan Cycles with Heating,
3 = Fan Cycles with Cooling.
1 to 1440 AC-HP Compressor Cycle Time (mins)
AC-HP Compressor Minimum On Runtime (mins)
AC-HP Compressor Minimum Off Runtime (mins)
1 to 1440 Heating Stages Cycle Time (mins)
(if set to 0 or less this will disable heating)
Heating Stages Minimum runtime (mins)
Heating Stages Minimum Off runtime (seconds)
1 to 1440 2 Position Valve Cycle Times (mins)
2 Position Valves Minimum runtime (mins)
0 to 180 Cooling Valve Stroke Time. (seconds)
0 to 180 Heating Valve Stroke Time. (seconds)
1=On/Off. 2=Analog to Binary 2 Position Valve Mode
On/Off Enable Fan Control display
Cooling Lockout Temp
Heating Lockout Temp
On/Off Off = Enable AI-0 input as a Space Temperature Sensor,
On = use the internal BACnet FF sensor (AV-104).
On/Off On = Enable AI-0 input as Space Temperature,
Off = OAT
Set by DDC AV-80 minus 2% Auto Fan Start Demand %
Fan stop delay (seconds)
Medium Speed Fan Setpoint
High Speed Fan Setpoint
On/Off Reverse Standby Logic.
0 to 12 Standby Heating SetPoint
23
