EasyStand Zing Owner's Manual

Multi-position supine stander. size 1: fits kids up to 44” tall and up to 70 lbs.
Hide thumbs Also See for Zing:

Advertisement

Quick Links

MPS & Supine
size1
Owner's Manual

Advertisement

loading

Related Manuals for EasyStand Zing

Summary of Contents for EasyStand Zing

  • Page 1 MPS & Supine size1 Owner’s Manual...
  • Page 2 SYMBOL LEGEND ENVIRONMENTAL CAUTION/ATTENTION CONDITIONS PINCHPOINT DATE OF MANUFACTURE SEE INSTRUCTIONS FOR USE SERIAL NUMBER Please be environmentally responsible and recycle this product through your recycling facility at its end of life. Afin de préserver l’environnement, veuillez confier ce produit à votre centre de recyclage à la fin de sa durée de vie.

  • Page 3: Table Of Contents

    Table of Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Safety Precautions .

  • Page 4: Introduction

    Indications for Use The EasyStand Zing products have a flat surface that can be adjusted from the prone or supine position to increase tolerance to an upright standing position. The Zing Size 1 is indicated for most individuals weighing up to 70 lbs.

  • Page 5: Safety Precautions

    • It is necessary to inspect your EasyStand Zing at least weekly to ensure it is in safe operating condition. Pay particular attention for loose hardware. Replacement of worn parts, major adjustments, or any other important corrections should be handled by an authorized dealer or service center.

  • Page 6: Assembly

    Assembly 1. Disregard all clear plastic bags and wrapping on the product. Lay out the parts as shown: Base Wheel Assembly Mast Foot Plates Hip Supports Calf Pads Knee Pads Lateral Supports Tray 2. Remove 4 bolts and washers from the base wheel assembly.
  • Page 7 4A. Place the mast onto the floor as shown. Depress the foot pedal. 4B. Allow the mast post to come up to a vertical position. 5. Flip the base wheel assembly over and place onto the mast as shown. 6. Start all 4 bolts and washers you removed in step 2.
  • Page 8 7. Once all 4 bolts have been started, tighten all 4 bolts securely. Place unit onto its wheels. 8. If the calf pad with knee strap was ordered, place the assembly onto the legs as shown. 9. Once the calf pad with knee strap is in position, tighten knobs securely.
  • Page 9 10. If the independent adjustable calf pads were ordered, loosen the ratchet handles on the clamps and position as shown. Clamp Insert the calf pads into the clamps on the multi-adjustable knee pads. 11. Insert multi-adjustable knee pads into the bracket on the outer side of the legs. Tighten securely.
  • Page 10 13. If the multi-adjustable foot plates were ordered, place each foot plate onto the legs. Tighten knobs securely. 14. If the hip supports were ordered, insert hip supports into the bracket behind the pelvic pad. Tighten securely. 15. If the lateral supports were ordered, insert lateral supports into the bracket behind the upper body support pad.
  • Page 11 16A. If the black molded tray was ordered, insert the two tray arms into the tray bracket as shown. 16B. Flip the red plunger back into the locked position and tighten knob securely. 17A. If the multi-adjustable tray was ordered, there are 2 knobs in the parts bag. Screw each knob into the tray bracket on the unit.

  • Page 12: Adjustments & Usage

    Adjustments & Usage Trays Black Molded/Multi-Adjustable Tray Height 19. To adjust tray height, loosen knobs on the back of unit and set to desired position. Tighten securely. Black Molded Tray Depth 20. To adjust the tray, loosen the knob until resistance is felt, then flip the red lever in the center of the knob fully open.
  • Page 13 Hip Supports 25. The hip support width can be adjusted by loosening the knobs behind the pelvic pad. Hip supports come with both thumb knobs and set screws for fore/aft positioning. Tighten securely. Lateral Supports 26. The lateral support width can be adjusted by loosening the knobs on the back of the unit.
  • Page 14 Calf Pad with Knee Strap 29. To adjust the calf pad with knee strap, loosen knobs on each side. Position fore/aft and up/down to the desired setting. Tighten securely. Multi-Adjustable Knee Pads 30. To adjust the multi-adjustable knee pad height, loosen the ratchet handle. Adjust to desired position.
  • Page 15 Head Support 35. To adjust the head support height, loosen the knob on the back, move to desired position. Tighten securely. 36. To adjust the head support depth, loosen the knob on the back of the headrest and slide into desired position. Tighten securely.
  • Page 16 Platform Foot Plates 38. Height-Platfrom Foot Plates are only height adjustable. Loosen knob, set to desired position. Tighten securely. 39A. Straps-Position straps into desired slots. 39B. Foot Holders-Position foot holders into desired position. Insert bolt and tighten knob securely. Multi-Adjustable Foot Plates 40.
  • Page 17 Leg Abduction 46. Loosen knob behind the pelvic pad. 47. Abduct each leg out to the desired position up to 30 degrees per leg. Tighten securely. Page 14...
  • Page 18 Supine (MPS only) 48. Flip the lever located behind the pelvic pad to the “supine to stand” position. 49. Adjust to the desired supine position by depressing the foot pedal and tilting. This can be done with the user in the unit. Prone (MPS only) 50.
  • Page 19 Gas Spring Lockout 54. Pull the lockout knob out and twist to unlock. Your unit can now be positioned using the foot pedal or hand lever. 55. Twist until the knob is vertical and locks into postion. The gas spring is now locked from unintended movement.

  • Page 20: Parts Detail

    Parts Detail-Supine Page 17...
  • Page 21 Parts Detail-MPS (multi-position stander) Page 18...

  • Page 22: Maintenance

    Do not dry clean any upholstery items. • If the EasyStand is being used with one user, clean the EasyStand on a monthly basis or as needed. • If the EasyStand is being used in a multiple-user environment, the EasyStand should be cleaned after each use.

  • Page 23: Limited Warranty

    Limited Warranty This warranty is extended only to the original purchaser/customer (or supplier non consumer who does not buy or resell). Altimate Medical, Inc., warrants the EasyStand against defects in materials and work- manship as listed below. • Steel Frames - 5 year warranty •...
  • Page 24 Morton, MN 56270 USA Toll Free: 800.342.8968 or 507.697.6393 Fax Free: 877.342.8968 or 507.697.6900 email: info@easystand.com www.easystand.com Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any medical precautions. Standing programs should be monitored by the attending therapist. AMI maintains a policy of continual product improvement and reserves the right to change features, specifications, and prices without prior notification.
