EasyStand Bantam Medium Perfect Fit Manual

Bantam
Medium
step one - measure
Before transferring into the Bantam medium,
measure for approximate seat depth. Measure
from the back of the knee to the back of the
back (A). Measure the seat to foot plate settings
by measuring from the bottom of the leg to the
bottom of the heal (B).
If the supine option was ordered, make sure the
controller is in the "Sit-to-Stand" position prior to
adjusting seat depth (C). The seat should be
lowered to a seated position for easiest
adjustment.
step two - seat depth
Use the measurement (A) to adjust the seat depth
on the stander, measure from the front of the seat
to the back.
To adjust the seat depth, loosen the knob under
the seat (D). With one hand supporting the back (if
equipped) depress the spring button on the outer
left side of the seat tube underneath the seat (E).
Using the back as a lever, move the seat depth to
the desired setting, noting the color. Tighten knob
securely (D).
Be sure to have one hand supporting the back
assembly (F). Loosen the 2 knobs on the
following arms (G). With one hand supporting the
back assembly flip the gray plunger lever in the
center of each knob fully open (H). Then continue
to loosen the knob until resistance is felt. DO
NOT continue to turn the knob counterclockwise.
Forcing the knob past its stop will damage the
mechanism.
Caution: Make sure to have one hand supporting
the back assembly, flipping the gray plunger lever
will cause the back assembly to fall.
Using the back as a lever, adjust the following
arms so that the color of the seat depth decals
are matched in the indicator window on the seat
tube underneath the seat. Release the gray
plunger levers to re-engage the locking plungers
in the clamp knobs. You may need to partially
tighten the knobs and slightly move the back
assembly to allow the locking pins to engage their
"home" positions. Fully close the gray plunger
levers and tighten the knobs securely.
step three - back angle
After achieving the desired seat depth, rotate the
back angle adjustment knob (I) so the seat/back
is in the desired angle.
step four - foot plates
Use the (B) measurement to adjust the foot plate
height. Loosen the ratchet handles (J) on the foot
plates to adjust height and plantar/dorsi. Tighten
ratchet handles after positioning. The knees
should be slightly lower than the hip with the legs
resting on the seat.
step five - knee pads
Position the user's hips as close as possible to
stander's hip pivot (K). Position the knee pads
over the knees, not leaving more then a finger
space between the back of the knee and the
seat. Reposition the back and seat depth until 2
finger or less space is reached (L). Tighten knees
securely (M).
Inspect your standing frame periodically to ensure it is in safe operating condition
Printed in the USA. 2017 Altimate Medical, Inc. FORM BANMFG 071917
(A)
(C)
(E)
(G)
(I)
(K)
800.342.8968 • easystand.com
Perfect Fit Guide
(B)
(D)
(F)
(H)
(J)
(L) (M)
