ElectroVoice®
SPECIFICATIONS
Versions Available:
See PIM-252 ordering matrix (Figure 1)
~ Typical Axial Frequency Response with
Presets of Dx34 Digital Speaker System
Processor (swept sine-wave input,
anechoic environment, 4 volts at 1 kHz
at 10 feet; see Figure 2):
45-1B,000 Hz
Typical Axial Frequency Response of
High- and Low-Frequency Sections Alone
(swept sine-wave input, anechoic
environment, 4 volts at 10 feet normalized
for 1 watt at 1 meter; see Figure 3):
45-1B,000 Hz
Low-Frequency 3-d8-Down Point:
45 Hz
Usable Low-Frequency Limit
(10-d8-down point):
40 Hz
Recommended Crossover Frequency:
1,200 Hz
Crossover Slopes,
Recommended:
24 dB per octave
Minimum:
12 dB per octave
Long-Term Average Power-Handling
Capacity (see Power-Handling Test
section),
Low Frequency (per EIA R5-426-A 1980):
BOO watts
High Frequency (per AES2-1984!ANSI
S4.26-1984):
75 watts
Sensitivity (far-field SPL referred to
1 meter, 1-watt input, anechoic environ-
ment, band-limited pink noise),
J
Low Frequency (100-800 Hz):
101 dB
High Frequency (500-5,000 Hz):
112 dB
PIM-252
(standard configuration)
Dual 15-lnch Two-Way
System for Permanent
Installation, Hom Loaded HF
• Part of PI Matrix SeriesTL....compact
trapezoidal systems for permanent
installation
• Components and physical
characteristics optional, to meet many
acoustic, architectural and
mechanical requirements
• 45-Hz low end for speech and many
music applications
• Stacked 15-inch woofers provide
high mid-band directivity-for higher
intelligibility in difficult acoustics
• Three HF coverages-60° x 40°
(standard), 60° x 60° or 90° x 40°
• PROTM circuit HF protection
• For biamplification (standard);
passive network optional
• Integral suspension system for safe
and installation
SPL at Full Power (far-field SPL at 1 watt!
1 meter referred to full power, anechoic
environment, band-limited pink noise),
Long-Term Average!Peak,
Nominal Coverage Angle,
Horizontal: 60°
Vertical: 40°
8eamwidth (angle included by 6-d8-down
points on polar responses, indicated one-
third-octave bands of pink noise, Dx34
presets employed; see Figure 4):
Low Frequency (100-1,200 Hz):
130 dB!136 dB
High Frequency (1,200-5,000 Hz):
131 dB/137dB
2,500 to 16,000 Hz Horizontal:
60° (+12°, _1°)
Impedance,
Nominal (low frequency!
high frequency):
4 ohms!B ohms
Minimum (low frequency!
high frequency):
4.5 ohms/6.3 ohms
Average Efficiency,
Low Frequency: 5%
High Frequency: 25%
FIGURE 1 - PIM-252 Ordering Matrix
500 to 16,000 Hz Vertical:
40° (+2, -12°)
Directivity Factor Re (0), 500- to 16,000-Hz
Median (see Figure 5):
1B.0 (+B .7, -8.5)
Directivity Index
0
1
,
500- to 16,000-Hz
Median (see Figure 5):
12.6 dB (+9.4 dB, -9.3 dB)
NOTE: Example is the s tandard sys tem c onfiguration
Options for
IPIMI
PIM-252
I
252 = Dual 15·inch two·way
t
Woofers :
A = DL15X
B = DL15X-16
C=N/A
D = EVX·150A
HF Drivers:
A = NlDVM" 1
B = NlDVM" 1-16
C = DH1A
D= DH1A·16
E = DH2As2
F = DH2As2·16
52ACA·C· BAAXXX
=
Dual 15-inch two-way with two
o
7
l1 5X, DH1A on an HP64S ,
·ply birch enclosure, painted
lack, barrier strip for biamp,
b
me
A
tal grille. flying hardware for
ncra
42546·10'5,
no
crossover and no miSC. Items,
Horns:
A = HP64S
B = HP66S
C = HP94S
252IAlcIAI-lcl-IBIAIAlx
X X
Mise 2:
X = none
..
i
1
I
Mise 1:
1
X = none
A = handles
Crossover:
L . . -
X
=
none
A = passive. standard
L . . -
B = passive, custom
L . . . - -
Rigging:
X
= none A = Ancra
Enclosure Finish/Materials:
Grille:
A = unfinished. 7 ·ply birch
B = unfinished. 14·ply birch
A = metal B = metal w/foam
C = textured blk paint. 7 -ply birch
D = textured blk paint. 14·ply birch
Input Panel :
E = Wolverine'" ureth .• 7·ply birch
A = Speakon"', Bi·Amp
F = Wolverine'" ureth. , 14·ply birch
B = barrier strip, Bi-Amp
G = white primer, 7-ply birch
C = Speakon"', passive
H = white primer. 14·ply birch
D = barrier strip, passive
