Operating lnstructions-7A19
trace to the
top
graticule
line.
Do
not
move
the
POSITION
control
after this
reference
line
has
been
established.
4.
Set the
Coupling
switch
to
DC.
The
ground
reference
line
can
be checked
at
any time by
switching to the
GND
position.
NOTE
To
measure
a
voltage
level
with respect
to
another
voltage
rather
than ground,
make
the
following
changes
to
Step
4.
Set
the
Coupling
switch
to
DC
and
apply
the reference voltage
to
the
INPUT
connector.
Then
position the
trace to
the reference
line
and
disconnect the reference
voltage.
5.
Set the time-base
Triggering
controls
for a stable
display.
Set the
Time
Base
sweep
rate for
an
optimum
display of the
waveform.
6.
Measure
the
distance
in
divisions
between
the
reference
line
and
the point
on
the
waveform
at
which
the
DC
level
is
to
be measured. For example,
in
Fig.
2 2 the
measurement
is
between
the reference
line
and
point
A.
7.
Establish
the polarity of the
waveform. With
the
POLARITY
switch
in
the
NORM
position,
any
point
above
the reference
line
is
positive.
8.
Multiply the distance
measured
in
step
6
by
the
VOLTS/D
IV switch
setting.
Include the attenuation
factor
of the probe,
if
used.
Po
r—
-
nt
A
If
.
._
u
/
"
'
'
-M-f f
m
•«
1
1
-H-++
4-H-f
Vertical
distance
..L,
\
Reference
line
Fig.
2-2.
Measuring
instantaneous
voltage
with
respect to
same
reference.
With
high
speed
signals,
the
transit
times of the probes
and
amplifiers
can
distort
the true
time
relationship of the
two
signals.
By
using the
VARIABLE DELAY
(Option
4),
the
transit
times
between
two
units
can be
matched
to
within
50
ps,
thus
giving
a
true
time
relationship of
the
signals
being viewed.
For matching
transit
times of
two
7A19
with
probes,
proceed
as
follows:
EXAMPLE:
Assume
the
vertical
distance
measured
is
3.6
divisions
(see Fig.
2-2)
and
the
waveform
is
above
the
reference
line,
using
a
lOX
probe with
a
VOLTS/DIV
switch
setting
of 0.5
V.
Using
the
formula:
Instan-
vertical
VOLTS/
probe
taneous =
distance
X
polarity
X
DIV
X
attenuation
voltage
(divisions)
setting
factor
Substituting the given
values:
Instantaneous Voltage
=
3.6
XIX
0.5
V X
10
The
instantaneous
voltage
is
18
volts.
Matching
transit
times
using
two
7A19's,
one
having
VARIABLE DELAY
(Option
4)
In
some
applications
it
is
necessary to
view
the
time
relationship of
two
signals,
one
with
respect to the other.
1.
Install
the
7A19
without
the
VARIABLE DELAY
option
in
the
left
vertical
plug-in
compartment.
2.
Install
the
7A19
with
VARIABLE
DELAY
option
in
the
right vertical plug-in
compartment.
3.
Connect
the
probes
to
a
common
signal
source
of
greater
than
100
kHz
and
adjust the
time-base
unit for
the
fastest
sweep
available.
4.
Set
the
Trigger
Source
switch
to
left
Vert,
and
Vertical
Mode
to Alternate.
5.
Set
both
7A19's
to
the
same
deflection
factor
settings.
6.
Center both
displays
vertically.
7.
Adjust
VARIABLE DELAY
so that the
two
displays
are
superimposed.
The
transit
times
of
both
units are
now
matched.
