SuperSail Marine Alarm Installation Manual
Marine alarm wireless
Hide thumbs
Also See for Marine Alarm:
- User manual (20 pages) ,
- Installation manual (8 pages) ,
- Installation manual (7 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
User Manual
Advertisement
Table of Contents
Related Manuals for SuperSail Marine Alarm
Summary of Contents for SuperSail Marine Alarm
-
Page 1: Installation Manual
Installation Manual Installation Manual SuperSail Marine Alarm Wireless Page 1 of 8... -
Page 2: Table Of Contents
Installation Manual Table of Contents CONTENTS OF THE PACKAGE ....................3 INSTALLATION ........................... 4 ....................4 OCATION OF THE NTENNAS ......................4 NERGY ONSUMPTION 12/24V C ........................ 4 ONNECTION ....................5 IRES IN THE ONNECTION ...................... 5 UTBOARD NGINE LARM ....................... -
Page 3: Contents Of The Package
Installation Manual Contents of the package The Supersail Marine Alarm basic package consists of the following: SuperSail Marine Alarm base (note the serial number of the unit) GPS antenna Mobile (GSM) antenna Siren Alarm connection box for cable connection of 12/24V and external units. Contains also fuse for protection. -
Page 4: Installation
Installation Manual Installation SuperSail Marine Alarm is delivered in a box containing the Alarm unit with associated antennas, connection box, siren and cables. The Alarm unit must be connected to 12/24V external power supply and additional different alarm sensors can be connected. -
Page 5: W Ireless W Ater S Ensor
Installation Manual This is a precondition for the Alarm unit to function as secure monitoring of the boat. Note that the siren must be either a 12V version or a 24V version, depending on the external supply level. Wires in the Connection Box In the below table the use of the different cables from the Alarm unit is shown. -
Page 6: W Ireless M Otion S Ensor
2.12 Maintenance The SuperSail Marine Alarm system is maintenance free. Repairs should be carried out at an authorized service center. Cleaning can be carried out with a soft cloth wrenched in lukewarm water Cleaning detergent containing solvent can harm the unit. -
Page 7: T Echnical S Pecifications
Installation Manual 2.13 Technical Specifications Power supply 12V or 24V DC Internal backup battery 1000 mAh Lithium Power use during operation 75 mA ex. possible use from external units connected to digital outputs Power use in energy mode 0.6 mA Power use while charging 500 mA Digital outputs... -
Page 8: Service
Installation Manual Service The SuperSail Marine Alarm system is on the front equipped with 3 LED. LED 1 and LED 2 is solely for service purpose and is used in connection with troubleshooting on the unit. LED 3 can with advantage be used to verify the GPS signal after installation.
