SuperSail Marine Alarm User Manual

Marine alarm
Hide thumbs Also See for Marine Alarm:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
User's Manual
User's Manual
SuperSail System
Side 1 af 20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Marine Alarm and is the answer not in the manual?

Questions and answers

Related Manuals for SuperSail Marine Alarm

Summary of Contents for SuperSail Marine Alarm

  • Page 1 User’s Manual User’s Manual SuperSail System Side 1 af 20...

  • Page 2: Table Of Contents

    ..........................19 HARGING ..........................19 PERATION ................... 19 OINT OF NTEREST EMOTE ONTROL LED’ ......................... 19 S INSIDE MARINE ALARM TRACKERS .................... 20 10.1 ..........................20 HARGING 10.2 ..........................20 PERATION LED’ 10.3 ........................20 S IN Side 2 af 20...

  • Page 3: Introduction

    SuperSail Marine Alarm is developed for fixed mounting in dry environment inside a larger boat. The Marine Alarm must be connected to external power supply and the antenne must be placed where the best signal is achieved. Alarm sensors can be connected wired or wireless.

  • Page 4: Login Menu

    If you have bought subscription for regatta data, your email and password will furthermore give access to your regatta data via the SuperSail website: www.super-sail.dk, under the menu “My Races”. Key in your email address in the Email field. Touch the field to have the keyboard displayed.

  • Page 5: Main Menu

    User’s Manual Main Menu In the main menu you have access to all relevant functions. At the top your name and your boats name are displayed. Your boats name is used in regatta data to identify the boat, and in alarm SMS’s, where it is included in the text.

  • Page 6: Tracker Info Menu

    User’s Manual Tracker Info Menu From the main menu it’s possible to edit your tracker settings, by selecting the ”Tracker” button. Pushing the “Back” button returns to the main menu without changing tracker settings. At the top you find the ”Reset Tracker” button, which executes a reset of the tracker.

  • Page 7: Surveillance Menu

    From the main menu it’s possible to activate surveillance of yourself during your sailing, by pushing the button “Surveillance”. This function is primary intended for dinghy sailors with a SuperSail Regatta Tracker, who are sailing/training alone. Via the button on the Regatta Tracker Surveillance, the tracker can send an SMS to up to 4 mobile numbers by a single press on the push button.
  • Page 8 User’s Manual If a message is sent by a mistake you can hold the Call Button in for at least 5 seconds, and the tracker will send a message to your predefined mobile numbers that the message is cancelled. The lamp around the Call Button stops blinking. Turning the Surveillance function off, initiates a message to your predefined mobile numbers telling that they are no longer monitoring you.

  • Page 9: Alarm Menu

    When your subscription is created a login to your subscription data is created with a personal password independent of the password used for the mobile app. Editing your subscription data can be done via the “Login” button on top of the SuperSail website www.super-sail.dk. Functions The Alarm Menu contains the following functions: ...

  • Page 10: Inputs

    User’s Manual Inputs SuperSail Marine Alarm Wireless has 2 configurable inputs, where SuperSail Marine Alarm has only 1. To the inputs external sensors like e.g. a smoke alarm or float switch can be connected, or a wire to an outboard engine can be connected for monitoring this. In the text field you can write a text that identifies the connected units.

  • Page 11: Chock Sensor

    Maximum chock effects with a configurable alarm limit in unit 1/1000 g (g=gravity). The Marine Alarm must be fixed mounted in the boat, to register the chock effect correct. Experience has shown that a value of 500 (500/1000 g ~ ½ of gravity) is normally suitable.

  • Page 12: Regatta Menu

    Data is collected for all boats registered for the same race in the regatta, and data for the complete race can be downloaded via the SuperSail website www.super-sail.dk. The tracking is automatically started 15 minutes before the race start and will automatically stop when the race ends.

  • Page 13: Register/Cancel Race Menu

    User’s Manual Register/Cancel Race Menu In the Register/Cancel menu is shown the races contained in the selected regatta. From this menu it’s possible to register or cancel individual races in a regatta. Registration is done by setting the check box for the relevant race.

  • Page 14: Cancel Regatta Menu

    Access to the Create regatta menu is controlled via user rights, which is assigned by your system administrator or by SuperSail. From this menu you can create new regattas or edit existing regattas.

  • Page 15: Create/Edit Regatta Menu

    User’s Manual Create/Edit Regatta Menu When you have defined the regatta to be edited or created, the Create/Edit regatta menu is shown. At the top is shown the name of the regatta to be edited or if the field is empty, you can define the name of the regatta. The system will not accept the same regatta name for more regattas for the same day.

  • Page 16: Create/Edit Race Menu

    User’s Manual Create/Edit Race Menu When you have specified the race that you want to edit or create, the ”Create/Edit Race” menu is shown. At the top is shown the name of the race to be edited or if the field is empty, you can define the name of the race.

  • Page 17: Download Regatta Data

    User’s Manual Download Regatta Data Download of regatta data is done via the SuperSail website (www.super-sail.dk), from where data for the races that you have participated in are available for download. Under the tab “My Races” you can key your email address and your password, which are the same that you use logging in to the mobile app.
  • Page 18 User’s Manual All data for the chosen regatta will be downloaded including all tracker files for the participating boats and wind data files for the boats having a wind instrument connected to the tracker. The following files are downloaded: 1. Comma separated position data files: ”Boat name”.csv 2.

  • Page 19: Regatta Trackers

    As the tracker never turns completely off, it will always have a minimal power consumption. Operation The tracker is started by the SuperSail server, which means that the GSM network connection is always active. When the Regatta Tracker is removed from the charger it enters an energy mode to reduce power consumption.

  • Page 20: Marine Alarm Trackers

    An intelligent internal charger ensures maximum life time for the internal battery. 10.2 Operation The tracker is started by the SuperSail server, which means that the GSM network connection is always active. If the external 12V supply for the alarm system is removed while the alarm is active it enters energy mode and reduces the monitoring of theft to 15 minutes intervals.
