- Page 1 Flexy Installation Guide 3G GSM Extension Card IG 019 / Rev. 1.4 FLB 3202 This installation guide explains how to install the eWON Flexy 3G GSM Extension Card FLB 3202. support.ewon.biz...
-
Page 2: Table Of Contents
5.2. Detected Cards Displayed in the System Page ..............15 5.3. Modem Information Displayed in the Info Page ..............16 Revision ..........................17 Revision History ............................. 17 Page 2 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 3: Product Summary
3202 of the eWON Flexy family. The eWON Flexy family is a range of modular industrial gateway/router. As the name eWON Flexy suggests, it has been designed to enable numerous different combinations of Extension Cards and Base Units. The present Installation Guide is focusing on an extension card which, as such, needs to be inserted in one of the Base Units in order to work. -
Page 4: Safety, Environmental & Regulatory Information
2.1. Scope The present heading addresses Safety, Environmental & Regulatory Information for the 3G GSM Extension Card FLB 3202. This Extension Card is basically belonging to the same compliance frame than the Base Units. In the present case of a telecommunication Extension Card, additional directives, standards and instructions apply. -
Page 5: Applicable Safety Standards
• Certificate Of Compliance (COC) # E350576 • CB certificate # DK-29479-M1-UL These certificates can be downloaded as PDF files on the eWON Support web site: http://support.ewon.biz/flexy 2.4. Official Modem Identification This product contains part identified as follows by national authorities: •... -
Page 6: Hardware Description
Chapter 3 Hardware Description 3. Hardware Description 4. Mechanical Layout and Interfaces SMA-F Female antenna connector SIM-Card drawer Backplane connector Page 6 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 7: Extension Card Label
0001 = sequential mfg order = product type CE, UL,... certificate number and Marks logos if applicable. Notified Body Number warrantor 0682 of the CE Mark validation Page 7 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 8: Part Number Structure For Extension Cards
Poor signal Reception Signal level █ Orange ON = level >10 Signal is OK Reception Signal level ▄ Orange ON = level >16 █ Good signal Page 8 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 9: Specifications Of The 3G Gsm Extension Card
Absolute maximum antenna gain as per FCC's rules and regulations, 47 CFR : Part 22H : 5.22dBi • Part 27 : 3.31dBi • Part 24E : 6.45dBi • Page 9 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 10: Ewon Flexy Extension Cards Environmental Conditions
Up to maximum 3000m 4.5. Plugging the Extension Card into the Base Unit 4.5.1. Base Unit Slot Compatibility The 3G GSM Extension Card (FLB 3202) must be inserted in one of the “B” slots of the Base Unit. Explanation: The Flexy Base Units feature two type of slots. The A slots are the two first slots starting from the left. -
Page 11: Sim-Card Insertion
SIM-card when the Extension Card will be inserted in the Base Unit. Note the position of the cutoff (1) of the SIM- card. Page 11 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 12: Extension Card Insertion
NOT complete its BOOT process. Therefore, the unit will not be accessible through its LAN interface. The slot error is returned by the USR LED. (red ON 1sec, OFF 0.5 sec). Page 12 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 13: Multiple 3G Gsm Extension Cards
Mechanical Layout and Interfaces 4.6.1. Multiple 3G GSM Extension Cards The eWON Flexy firmware currently supports up to one 3G GSM Extension Card of type FLXB3202. The boot process of the Base Unit includes an automated detection of the inserted Extension Cards. -
Page 14: Powering On The Base Unit With Its Extension Cards
Would the USR LED of the Base Unit be flashing RED, it might be because the Extension Card was improperly inserted (for example in a wrong slot). Page 14 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 15: Check Card Detection On The Embedded Web Page
Cards. To access the system status summary, click on Diagnostic (1) > Status (2) > System Info (3) > System (4). The screen capture below gives an example of an FLB 3202 extension card that has been detected in slot 3 (5). -
Page 16: Modem Information Displayed In The Info Page
- is available in the Info page. The path to the Info page is: Diagnostic (1) > Status (2) > System Info (3) > Info (4). Page 16 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019... -
Page 17: Revision
No part of this handbook can be reproduced, transmitted or copied in any way without written consent from the manufacturer and/or the authors of this handbook. eWON sa, Member of ACT'L Group Page 17 / 17 eWON Flexy 3G GSM Extension Card FLB 3202 | IG 019...
