Sony KDL-60NX801 Operating Instruction

Bravia lcd digital color tv.
Hide thumbs

Advertisement

LCD
Digital Color TV
Setup Guide
KDL-60NX810 / 60NX801 / 60NX800 / 55NX811 / 55NX810 / 52NX800 / 46NX810
KDL-46NX800 / 46NX711 / 46NX710 / 46NX700 / 40NX711 / 40NX710 / 40NX700
Downloaded From TV-Manual.com Manuals
(Operating Instructions)
Setting up your TV
To watch TV
Additional Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Please Do Not Return
the Product to the Store
4-178-676-
(1)

Advertisement

Table of Contents

   Related Manuals for Sony KDL-60NX801

   Summary of Contents for Sony KDL-60NX801

  • Page 1 4-178-676- Setting up your TV To watch TV Digital Color TV Additional Information Setup Guide (Operating Instructions) Sony Customer Support U.S.A.: www.sony.com/tvsupport Canada: www.sony.ca/support United States Canada 1.800.222.SONY 1.877.899.SONY Please Do Not Return the Product to the Store KDL-60NX810 / 60NX801 / 60NX800 / 55NX811 / 55NX810 / 52NX800 / 46NX810 KDL-46NX800 / 46NX711 / 46NX710 / 46NX700 / 40NX711 / 40NX710 / 40NX700 Downloaded From TV-Manual.com Manuals...
  • Page 2 Glasses or the battery near fire, or “PlayStation” is a registered trademark the spaces provided below. Refer to and “PS3” is a trademark of Sony in places with a high temperature, them whenever you call upon your Computer Entertainment Inc.
  • Page 3: Table Of Contents

    ® The BRAVIA Full HDTV Experience • Receive over-the-air HD broadcasts with an Thank you for choosing Sony! Your new HD-quality antenna connected directly to the ® BRAVIA TV opens the door to the “Full HDTV back of your TV.
  • Page 4: Checking The Accessories

    *3 KDL-60NX801/60NX800 models are shipped with the parts attached to the TV. Checking the accessories *4 These screws and spacers are required when installing an optional Wall-Mount Bracket. For all models You must use these screws instead of the ones Table-Top Stand (1) provided with the bracket for safety reasons.
  • Page 5: Programming The Remote Control

    1 Look for the code in the Manufacturer’s Code List (refer to i-Manual) that corresponds to the equipment you would like to operate with the Sony remote control. If more than one code is provided, try programming the first code listed. If your equipment’s code is not listed, visit...
  • Page 6: Setting Up Your Tv

    Setting up your TV Some TV models are packaged with a Attaching the Table-Top detached Table-Top Stand so you can mount your TV to a wall right away. If you are not Stand mounting the TV to a wall, you will need to attach the Table-Top Stand.
  • Page 7 After all the screws are tighten cover the Table-Top Stand with the supplied Stand Rear Cover. For KDL-55NX811, KDL-60/55/ 46NX810, KDL-46/40NX711 and KDL-46/40NX710 Align with the two dowels of the Table-Top Stand, and gently place the TV, checking the f mark is facing the front.
  • Page 8 Adjusting the viewing angle (except 60-inch models) This TV can be adjusted within the angles shown below. For KDL-52/46NX800 and KDL-46/40NX700 0° 6° Remove screw as Install screw into the shown. top screw hole of the Table-Top Stand. Slide in. Lift up and tilt.
  • Page 9: Connecting The Tv

    Connecting the TV The following chart shows the high-definition (HD) and standard-definition (SD) video formats supported by your BRAVIA TV inputs. 720/24p format is supported by KDL-55NX811, KDL-60/55/46NX810, KDL-46/ 40NX711 and KDL-46/40NX710. For supported PC formats refer to the i-Manual. Downloaded From TV-Manual.com Manuals (Continued)
  • Page 10 Shown with a Set Top Box with HDMI Shown with a Set Top Box with connection COMPONENT connection Set Top Box Set Top Box Cable System or VHF/UHF Antenna System Cable Antenna Downloaded From TV-Manual.com Manuals...
  • Page 11 ® Shown with HD BRAVIA Sync™ Basic Connection *Rear of TV *A/V Receiver SAT IN DVD IN VIDEO 2/BD IN OPT IN OPT IN COAX IN AUDIO IN AUDIO IN AUDIO IN VIDEO 1 FRONT R FRONT L SUR R SUR L CENTER SUBWOOFER *Blu-ray Disc...
  • Page 12 Shown with PC Connection with SD VCR/DVD Side Panel Rear of TV Notebook PC Splitter VCR/DVD Combo Cable/Antenna Downloaded From TV-Manual.com Manuals...
  • Page 13: Securing The Tv

    Consider the following measures when chain. securing your TV to a TV stand (not An alternative way to secure the TV is with supplied). an optional Sony Support Belt Kit. Machine screw (not supplied) Rope or chain (not supplied) Screw hole on the...
  • Page 14: Organizing The Ac Power Cord

    Organizing the AC power Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV cord model name. • For United States call: 1-800-488-7669 or visit: www.sony.com/accessories • Do not bundle the AC power cord together •...
  • Page 15: Running Initial Setup

    • Do not remove the Table-Top Stand for any reason other than to install corresponding accessories on the TV. Complete your cable connections For KDL-60NX801, KDL-60/52/ before proceeding with the Initial 46NX800 and KDL-46/40NX700 Setup. Connect the TV to your nearest power •...
  • Page 16: Using A Wall-mount Bracket

    (10 cm) you use the Wall-Mount Bracket (10 cm) designed for your TV and the installation should be performed by a Sony dealer or licensed contractor. Leave at least this much space around the set. • Follow the instruction guide provided...
  • Page 17: To Watch Tv

    To watch TV To watch programs Turn on the TV. Check the ENERGY SAVING SWITCH setting is on (z). Press 1 (POWER) on the TV or TV ?/1 on the remote control to turn on the TV. (You may use the GUIDE TV ?/1 button located on the back of the remote control.)
  • Page 18: To Use I-manual

    To use i-Manual Your BRAVIA TV comes with an on-screen manual. You can browse your i-Manual anytime you need to find the varieties of convenient functions. Press i-MANUAL. Press F/f/G/g/ to navigate and select items. i-Manual Welcome to i-Manual BRAVIA TV Features Watching TV Using the Home Menu Fun Features with Connected Equipment...
  • Page 19: Troubleshooting

    Press 1 (POWER) on the TV to turn it off, disconnect the AC power cord, and inform your dealer or Sony service center of how the indicator flashes (number of flashes). When the STANDBY indicator is not flashing Check the items in the tables below.
  • Page 20: How To Care For Your Bravia

    Condition Explanation/Solution • Replace the batteries. The remote does not • Your TV may be in SYNC mode. Press SYNC MENU, function. select TV Control and then select Home (Menu) or Options to control the TV. The TV and its •...
  • Page 21: Specifications

    Specifications Model name KDL- 60NX801/ 52NX800 46NX800 46NX700 40NX700 60NX800 System Television system NTSC: American TV standard ATSC (8VSB terrestrial): ATSC compliant 8VSB QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69 Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel...
  • Page 22 Model name KDL- 60NX810 55NX811/ 46NX810 46NX711/ 40NX711/ 55NX810 46NX710 40NX710 System Television system NTSC: American TV standard ATSC (8VSB terrestrial): ATSC compliant 8VSB QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69 Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel...
  • Page 23 (meaning they have priority) of 5250-5350 MHz and Sufficient expertise is required for TV installations. Be 5650-5850 MHz and these radars could cause sure to subcontract the installation to a Sony dealer or interference and/or damage to this device. licensed contractor and pay adequate attention to safety...
  • Page 24: Software Updates

    Software Canada http://www.sony.ca/support Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by selecting Settings, Product Support and then Automatic Software Update. © 2010 Sony Corporation Printed in U.S.A. Downloaded From TV-Manual.com Manuals...
