User Manual
Of Digital Set Top Box
ADT110
* Caution
- This settop box is used for PAL TV (PAL B/G :Germany, Italy, Belgium, PAL-I : UK) and
Multi-system TV only.
- In case the picture is not correctly shown up on your TV, please adjust your COLOR
SYSTEM setting to AUTO or PAL.
Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.

Advertisement

loading

Related Manuals for Triax ADT110

Summary of Contents for Triax ADT110

  • Page 1 User Manual Of Digital Set Top Box ADT110 * Caution - This settop box is used for PAL TV (PAL B/G :Germany, Italy, Belgium, PAL-I : UK) and Multi-system TV only. - In case the picture is not correctly shown up on your TV, please adjust your COLOR SYSTEM setting to AUTO or PAL.

  • Page 2: Table Of Contents

    Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. The symbol indicates that dangerous voltages constituting a risk of electric 4) Follow all instructions. shock are present within this unit. 5) Do not use this apparatus near water. The symbol indicates that there are important operating and maintenance 6) Clean only with dry cloth.

  • Page 3: Front And Rear Panel Illustration

    Front and Rear Panel Illustration Remote Controller Remote Key Function: 1. Front Panel 1. MUTE:Turn the sound on or off. 2. NUMBER KEYS:Select channel numbers or input numbers in menus. 3.TV/RADIO: Switch between TV channels and Radio stations. 4. INFO: Display information about the channel being viewed or further information about the program when in small EPG screen.

  • Page 4: Connections

    Installing the Batteries Connections Remove the battery cover from the remote control and put 2xAAA size batteries inside the compartment. Caution: Make sure to check the voltage specification of the wall outlet is the same The diagram inside the battery compartment shows the correct way to install the rating with the receiver.

  • Page 5: User Interface

    7) DTV/VCR Switch User Interface Press DTV/VCR key on remote to toggle between DTV and VCR mode. 8)D igitalIn formation The 'Exit ' key will remove all digital menus. Whenv iewingad igitalpr ogram,asi nglep resso fth ein fok eyw illbr ing The exception to this is for persistant banners i.e.
  • Page 6 9) Channel Change OSD Again, the user will be able to scroll through information for other channels whilst still watching the current program by using the CH+/- keys. In addition, This is the graphic seen after using CH+/- or when a direct digit entry the left and right cursor keys will toggle extended info for 'Now' and “Next”.
  • Page 7 14) Main Menu 11) Subtitle The Main Menu contains 5 options. Pressing the subtitle key will display the following menu. This menu displays all the subtitle streams available on the current service and a subtitle off option. The selection is done using the up/down keys. Pressing the OK key selects the new subtitle language.
  • Page 8 If the user selects to delete a service, then the first time this is se lected the user must enter the PIN. This is to prev ent deletion of services without a parent's consent. Re-order Menu 2. Favourites 2.2) Name Editor 1.
  • Page 9 The options are: If the PIN is not entered before a timeout or it is skipped then the event Three digit channel number. will still be added and viewing restrictions will apply to the event Date Start date in DD/MM/YYYY format. depending on its censorship level.
  • Page 10 System benefit from being supplied with a default PIN and a master PIN. The master PIN is intended to be used to over-ride the user supplied PIN if it is lost or forgotten. 4.3.3) Parental Control Menu Entering a valid PIN gives access to a sub menu that provides options to change the PIN, Lock and Unlock services or adjust Censorship.
  • Page 11 4.3.5) Parental Locking Change PIN 4.4.2) Full Scan Replace Existing Services Selecting the option to change the PIN takes the user to a further sub When 'Full Scan Replace Existing Services' option is selected, the menu that handles the confirmation and storing of the new PIN. same as the 'Full Scan Add New Services' menu is displayed except The menu prompts for a new PIN.
  • Page 12 Signal Level Bar indicator to show the current signal level. If the video can't be displayed then one of the following messages will This bar will have 3 colours to distinguish how good the be displayed in the preview area: signal is, RED=Bad, YELLOW=Medium and GREEN=Good.
  • Page 13 Some downloads may be signaled as high priority which means the 4.5) Check For Download manufacturer of the receiver wants the user to perform the download. The option allows the user to update the software. In this case the download will automatically start when detected or after leaving standby.
  • Page 14 Thumbnail/Folder (3) Download message after restart The info(Width x Height and date) of selected photo will be displayed When the receiver restarts after a download, the following menu will be at the left bottom at Thumbnail mode. displayed. This can contain either a success or failure message and any other information about the new software.

  • Page 15: Specifications

    Specifications Troubleshooting If you experience problems with this receiver or its installation, in the first instance please read carefully the relevant sections of this User Manual and this Troubleshooting section.
