Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
Contents Front panel Troubleshooting Safety instructions Technical information Before washing for the first time Installation Loading the dishwasher Service Using the dishwasher Program chart Settings Your notes Care and cleaning Front panel The panel is fitted with touch buttons with audible feedback (see the chapter Settings). On/Left-on mode Rinse aid indicator Delayed start...
Safety instructions General WARNING! Read the operating instructions and keep them in a safe place! Dishwasher detergents are strongly alkaline. They can be Never use the dishwasher for any purpose other than that extremely dangerous if swallowed. Avoid contact with skin and specified in these operating instructions.
Before washing for the first time Loading the dishwasher Program key Economic dishwashing Some dishwashers include program keys in different languages. Run programs only with a full load Attach the program key in the desired language to the top of the Wait to run a program until the dishwasher is full.
Knife basket Upper basket and knife basket Place glasses, cups, bowls, side plates and saucers in the upper basket. Wine glasses are placed on the wine glass shelf (if fitted). Place sharp knives in the special knife basket at the top of the dishwasher, or in the knife stand on the right (if fitted).
Positioning of cutlery basket lid (in upper basket) The cutlery basket lid can be removed and used, for example, as an extra cutlery basket in the upper basket (see below). Cutlery basket Place cutlery with the handles facing down, except for knives, and spread them out as much as possible.
Using the dishwasher Add detergent Program selection Press the Program selector one or more times until the desired program symbol appears on the display. Time program The program adapts to the specified running time or finish time. With this program it is important to choose a time suited to how dirty the dishes are.
2 Press Start/Stop and the dishwasher counts down 1 hour at Eco wash a time and starts after the selected delay. Use when you want to save water. For normally dirty dishes. Press and hold Start/Stop for three seconds if you want to cancel the Delayed start option.
Blue If the dishwasher is turned off using Load more. The program has started, but you can still load more the On/Left-on mode button or due dishes. to a power failure Do not load. You should not load more dishes (risk of poorer If the dishwashing program was not finished, the interrupted dishwashing result).
Settings Do as follows to open the settings menu: First, open the door. Turn off the dishwasher using the On/Left-on mode button (press and hold). Release the button. Press and hold the On/Left-on mode button until the display lights up. Within five seconds, press and hold the Program selector and the Long dry button.
Page 11
Button press Options Settings Description Operation volume This sound is used to confirm each button press. (Off) (Low) (High) Press Start/Stop to save the setting value and continue to the next setting. LCD contrast For adjusting the contrast of the display on the panel. (Low) (High) Press Start/Stop to save the setting value and continue to the next setting.
Care and cleaning Coarse filter NOTE! The coarse filter traps larger food particles, which cannot get The dishwasher must not be used without the filter in place! past the drainage pump. Empty the coarse filter as necessary. Diswashing efficiency can be affected if the course filter is 1 Lift the coarse filter by the handle.
Door When cleaning the edge around the door, use only a slightly damp cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock. This is to ensure that water does not penetrate the door catch and come into contact with the electrical components.
Troubleshooting Display Type of fault Action Overfilling Call the service division. Water outlet fault See "Water remains in the dishwasher" in the table below. Water inlet fault Check that the water tap is on. Check whether dishwasher inlet hose is connected to a pressure limiting valve (some pressure limiting valves may restrict the supply of water to the dishwasher).
Page 15
Problem Possible causes Action Spots left after washing. Lipstick and tea can be difficult to wash off. Use a detergent with a bleaching agent. Rattling sound when dishwashing. The dishes are not correctly placed or the Check that the dishes are placed securely. spray arms are not rotating.
Page 16
Problem Possible causes Action Cannot close door. The baskets are not correctly positioned. Check that the baskets are correctly posi- tioned horizontally. Check that the dishes are not blocking the baskets from sliding properly into place. The touch buttons do not react when You have pressed the touch buttons too soon Wait a moment then try again.
Technical information Information for test institute Energy labelling Australian standard: AS/NZS 2007 Number of place settings: Dishwashing programs: Normal program; Low temperature, Short dry (no options) The door should be opened upon completion of the drying cycle a distance of 35 mm at V. Program time: 1:45 hours:minutes Connection:...
1 Teaspoons 2 Dessertspoons 3 Soupspoons 4 Forks 5 Knives Technical data Height: 857-912 mm Width: 596 mm Depth: 550 mm Weight: 50 kg Capacity: 14 Place settings Water pressure: 0.03–1.0 MPa 0.3–10 kp/cm 3–100 N/cm Electrical connection: See type plate. Rated power: See type plate.
Installation 1229 [mm] 30-94 *Remove locking nuts for an installed height of 860-861 mm. **Door length. It is important that you read through and follow the instructions Make sure the area on which the dishwasher is to be installed and directions below. Conduct installation and connection in is firm.
Service Read chapter Troubleshooting before contacting the service Connection to water supply department. Note down the details on the rating plate positioned Use only the supply hose provided with the dishwasher. Do not on the right inside the dishwasher. Note down the item number re-use old hoses or other spare supply hoses.
Two minutes after the last button press, the panel backlight enters energy saving mode. Close and reopen the door, or press the On/Left-on mode button, to reactivate the panel. Press and hold Start/Stop for two seconds and close the door (see page 8) en (05-14) ASKO APPLIANCES AB SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
