12 Replacing components
3.
Fitting a magnetron
Follow the steps in the reverse order to fit a spare magnetron.
Ensure nothing becomes trapped under the magnetron mounting points (e. g. insulation material) while
fitting the magnetron. This can lead to microwave leakage.
NOTICE:
If the electric connections have not been restored properly this may lead to malfunction/damage of the
oven.
eikon e2s Service and Repair Manual CE
Unfasten four M8 hex cap screws to remove the magnetron.
There is one pair of screws on each side of the magnetron.
Disconnect any cables leading into the magnetron(s).
143
