- Page 1 LED‐707‐1W (RGBW/RGBA) User Manual Please read the instruction carefully before use ...
- Page 2 Contents 1. Safety Instructions....................2 2. Technical Specifications ....................3 3. Panel.........................4 4. Troubleshooting......................5 5. Cleaning And Maintenance ..................5 ...
- Page 3 1. Safety Instructions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. It’s important to ground the yellow/green conductor to earth in order to avoid electric shock. The unit is for indoor use only. Use only in a dry location. The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure that no ventilation slots are blocked. Disconnect main power before replacement or servicing. Make sure there are no flammable materials close to the unit while operating as it is fire hazard. Use safety cables when fixing this unit. Maximum ambient temperature is Ta: 40 degrees C. DO NOT operate it where the temperature is higher than this. Turn off the power and allow about 15 minutes for the unit to cool down before servicing. ...
- Page 4 Caution: There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer. Installation: The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. Make sure that the structure to which you ...
- Page 5 Dimension: 224 × 141 × 203mm 3. Panel 1. POWER OUT: Connects to next fixture. 2. POWER IN: Connects to power supply. 3. MICROPHONE: Receives music signals for sound active mode. 4. FUSE (T 1A): Protects the unit from over‐voltage or short circuit. ...
- Page 6 4. Troubleshooting If the fixture does not work, no light, please check the connection of power cable, also measure the mains voltage on the main connector 5. Cleaning And Maintenance The cleaning must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: moist, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the fixture. Clean with lint‐free cloth using normal glass cleaning liquid. Always dry the parts carefully. Clean the surface at least every 30 days. Never use alcohol or solvents. ...
- Page 7 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 2004/108/EC. EN55103‐1: 2009 ; EN55103‐2: 2009; EN61000‐3‐2: 2006 + A1:2009 + A2:2009; EN61000‐3‐3: 2008. & Harmonized Standard EN 60598‐1:2008 + All:2009; EN 60598‐2‐17:1989 + A2:1991; EN 62471:2008; EN 62493: 2010 Safety of household and similar electrical appliances Part 1: General requirements ...
- Page 8 Innovation, Quality, Performance ...
