Avision FT-1109H User Manual

Avision FT-1109H User Manual

Sheet-fed duplex scanner
Hide thumbs Also See for FT-1109H:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
Sheet-Fed Duplex Scanner
User's Manual
Regulatory model: FT-1109H
manual-en-250-0722-E-320E2+-v3
Avision Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT-1109H and is the answer not in the manual?

Questions and answers

Related Manuals for Avision FT-1109H

Summary of Contents for Avision FT-1109H

  • Page 1 Sheet-Fed Duplex Scanner User’s Manual Regulatory model: FT-1109H manual-en-250-0722-E-320E2+-v3 Avision Inc.
  • Page 2 Warranty The information contained in this document is subject to change without notice. Avision makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of fitness for a particular purpose. Avision shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 EMC Directive 2004/108/EC  CE compliance of this product is valid if powered with the correct CE-marked AC adapter provide by Avision. This product satisfies the Class A limits of EN55022, EN55024 and safety requirements of EN 60950. CE Warning This is a class A product.

  • Page 4: System Requirements

    User’s Manual ® As an ENERGY STAR Partner, Avision Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. *This machine is certified as Class 1 LED product. This means that this machine does not produce hazardous laser radiation.

  • Page 5: Table Of Contents

    User’s Manual Table of Contents Introduction..........1-1 Scanner Installation........2-1 Installing the Input Paper Tray...... 2-2 Installing the Output Paper Tray....2-4 Installing the Scanner Driver and Cables ..2-6 2.3.1 Connecting to Power......2-6 2.3.2 Turning on the Scanner..... 2-7 2.3.3 Installing the Scanner Driver .....
  • Page 6 User’s Manual The Paper Tab .......... 4-35 4.5.1 Cropping........4-36 4.5.2 Other Paper Selection ..... 4-41 The Multi-Feed Detection Tab...... 4-44 The Preview Tab ........4-52 The Options Tab........4-53 The Setting Tab ........4-62 4.10 The Imprinter Tab ......... 4-65 4.11 The Information Tab ......

  • Page 7: Introduction

    User’s Manual 1. Introduction Congratulations on your purchase of the color sheet-fed image scanner. With this scanner, you can scan documents from the auto document feeder increase your productivity. Before you install and operate the new scanner, please take a few minutes to read through this manual. It provides proper instructions for you to unpack, install, operate and maintain the scanner.
  • Page 8 User’s Manual Scanner Main Unit ADF Paper Tray ADF Output Paper Tray Software CD & Quick Guide USB Cable Power Adapter & Power Cord...
  • Page 9 User’s Manual Note: 1. Only use the AC adapter DA-48M24 (APD) included in the machine. Using other AC adapters may damage the machine and void the warranty. 2. The suitable power supply cord will be provided and evaluated when national approval. 3.

  • Page 10: Scanner Installation

    User’s Manual 2. Scanner Installation Precautions Keep the scanner out of direct sunlight. Direct  exposure to the sun or excessive heat may cause damage to the unit. Do not install the scanner in a humid or dusty place.  Be sure to use the proper AC power source.

  • Page 11: Installing The Input Paper Tray

    User’s Manual 2.1 Installing the Input Paper Tray Pull the ADF Release button to open the front cover. ADF Release Button Front Cover Insert the pin with a inclined plane on the right side of the Input Paper Tray to the hole on the rear of the scanner as illustrated.
  • Page 12 User’s Manual Use your left thumb to press the place near the pin with a inclined plane of the other side of the Input Paper Tray and then insert the pin to the hole of the scanner as illustrated. Press the place near the pin Hole...

  • Page 13: Installing The Output Paper Tray

    User’s Manual 2.2 Installing the Output Paper Tray Insert the smaller pin of the left side of the Output Paper Tray to the hole on the front of scanner as illustrated. Output Paper Tray...
  • Page 14 User’s Manual Use your thumb to press the place near the pin of the other side of the Output Paper Tray and then insert the smaller pin to the hole on the scanner as illustrated. Press the hinge area Hole The smaller pin...

  • Page 15: Installing The Scanner Driver And Cables

    User’s Manual 2.3 Installing the Scanner Driver and Cables NOTE: 1). The Windows system CD may be required when installing on some PC’s. 2). To ensure your computer can identify the USB scanner, please install scanner driver first before connecting the scanner to your computer.

  • Page 16: Turning On The Scanner

    User’s Manual 2.3.2 Turning on the Scanner Press the Power Switch button on the front panel, the Power LED will flash. When it is finished and ready to scan, the LED indicator will stop flashing and become steadily on. To turn off the scanner, press the Power Switch button for about 3 seconds, the Power LED will be off.

  • Page 17: Installing The Scanner Driver

    User’s Manual 2.3.3 Installing the Scanner Driver Place the supplied CD-ROM onto your CD-ROM drive. The software installation graphic appears. If not, run “setup.exe”. Contents on the installation graphic:  Install Button Manager V2: To use the buttons on the scanner, you need to install Button Manager V2. To ensure Button Manager V2 works properly, please FIRST install Button Manager V2 before installing the scanner driver.
  • Page 18 User’s Manual  Install Adobe Reader: To view the user’s manuals for the scanner and Button Manager V2, you need to use Adobe Reader to open and view the manuals in pdf file format. If you already have Adobe Reader installed on your computer, you may disregard this item.

  • Page 19: Connecting To Computer

    User’s Manual 2.3.4 Connecting to Computer Connect the square end of the USB cable to the USB port of your scanner. Connect the rectangle end to the USB port of your computer. The computer should detect a new USB device and prompt a “New Hardware Found”...
  • Page 20 User’s Manual Important! Please note for this model. Your computer will identify two USB devices. You have to install “Found New Hardware ” wizard twice to complete the installation. When the Finish dialog is prompted, click the Finish button. Click “View Manual” to view or print the detailed user manual for the scanner and bundled applications respectively.

  • Page 21: Completing Your First Scan

    User’s Manual 3. Completing Your First Scan 3.1 Loading Your Paper 3.1.1 Notice on Using the ADF Before using the ADF, please make sure that your paper meets the following specifications:  Document(s) can range in size from 2 by 3 inches to 11.69 by 17 inches.

  • Page 22: Placing Your Document In The Input Paper Tray

    User’s Manual 3.1.2 Placing Your Document in the Input Paper Tray Fanning Your Document Standard paper size should feed easily through the scanner. To avoid occasional paper jam when automatically feeding multiple documents, loosen the paper before loading. Document feeding Place your document with the text face down on the ADF Paper Tray.

  • Page 23: Verifying Your Scanner Installation

    User’s Manual Verifying Your Scanner Installation To verify if your scanner installation is correct, Avision provides you a useful test program called Avision Capture Tool. With this tool, you can perform simple scans and view the captured images. In addition, it helps you complete your scan at a rated speed.
  • Page 24 User’s Manual Actual Page Size Save File Path File Format Scan Setup Choose your desired file format from the File Format drop down list box. (Default is BMP, other choice includes TIFF, MTIFF, PDF, MPDF, GIF, and JPEG.) The supported file formats vary depending on your scanner model.
  • Page 25 User’s Manual Image Selection From the Image Selection Box, choose your desired image type for your scanned image. (Default is Front B&W) If you have a duplex scanner, choose Front and Rear to scan both sides of your document. Click OK to quit the Scanner Properties dialog box. (To learn more details about the Scanner Properties dialog box, please see the subsequent chapter, Using the Scanner Properties Dialog Box.)
  • Page 26 User’s Manual Thumbnail View Status Bar Fit Page View 11. You can view the scanned image in Fit Page ( ) or Actual Size (100%) button ( ) from the Viewing toolbars at the right side. 12. Click the Close box or Quit from the File menu to exit the Scan Validation Tool.

  • Page 27: A Glance Of The Scanner Properties Dialog Box

    User’s Manual A Glance of the Scanner Properties Dialog Box 1. Tab Options Choice: Image, Compression, Color Dropout, Paper, Multi-Feed Detection, Preview, Options, Settings, Information. 2. Image Choose your image type and the side of Selection Box document you wish to scan. Options vary based on type of scanner.

  • Page 28: Using The Scanner Properties Dialog Box

    User’s Manual 4. Using the Scanner Properties Dialog Box The Scanner Properties dialog box allows you to configure the scanner’s settings. It consists of several tabbed windows each of which will be described in this chapter. Note: In this chapter, all options are available based on a duplex (double-side) scanner.

  • Page 29: Buttons On The Scanner Properties Dialog Box

    User’s Manual 4.1 Buttons on the Scanner Properties Dialog Box The buttons on the Scanner Properties dialog box Buttons Description Defaults Click the Defaults button, the factory default settings will be shown on each tab. Scan After all the scan settings are satisfactory, click the Scan button to start scanning your document.
  • Page 30 User’s Manual The following table shows the default settings： Tab name Default settings Image Image：Front B&W Binarization：Dynamic Threshold Resolution：200 dpi Invert：Blank on White Scan Source：Auto Document Feeder Threshold：None Brightness：None Contrast：None Compression None Color Dropout None Paper Cropping：Automatic Deskew：Yes Orientation：Portrait OverScan：0.00 Unit：Inch Multi-Feed None...

  • Page 31: The Image Tab

    User’s Manual 4.2 The Image Tab The Image tab allows you to choose the front side and (or) the rear side of your document, the type of image, and to set several basic scan settings. Note that except for the resolution, you can set individual scan settings for the front side and the rear side.

  • Page 32: The Image Selection Box

    User’s Manual 4.2.1 The Image Selection Box The Image Selection box includes the image type document side option. If you wish to scan both the front side and the rear side of your color document, you can check both Front Color and Rear Color at the same time.
  • Page 33 User’s Manual Example 2：Scanning a two-sided color document, one in B&W(Drop Blue Color：Threshold：10, Background：79), the other in color Side/Image Selection Rear Front Image Type Description Color Choose Color if you wish to scan a color image for your original in color. Gray Choose Gray image if your original contains actual shades of gray.
  • Page 34 User’s Manual Front/Rear Auto Color Detection: Click to automatically detect and scan the front or the rear page of your color document in color image mode. If your document is in colors, the scanner will automatically scan the document into a color image. If your document is non-color, you can choose the output to be either B&W or Gray from the Non-Color Selection option.

  • Page 35: Other Image Options

    User’s Manual 4.2.2 Other Image Options This is the process of converting a Binarization grayscale or color image to a bi-tonal image. There are several different methods of performing this conversion. Options: Dynamic Threshold, Fixed Processing, Halftone 1~5, Error Diffusion. Dynamic Threshold: Selecting Dynamic Threshold allows the scanner to dynamically evaluate each document...
  • Page 36 User’s Manual Fixed Processing: Used for black-and- white and other high contrast documents. A single level is set to determine the black- and-white transition. The threshold is programmable over the entire density range. Fixed Processing sets Contrast to 0. If Fixed Processing is selected, Contrast is not available.
  • Page 37 User’s Manual Error Diffusion Image 4-10...
  • Page 38 User’s Manual Threshold Used to convert a grayscale image to a bi-tonal image. The value ranges from 0 to 255. A low threshold value produces a lighter image, and can be used to subdue backgrounds and subtle, unneeded information. A high threshold value produces a darker image, and can be used to help pick up faint images.
  • Page 39 User’s Manual Gray Document Type: Choice: Normal, Photo, Document Three options of document type are provided when you choose Gray as the image type for your scanned document. Choice: Normal, Photo, Document.  Document: Choose Document if your original contains pure text or a mixture of text and graphic since it is an optimal setting for regular business document.
  • Page 40 User’s Manual Normal Photo Document (Threshold: 230) Normal Photo Document (Threshold: 230) 4-13...
  • Page 41 User’s Manual Adjusts the lightness or darkness of an Brightness image. The higher the value, the brighter the image. Drag the slider to the right or left to increase or decrease the brightness. The range is from –100 to +100. Adjusts the range between the darkest and Contrast the lightest shades in the image.
  • Page 42 User’s Manual Resolution A good control of the resolution results a good detail of an image that scans. The resolution is measured by dots per inch (dpi). Normally, the greater the dpi number, the higher the resolution and the image file size.
  • Page 43 User’s Manual Invert Reverses the brightness and the colors in the image. The default setting is Black on a White background. Reverse mode is White on a Black background. For color images, each pixel will be changed into its complementary color at the command of Invert.
  • Page 44 User’s Manual Scan Choice: Auto Document Feeder: Used to scan Source  multiple pages. Flatbed: Used to scan a single page. For  example, pages from newspaper clipping, paper with wrinkles or curls. Flatbed (book): Used to scan several  inside pages from book.
  • Page 45 User’s Manual Color The purpose of Color Matching is getting the Matching accurate color. This option uses the default parameters (ICC profile) to adjust the colors of the image. Choice: None, Document, Photo  None: Choose “None” to disable this option.

  • Page 46: Scanning Color Images

    User’s Manual 4.2.3 Scanning color images The following options are available for scanning color images. Brightness  Contrast  Resolution  Invert  4.2.4 Scanning grayscale images The following options are available for scanning gray images. Brightness  Contrast  Resolution ...

  • Page 47: Editing Profiles

    User’s Manual 4.2.6 Editing Profiles The Scanner Properties dialog box allows you to change and save your frequently used scan settings into a profile. You can edit these profiles by renaming or deleting them. To add a new profile, Customize your settings. (For example, change your resolution, image type, cropping method, scan size, or other scan settings.) Click the Image tab and then choose “Profiles”...
  • Page 48 User’s Manual To load a profile, From the Image tab dialog box, choose your favorable profile from the “Profiles” dropdown list box. Your favorable profile will be immediately loaded and displayed on Scanner Properties dialog box. To delete a profile, From the Image tab dialog box, click “Profiles”...
  • Page 49 User’s Manual To rename a profile, From the Image tab dialog box, click “Profiles” to prompt the Edit Your Profile dialog box. Choose the profile you want to rename from the dropdown list box and then click the Rename button. Enter new name for the profile.

  • Page 50: The Compression Tab

    User’s Manual 4.3 The Compression Tab The Compression tab allows you to compress your scanned image and choose the level of compression. Bi-tonal images are normally compressed using CCITT standard called Group 4 (G4). Color and grayscale images are often compressed using JPEG technology.
  • Page 51 User’s Manual The Compression tab dialog box 4-24...

  • Page 52: The Color Dropout Tab

    User’s Manual The Color Dropout Tab 4.4.1 Color Dropout Selection Color Dropout tab allows you to drop either of the red, blue, or green color in your scanned image. If your image contains red color watermark or background, choose the R (Red) channel then any red watermark or background will be removed.
  • Page 53 User’s Manual To select a color on the Color palette, Click the Color Dropout tab from the Scanner Properties dialog box. Choose Gray or B&W from the Image Selection box and click “Custom” from the Color Dropout drop-down menu. The Color palette appears.
  • Page 54 User’s Manual Move your cursor over the palette. The cursor becomes a cross sign. Click to choose a color. The RGB values are changed simultaneously. 4-27...
  • Page 55 User’s Manual To select a color or view a color dropout result via the Preview window, Click the Preview tab to open the Preview dialog box. Insert your document to the scanner and click the Preview button to get a preview image at a low resolution.
  • Page 56 User’s Manual Click the Color Dropout tab. The Color Dropout dialog box is displayed with a Preview Window button. Click the Preview Window button to prompt the Preview window as shown. 4-29...
  • Page 57 User’s Manual Click the Eyedropper button ( ) and then move the cursor over the preview image. Click to select a color which you wish to remove. Click the Preview Result button to view the result after removing the specified color. 4-30...
  • Page 58 User’s Manual If the result is satisfactory, click “OK” to close the Preview window and return to the Color Dropout dialog box. On the Color Dropout dialog box, click the Scan button to perform your final scan. The specified color is removed accordingly.
  • Page 59 User’s Manual The Color Dropout dialog box 4-32...

  • Page 60: Other Color Dropout Options

    User’s Manual 4.4.2 Other Color Dropout Options Advanced Processing provides two options that can adjust your scanned image in the best optimal result. Filter This value is used to determine the color Threshold which will be dropped out. A lower value will drop more of the selected color out, while a higher value will leave more of the selected color in.
  • Page 61 User’s Manual Remove Blue, Threshold: 20, Background: Remove Blue, Threshold: 20, Background Level: 210 4-34...

  • Page 62: The Paper Tab

    User’s Manual 4.5 The Paper Tab The Paper tab allows you to define values relating to image output (i.e., Auto Crop or not, Scan Area, OverScan, Multi-Feed Detection). The Paper tab dialog box 4-35...

  • Page 63: Cropping

    User’s Manual 4.5.1 Cropping Cropping allows you to capture a portion of the document being scanned. Choice: Automatic, Fixed to Transport, EOP (End of Page) Detection, Automatic Multiple, Relative to Documents. Options Description Automatic Automatic adjusts the cropping window according to different document sizes. Use this option for batches of mixed-sized documents.
  • Page 64 User’s Manual Automatic This option allows you to place various Multiple sized documents such as photos, ID Cards, or business cards on the flatbed (if available) and lets you create multiple individually cropped images in one scan. Note: To correctly create multiple images, please make sure there is at least 12mm (0.5”) of space between each document.
  • Page 65 User’s Manual Relative to Document: (used for batches of same-sized documents) This option allows you to crop different areas on your documents and deliver these images in B&W, Gray, or Color separately. For example, there are applications which require you to store the entire document in B&W and a part of the document in color to save storage space.
  • Page 66 User’s Manual Click the Preview tab to display the Preview window. A black rectangular box appears to indicate the max. scan size your have just selected. The Image The selected Selection image A black rectangular Click the Preview button to view the entire image in low resolution to correctly crop your relative scan area.
  • Page 67 User’s Manual A Cross Sign Relative Area Check the B&W image from the Image Selection box to scan the entire document. Click the Scan button to start scanning the document in two image types and sizes. (See the result in below.) The entire document in B&W The relative area in color 4-40...

  • Page 68: Other Paper Selection

    User’s Manual 4.5.2 Other Paper Selection Deskew Use this option to automatically deskew a document. Note: If the skew angle is too great, some of the image may be cut off. Scan Area Choose your desired paper size with the drop-down list box. Or you may select a custom paper size by clicking the Scan Area box and then click Add to include in the choice.

  • Page 69: Transport Timeout

    User’s Manual Choose “Unknown Length” if you have a batch of long page document with unknown length. Choose “Enter Length” to enter the length and width of your documents or your desired scan size on documents. This is useful when you have a batch of documents with the same scan size or a batch of same-sized documents.
  • Page 70 User’s Manual Note: Within the specified timeout period, if you load your document to the feeder, the scanner starts scanning automatically. If your scanner has a flatbed option and you place your paper on the flatbed, after the timeout period, you need to click the Scan button on the TWAIN user interface to start scanning.

  • Page 71: The Multi-Feed Detection Tab

    User’s Manual The Multi-Feed Detection Tab Multi-Feed Detection Multi-Feed Detection allows you to detect overlapped document that go through the auto document feeder. Multi-Feed usually occurs due to stapled documents, adhesives on documents, or electro-statically charged document. Note： The availability of the function varies based on type of scanner.
  • Page 72 User’s Manual Additional Length Detection Additional Length Detection allows you to define the length of document being multi-fed. This value indicates the additional length exceeding your scan area. The Display window will show the size of the document as you change the value. A value of 0 indicates no additional length detection.
  • Page 73 User’s Manual By Length (Paper/Object)+Position: When a multi-feed is detected for the first time, the scanner memorizes the length of the document, the length and position of the object (photo or label) attached to the document. When you perform next scanning, this pattern of multi-feed will be bypassed.
  • Page 74 User’s Manual Detection Area This option allows you to specify a multi-feed detection area. To specify a multi-feed detection area, Choose Disable from the Intelligent Mode. The Detection Area will be enabled. Choose Inside the Range or Outside the Range. The detection area will be highlighted.
  • Page 75 User’s Manual Detection Area: Outside the Range, Box, Top: 3”, Bottom: 7” 4-48...
  • Page 76 User’s Manual Ultrasonic Detection Ultrasonic Detection allows you to set overlapped document by detecting paper thickness between documents. Note： The availability of the function varies based on type of scanner. There are two options available if Multi-Feed is detected. Stop Scanning after Multi-Feed ...
  • Page 77 User’s Manual Clear the Multi-Fed Paper: Auto If this is checked, once multi-feed is detected and scanning operation is stopped, the scanner will automatically clear the transport of the multi-fed paper. If this is not checked, once multi-feed is detected and scanning operation is stopped, you need to manually clear the transport of the multi-fed paper.
  • Page 78 User’s Manual How to add the sound alarm： 1. Click the Browse button on the right side of the speaker icon. The Open dialog box appears. 2. Choose your wave file. 3. Click the Open button. The wave file is added. Units Defines the primary measurement system.

  • Page 79: The Preview Tab

    User’s Manual 4.7 The Preview Tab The Preview tab allows you to preview (a low-resolution scan) your image before final scan. This preview image lets you allocate your scan area. You can choose your scan area by the “Scan Area” drop down list box or placing your cursor on the Display window and dragging it diagonally on the Display window.

  • Page 80: The Options Tab

    User’s Manual 4.8 The Options Tab The Options tab allows you to set following additional image processing settings. The Option tab dialog box 4-53...
  • Page 81 User’s Manual Flip Side Select “fanfold” to rotate the image Rotation of the reverse side to 180 degrees. This is applied to double-sided document which are viewed in portrait are sometime fed into the scanner in landscape or vice versa. Choice: Book, Fanfold.
  • Page 82 User’s Manual Rotate Image Choose the rotation angle from the drop down list if you wish to rotate your scanned image. Choice: None, 90°CW(clockwise), 90°CCW(counter clockwise), 180°, Auto based on contents. Auto rotate every even page. Rotate 90°CW Original Rotate 90°CCW Rotate 180°...
  • Page 83 User’s Manual Blank Page Check if you wish to remove the blank page Removal and move the slider to the left or right to your desired threshold. Choose White or Black if you wish to add white or black edge on the border of your scanned image. Edge Fill Original...
  • Page 84 User’s Manual Image Check the Mirror box if you wish to reverse the right Control and left side of your image. Option Original The Mirror Effect 4-57...
  • Page 85 User’s Manual Split By splitting an image, two separate images are Image created horizontally or vertically. This is useful for documents containing two pages per image when you want to save them as two images (one page for one image). Choice: None, Horizontal, Vertical.
  • Page 86 User’s Manual Despeckle Occasionally small dots or specks appear in the background of a scanned image. Remove unwanted speckles provides a cleaner image for OCR (Optical Character Recognition) processing, and also helps to reduce compressed file size. Define the speckles (also known as image noise) you wish to remove by specifying its number (size) and radius (range).
  • Page 87 User’s Manual Note:  The function is currently available for Black and White image only.  To scan at rated speed, it is recommended to set the noise radius up to 10 pixels. 4-60...
  • Page 88 User’s Manual Background This option allows you to set your scan Setting background. Choice: White Background, Black Background. Note: For a sheet-fed scanner with an auto document feeder, this option is currently available only in the “Auto crop” mode. For a scanner with a flatbed platen, this option is available either in the “Auto crop”...

  • Page 89: The Setting Tab

    User’s Manual 4.9 The Setting Tab The Setting tab allows you to set the following settings: The Setting tab dialog box Energy Saving Check the Enable Energy Saver box Control and move the slider to the right to set the amount of time to start the energy saver after your last action.
  • Page 90 User’s Manual Cache Mode: None, Page Number, Memory Size. This option allows you to assign a specified memory size from the available RAM to process the image data. By specifying a smaller memory size, you can free more memory for other applications you are running.
  • Page 91 User’s Manual Show Scanning Check and the scanning progress bar Progress will be shown during scanning. Show Warning Check to show the warning messages Message such as “ADF pad count exceeds 50,000 scans (the number varies based on type of scanner). Please replace the ADF pad and reset the pad count.”...

  • Page 92: The Imprinter Tab

    User’s Manual 4.10 The Imprinter Tab The Imprinter tab allows you to print alphanumeric characters, date, time, document count and custom message on your scanned image if digital imprinter is selected or at the back of your document if external imprinter is selected. Choice: External Imprinter, Digital Imprinter.
  • Page 93 User’s Manual Contents Print All Check Print All to automatically print the text at all pages of your documents. Uncheck Print All to print the text for the first page of your documents only. Custom Enter your custom text to be included in your print string.
  • Page 94 User’s Manual String Choose your string orientation. Orientation Choice: Normal, Rotated, Vertical, Vertical Inversion, 90 degrees CW, 90 degrees CCW Normal Rotated Vertical Vertical Inversion 90 degrees CW 90 degrees CCW If you check the digital imprinter to stamp text on your scanned image, the illustration of normal and rotated string is shown below: Rotated Normal...
  • Page 95 User’s Manual Print Choose the position you wish to print your Position string. Move the slider to the right to increase the value or to the left to decrease the value. Range: 0~355mm, default:0 mm The value indicates the height from the bottom of your paper to the last letter of your string.

  • Page 96: The Information Tab

    User’s Manual 4.11 The Information Tab The Information tab displays the following system and scanner information. The Information tab dialog box The “Report” button： If you encounter any error message while using the scanner, click the Report button. A report.txt file (C:\AVxxx) will be generated.
  • Page 97 User’s Manual The “Reset Pad Count” button： After scanning approximately 30,000 pages (the number varies based on type of scanner) through the Auto Document Feeder (ADF), the ADF pad may be worn out and you may experience problems with document feeding. In this case, it is highly recommended to replace the ADF pad with a new one.

  • Page 98: Isis Interface Operation

    User’s Manual 5. ISIS Interface Operation * Please refer to the preceding chapter, Scanner Installation, to install ISIS scanner driver. You may start the supplied QuickScan software application to scan via the ISIS user interface. The ISIS driver operation method is similar to the TWAIN’s. Every function on the ISIS interface screen is briefly described as below: Mode: Select one of scan modes, including B&W, gray, color...

  • Page 99: Using The Buttons

    User’s Manual 6. Using the Buttons The following picture shows the 4 buttons and 1 function screen on the scanner. Power Switch Scan Button Cancel Button Function-Select Function Button Screen...

  • Page 100: Installing Button Manager V2

    User’s Manual 6.1 Installing Button Manager V2 Button Manager V2 provides you an easy way to scan your document and then link the scanned image to your designated software application. All this can be done by a simple touch of the button on the scanner.
  • Page 101 User’s Manual The Button Panel shows the first five scanning buttons. Right-click the button (function) you wish to check. The Button Properties window appears. Name of the Selected Button Button Name Image Mode Basic Scan Selection Parameters Folder and file name for the scanned image...

  • Page 102: Using Button Manager V2 With Default Function Numbers And Predefined Tasks

    User’s Manual 6.3 Using Button Manager V2 with Default Function Numbers and Predefined Tasks The scanner is shipped with nine preconfigured button settings for your frequently tasks such as scan-to-folder, scan-to-email, or scan-to-printer. The following table shows these factory default settings. You can change any of these settings. Button Name Destination/...
  • Page 103 User’s Manual Scan To Select this Auto Color Detection, button when you 200 dpi, Simplex, want to scan a JPEG, Auto Crop document and send the image to your designated application (default: MS Paint) E-mail Select this Auto Color Detection, button when you 200 dpi, Simplex, want to scan a...
  • Page 104 User’s Manual Select this Auto Color Detection, button when you 200 dpi, Simplex, JPEG, want to scan a Auto Crop document and save the image to a network file server such as FTP. ShareP Select this Auto Color Detection, oint button when you 200 dpi, Simplex, JPEG, want to scan a...
  • Page 105 User’s Manual Note:  To accurately use the default settings, you need to setup your computer in an internet environment and install the necessary software applications such as E-mail software, or printer before installing Button Manager V2.  To send your scanned images to a network server such as FTP, Microsoft SharePoint, or Google Docs, make sure you have the previledge to access the network server.

  • Page 106: Scanning From One Touch Of The Buttons

    V2, please refer to the user’s manual in the supplied CD. You may also use Button Manager V2 on your desktop by starting Button Manager V2 from All Programs or double clicking the Avision Scanner Utility from the Control Panel.

  • Page 107: Maintenance

    User’s Manual 7. Maintenance Cleaning the ADF From time to time the pad assembly and feeding rollers may become contaminated with ink, toner particles or paper dust. In this case the scanner may not feed documents smoothly. If this occurs please follow the cleaning procedures to return your machine to its original state.
  • Page 108 User’s Manual ADF Roller ADF Pad ADF Roller...

  • Page 109: Cleaning The Calibration Area

    User’s Manual 7.2 Cleaning the Calibration Area Press the ADF Release button. Open the front cover to the left. Wet a clean lintless cloth with some isopropyl alcohol. (95%) Wipe the glass and the white area as illustrated in below from side to side to rid the dust or dirt.

  • Page 110: Replacing The Snap-In Pad Module

    User’s Manual 7.3 Replacing the Snap-in Pad Module After scanning approximately 100,000 pages through the ADF, the pad may be worn out and you may experience problems with document feeding. In this case, it is highly recommended to replace the pad module with a new one. For ordering the pad module, please consult your nearest dealer and follow the procedure below to replace it.

  • Page 111: Troubleshooting

    User’s Manual 8. Troubleshooting 8.1 Clearing a Paper Jam In the event of a paper jam, follow the procedures below to remove the paper: Pull the ADF Release Button on the left side. Gently open the front cover to the left. Carefully pull the paper out of the ADF unit.

  • Page 112: Questions And Answers

    User’s Manual 8.2 Questions and Answers Paper becomes jammed during Question: scanning. Answer: 1) Open the front door. 2) Pull out the jammed paper carefully. 3) Close the front door. More than one sheet of paper are Question: fed into the scanner. 1) Open the scanner front door.
  • Page 113 User’s Manual Question: Why does my scanned image always come out too dark? Answer: 1) Please adjust the screen settings to SRGB. 2) Please adjust the brightness settings on the screen from application software. When I choose optical resolution Question: to be 600 dpi, the "auto crop"...

  • Page 114: Technical Service

    User’s Manual 8.3 Technical Service Before contact Avision, please prepare the following information:  Scanner serial & revision number (located on the bottom of the scanner);  Hardware configuration (e.g., your host CPU type, RAM size, free disk space, display card, interface card);...
  • Page 115 User’s Manual China Area Hongcai Technology Limited 7A,No.1010,kaixuan Road,Shanghai 200052 P.R.C. TEL :+86-21-62816680 FAX :+86-21-62818856 E-MAIL : sales@avision.net.cn Web Site: http://www.avision.com.cn Europe Area Avision Europe GmbH Bischofstr. 101 D-47809 Krefeld Germany TEL: +49-2151-56981-40 FAX: +49-2151-56981-42 E-MAIL: info@avision-europe.com Web Site: http://www.avision.de...

  • Page 116: Specifications

    User’s Manual 9. Specifications All specifications are subject to change without notice. Model Number： FT-1109H Scanner Type: A3 sheet-fed Scanner Optical Resolution: 600 dpi Scanning Modes: Black & White Gray Color ADF Capacity: 100 pages (75 g/m+² or 20 lb.) 150 pages (60 g/m²...

  • Page 117: Index

    User’s Manual Index Automatic, Fix to Transport, 4-30 EOP Detection, Ａ Custom Font Normal, Fixed Width, 4-59 Additional Length Detection, Ｄ Auto Color Detection sensitivity, 4-7 default settings, 4-35 Deskew, Ｂ Despeckle, 4-52 Noise Number, Noise Radius, B&W, 4-6 4-52 4-27 Background Level, Document Type...
  • Page 118 User’s Manual Ｐ Ｉ Print All, 4-59 Intelligent Mode (Skip Print Position, 4-61 Multi-feeds) Disable, By Ｒ Length(Paper/Object), By Position, By Reset Pad Count, 4-63 Length(Paper/Object)+Posi Reset Roller Count, 4-63 tion, 4-39 Resolution, 4-15 4-16 Invert, 4-49 Rotate Image, Ｊ Ｓ...
