Summary of Contents for Polaroid tdae-03219
- Page 2 11Last Page...
- Page 3 21Last Page...
-
Page 4: Important Safety Instructions
Safety Information IMPORTANT SAFETY INSTRUCTIONS READ INSTRUCTIONS- All the safety and operating instructions should be read before the product is operated. RETAIN INSTRUCTIONS- The safety and operating instructions should be retained for future reference. HEED WARNINGS- All warnings on the product and in the operating instructions should be adhered FOLLOW INSTRUCTIONS- All operating and use instructions should be followed. - Page 5 Safety Information This product should not be placed in a built-in installation such as a book case or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. 11. POWER SOURCE- This product should be operated from the type of power source indicated on the marking label.
-
Page 6: Replacement Parts
Safety Information 17. POWER LINES- An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. - Page 7 Contents Unit and Accessories Stand Base Screws x9 Stand Neck TV Set Adaptor Batteries Manual Remote Products and Features • 32”(31.5 measured diagonally) wide screen TV • 1366(H) x 768 (V) native resolution for Full-HD performance • Integrated ATSC TV tuner for true digital connections •...
-
Page 8: Location Of Controls
Location of Controls Introduction Front View Speaker Stand Base Power indicator Remote Sensor Note : IR Infrared Receiver IR signals from the remote control. (Power on/Standby) LED Indicator: Press Power to turn on and off. Side View DVD Slot Input Button Menu Button Channel up button Channel down button... -
Page 9: Rear View
Location of Controls Rear View Headphone Jack 7. HDMI 3 PC Audio IN 8. Coaxial 75 ohm Antenna Socket/Cable 9. USB Input PC IN 10.Composite : Video Input HDMI Input 1 11.Component Video Input HMDI Input 2 12. L/R Audio Output 81Last Page... -
Page 10: Wall Mounting
It is strongly recommended to contact a technician for professional assistance for wall mount installation Polaroid is not responsible for any damage to the product or injury to yourself or others resulting from the wall0mounting. - Page 11 External Devise Connections You can enjoy picture, sound and a PC monitor by connecting a DVD player, video game system or computer to the input located on the rear of the LED TV set. For the cable, use a commercially available audio/video cable. For more information about external device connections, see the operation manuals of you external devices.
-
Page 12: Remote Control
Remote Control Button 13. Input Numeric Buttons 14. Return previous Picture button 15. Display Button Sound Button 16. Sleep Set Volume + 17. Channel + Mute Button 18. Channel Volume - 19. Menu Exit button 20. Stop OK or Enter button 21. - Page 13 DVD Remote Control Play/Pause button 11. Stop Button Eject Button 12. Setup Button Fast Reverse 13. Next Chapter Fast Forward 14. Previous Chapter Language Button 15. Slow Zoom 16. Subtitle Menu 17. GOTO Angle 18. Title Program 19. A-B 10. Intro 20.
-
Page 14: Inserting Remote Control Batteries
Remote Control Inserting Remote Control Batteries On the Back of the remote, control, push down the catch on the battery compartment cover and lift to remove it. Insert the two AA batteries supplied, ensuring that you follow the polarity diagram inside the battery compartment. -
Page 15: Using Remote Control
Using Remote Control Changing Channels Press the “CH /” buttons to change higher or lower stored main channels and sub-channels. Press numeric button “0-9” and”•” button and press number “2” button. Then hit the “ENTER” button to confirm. To review the stored Channel Press “CH-List”... - Page 16 Operating Your TV Once you have connected your TV to an antenna or cable system, plugged the TV in, and put batteries in the remote, you are ready to use the TV. The first thing you should do is program your TV to memorize all of the available channels in your area.
- Page 17 Operating Your TV Picture Menu Description Picture Settings: Press button to enter the Picture Settings menu Picture mode: Select between Dynamic, Standard, Movie, User and Power Saving. You may select the picture mode directly by pressing the PICTURE button on the remote control.
-
Page 18: Sound Menu
Operating Your TV OSD Menu 1. Advanced Picture Settings: Press button to enter the Advanced Picture Settings. Dynamic Contrast: Select the dynamic contrast mode between Off, Low, Medium and High. Film Mode: Activate or deactivate the Film Mode. Noise Reduction: If the broadcast signal receiver is weak you can select the DNR option to reduce the video noise level between Off, Low, Medium, High. - Page 19 Operating Your TV Equalizer Settings: Press button to enter the Equalizer Settings menu. Use / button to select the mode between User, Off, Rock, Pop, and Jazz. You could press button to enter the item and use the / buttons to adjust. You could come back to the Mode selecting item by pressing button.
- Page 20 Operating your TV Parental Control You must enter the password to gain access to the Parental Control menu. The default password is 000. You may modify the following options: V-Chip: Press button to enter V-Chip menu. Canada V-Chip: Press button to enter the Canada V-Chip menu Movie Rating The Movie rating (MPAA) is used for original movies rated by the Motion Picture Association of...
- Page 21 Operating Your TV TV Ratings: Use / buttons to select the desired rating & press button to block or unblock. Rating Description Rating Description Fantasy violence TV-Y All children Violence TV-Y7 Children over seven years of age Sexual situations TV-G General Audience Adult Language Sexually...
-
Page 22: Setup Menu
Operating your TV 5. Setup Menu Description Caption Display: Press button to enter the “Close Caption” Menu. Caption Display: Activate or Deactivate the displaying. Analog Caption Type: Allows you to select the advanced selection among: Service 1, Service 2, Service 3, Service 4, Service 5, and Service 6. -
Page 23: View Channel Information
Operating Your TV Blue Screen: Turn on/off the blue screen function when there is no signal. No Signal Power Off: The TV will turn off automatically if there is no signal after 10 minutes. Operation Power Off: The TV will turn off automatically if there is no operation on the TV after 3 hours. - Page 24 DVD Operation Basic Operation Press the Power button on the TV or remote control, then press the INPUT button to select DVD mode. If there is no disc in the DVD player the screen will show “NO DISC”. Insert the disc according to the picture next to the disc slot.
- Page 25 DVD Operation OSD Language This is used to select the OSD language. Screen Saver Start the screen saver, the screen saver image will appear when the player stops or the picture is frozen for a few minutes. This saver can keep the screen from being damaged.
-
Page 26: Audio Setup
DVD Operation Audio Setup Speaker Setup In the “Audio Setup page” press “” button to select “Speaker Setup” item; press “OK Enter” or “” button to get into the “Speaker Setup Page” Downmix LT/RT A disc recorded multi-channel soundtrack, the output signal will be incorporated to left and right channel/ Stereo A Disc recorded multi-channel soundtrack;... -
Page 27: Dolby Digital Setup
DVD Operation Dolby Digital Setup Dynamic This is used to set the compression ratio in order to control; the sound (volume) contrast. You must press Stop twice to enter Preference Page or NO Disc. TV Type This is selected when the player is connected to a PAL System TV. Multi The player will set the TV system according to the disc in the tray. - Page 28 DVD Operation Prefence Setup Audio-If a language listed below is recorded on the disc; you can play the sound in such language. If not, the recorded language will be used. Subtitle-If a language listed below is recorded on the disc, you can set the subtitles to be displayed in such language;...
- Page 29 DVD Operation Parental When playing disc with parental lock function, you may select an Age Control Grade according to grade of disc and your own preference. For example, if PG is selected, DVD Disc rated higher than PG grade cannot be played.
- Page 30 Trouble Shooting Your television is designed to give you trouble-free performance for many years. If you have a problem with your TV, try the solutions listed below. There is no picture or sound or TV doesn’t turn on. Make sure the TV is plugged in, Make sure MUTE is not set on.
- Page 31 Care & Maintenance This television receiver represents a fine example of electronic engineering and construction. As such it should be treated with care. We offer the following suggestions so you will enjoy this product for many years to come. Keep it dry. If water should get on it, wipe it off immediately.
- Page 32 Technical Specification TV Section Television System NTSC American TV Standard ATSC(8vsb terrestrial) ATSC compliant 8VSB Channel Coverage Terrestrial(analog) 2-69 Cable TV(analog) 1-125 Terrestrial(digital) 2-69 Cable TV(digital) 1-135 Antenna 75-ohm unbalanced antenna terminal for VHF/CAT/UHF Audio-Audio Output 1 W + 1W LCD Panel Panel Size 32 Inches(diagonal)
