Summary of Contents for Polaroid 65T7U

  • Page 2: Table Of Contents

    Contents Important Safety Instructions..........Safety Information.

  • Page 3: Important Safety Instructions

    Important Safety Instructions before this product is operated. for future reference. should be adhered to. instructions. plug has two blades with one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your replacement of the obsolete outlet.

  • Page 4: Safety Information

    Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical safety The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product.
  • Page 5 Safety Information FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 6: What Is Included/Tv Placement Setup

    What is Included/TV Placement Setup Unit and Accessories Base Stand 65" UHD LED SMART TV Remote Control 6 Screws TV Set with Batteries TV Stand Installation /Removal 400mm 200mm Four mounting holes Wall Mounting VESA mounting pattern is 400 x 200mm.

  • Page 7: Front/Back View

    Front/Back View NOTICE:There is a square glue to protect the IR model，it can be removed after instal the base. Button Functions illuminates green when the TV is turned on. illuminates red when the TV is in POWER LED: standby mode. Receives IR signals from the remote control.

  • Page 8: Connecting To External Devices

    Connecting to External Devices Connecting external devices to your LED TV AUDIO VIDEO RJ45 HDMI3 HDMI2 DEBUG OPTICAL HDMI1 USB2 USB1 (ARC 0.5A 0.5A AUDIO L/R: Stereo audio input VIDEO IN: Video intput RJ45:Network connection port. OPTICAL:Connect a digital sound system to this jack. DEBUG:Used for software debugging...

  • Page 9: Remote Control

    Remote Control 1. POWER: Turn the TV on and off. : Press th is button to cut off the sound of the TV set temporarily, press again to resume. 3. Digital Buttons(0-9, -): Directly select channel with digital buttons. 4. List: Press it to show channel list and favorite list on screen.

  • Page 10: Install The Batteries

    23. VUDU: Press this button to select VUDU application. 24. pandora: Press this button to select pandora application. 25. CC: Press this button to adjust CC mode. Install the Batteries If the remote control fails to operate the TV functions, replace the batteries in the remote control.

  • Page 11: Basic Operations

    Basic Operations Menu Operation First Time Installation to start and finish following steps. Select the Environment as you need. Select the OSD language...
  • Page 12 Read to decide whether or not to accept the “DATA COLLECTION AND FIRMWARE UPDATES NOTICE”. Select the country.
  • Page 13 Set up the TV time setting. Read to decide whether or not to accept the “End User License Agreement.”...
  • Page 14 Select whether or not to connect the network. Select the Antenna Type to start auto tuning to search for programs, when finished, the programs Note: If you wanna restart the initial setup after the first time, you can select “Restore Default”...

  • Page 15: Input Setup

    Menu system instruction Input Setup Press SOURECE button to display the input source list, Press EXIT button to quit. Picture Menu Press MENU button to display the main menu.
  • Page 16 Picture Mode Choose among Standard, Movie, User and Dynamic/Soccer depending on the region. It will be set to “User” mode automatically when you adjust any of the following six items. Contrast Adjust the difference in color and light between parts of the picture. Brightness Adjust the lightness of the picture.
  • Page 17 Aspect Ratio Choices are Auto, 4:3, 16:9, Movie, Just Scan or Panorama. Note: The choices of aspect ratio differ by different regions or sources. Noise Reduction: Eliminate noise in the picture. Choices are Off, Low, Middle and High. MPEG Noise Reduction Eliminate noise generated while creating digital picture signals.

  • Page 18: Sound Menu

    Dynamic Contrast Turn on or turn off the function of dynamic contrast. Film Mode Turn on or turn off the function of film mode. Sound Menu Press MENU button to display the main menu. Press ▼ / ▲button to select SOUND in the main menu. On Time Sleep Timer Auto Sync...
  • Page 19 Sound Mode Choose among Standard, Music, Movie, Sport/Soccer and User depending on the region. Balance Control the sound balance between the right and left speaker. Auto Volume Turn on to adjust the sound volume depending on the input signal. Surround Sound Help to create rich and wider sound from stereo sound sources.

  • Page 20: Channel Menu

    Advanced Effect DAP 1. DAP Enable: Turn on or turn off the DAP function. When it is turned on, the following four items can be adjusted. 2. DAP Mode: Select the desired DAP Mode. 4. Dialog Enhancer: Select the effect of dialog enhancer. 5.
  • Page 21 Auto Tuning DTV Manual Tuning ATV Manual Tuning Manually search for the ATV programs. When a program is found, press RED button to save it. Before ATV manual tuning, there are related items to be adjusted firstly, which differ by different sources as following instructions.
  • Page 22 Program Edit Edit the programs. You can delete programs, add programs to the favorite list, and so on. Signal Information detail information about the signal. Only available when there is signal in DTV.

  • Page 23: Time Menu

    Time Menu Press MENU button to display the main menu. Auto Sync Select the mode of auto sync to be “Auto” or “Manual”. Clock when Auto Sync is set to “Manual”.
  • Page 24 Sleep Timer Set to turn off the TV set automatically. Choices are Off,10, 20, 30, 60, 90, 120, 180 and 240 minutes. Time Zone Summer Time You can turn on or turn off this function.

  • Page 25: Setup Menu

    Setup Menu Press MENU button to display the main menu. OSD Language Select your desired OSD language. Audio Language corresponding to the signal.
  • Page 26 Closed Caption Restore Default Restore Menu options to the factory defaults, and restart the initial setup. Note: User data on this TV will lose completely after operating this feature. HDMI Link Command and control HDMI devices connected to the TV set. 1.

  • Page 27: Advanced Menu

    HDMI EDID Switch the version of Extended Display Identification Data. Location Select the TV using environment between Home and Store. Home Mode: “Home” mode is recommended for home viewing. Store Mode: “Store” mode is used to display the TV in a store or the like. It will consume more energy in “Store”...

  • Page 28: Network Menu

    Network Menu Press MENU button to display the main menu. Wired Network 1. Connect the network cable to the LAN port at the back of the TV. 3. Select “Wired Network”, and then select “Auto Input”, wait a few seconds, the network configuration will be finished successfully.

  • Page 29: Home Features

    Home Features and access an application. Media Player You can view movie, music and photo files from your USB storage devices. Connect USB storage device to USB input terminal. Press HOME button and select “Media” to enter media player. Movie Menu Press MENU to display or exit movie menu while playing the movie.
  • Page 30 Music Menu The music menu includes the following items: Play/Pause, Stop, Skip Previous, Skip Next, Fast Reverse, Fast Forward, Play Mode, Information and Play List. Photo Menu Press MENU to display or exit photo menu while viewing the photo. The photo menu includes the following items: Play/Pause, Stop, Rotate CW, Rotate CCW, Skip Previous, Skip Next, Zoom, Information, Play List and Play Mode.

  • Page 31: Troubleshooting

    Troubleshooting If the device performance fails, check whether the detected problem is in the following table. If your device still fails, contact customer service. SYMPTOM POSSIBLE CAUSE REMEDY Signal cable is loose or not Ensure signal cable is not loose or connected, loose or connected.

  • Page 32: Specifications

    Specifications Model 65T7U TV System NTSC Resolution 3840x2160 cd/m2 Brightness Power Consumption 198W Power Supply AC 100-120V~50/60Hz Connectivity VIDEO IN RJ45 RF Antenna Input HDMl input x 3 OPTICAL Output Multimedia Playback Format Multimedia File Extension Categories Video .avi/.mp4/.mkv/.mov/.mpg/.dat/.vob/.ts/.flv Music .mp3/.m4a/.aac/.ac3/.wav...
