2 0 0 5
VOLVO
S60
Introduction
Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your
Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this
vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and
maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts
at all times in this (or any other) automobile. And, of course, please do not operate a vehicle if you may be affected by
alcohol, medication or any impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels
attached to the driver's door opening and on the left wheel housing in the engine compartment.
For further information please contact your retailer, or:
In the USA:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2005 S60R and is the answer not in the manual?

Questions and answers

Related Manuals for Volvo 2005 S60R

Summary of Contents for Volvo 2005 S60R

  • Page 1 Introduction Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
  • Page 2 The manual is structured so that it can be used for reference. For this reason, it should be kept in the car for ready access. Do not export your Volvo to another country before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the...
  • Page 3 Volvo and the environment Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
  • Page 4 Properly dispose of any vehicle-related waste such as used motor oil, used batteries, brake pads, etc. When cleaning your car, use Volvo's own car care products, all of which have systematically been adapted to the environment.
  • Page 5 10. Parking brake (hand brake) 11. Center console switches 12. Climate control 13. Audio system 14. 12 V socket 15. Hazard warning flashers 16. Glove compartment 17. Panel vents 18. Text window 19. Temperature gauge 20. Odometer/ Trip odometer/Cruise control indicator 21.
  • Page 6 Contents Safety Instruments and controls Climate control Interior Locks and alarm Starting and driving Wheels and tires Car care Maintenance and service Specifications Audio Index Back Cover Contents Top of Page...
  • Page 7 Seat belts Not wearing a seat belt is like believing "It'll never happen to me!" Volvo, the inventor of the three-point seat belt, urges you and all occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
  • Page 8 Extending the lap belt To buckle a seat belt: Pull the belt out far enough to insert the latch plate into the receptacle until a distinct click is heard. The seat belt retractor is normally "unlocked" and you can move freely, provided that the shoulder belt is not pulled out too far. The retractor will lock up as follows: if the belt is pulled out rapidly during braking and acceleration...
  • Page 9 Driver's side airbag As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS) to complement the three-point seat belt system. The inflatable airbag is installed folded up in the center of the...
  • Page 10 When installing any accessory equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible. pg. 5 Safety Passenger side airbag The airbag on the front passenger side is folded up in a compartment above the glove compartment.
  • Page 11 WARNING! Children must never be allowed in the front passenger's seat. Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the back seat of any vehicle with a front passenger-side airbag.
  • Page 12 This is a normal characteristic and does not indicate fire. NOTE: Volvo's dual-threshold, dual-stage airbags use special sensors that are integrated with the front seat buckles. The point at which the airbag deploys is determined by whether or not the seat belt is being used, as well as the severity of the collision.
  • Page 13 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car. The SRS system is a supplement to the seat belts.
  • Page 14 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars. The system is designed to supplement the protection provided by the three-point seat belt system.
  • Page 15 Never try to repair any part of the SRS or SIPS bag systems yourself. Any interference in the system could cause malfunction and serious injury. All work on these systems should be performed by an authorized Volvo retailer. pg. 12 Safety...
  • Page 16 - Never try to open or repair any components of the SIPS airbag system. This should be done only by an authorized Volvo service technician. - In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened.
  • Page 17 2 0 0 5 VOLVO Instruments and controls pg. 25 Instruments and controls Instrument panel Indicator and warning symbols Switches in the center console Steering wheel adjustment Lighting panel Lighting panel, Manually unlocking the fuel filler door Turn signals Windshield wipers/washer...

  • Page 18: Indicator And Warning Symbols

    coolant level - see page 139. 4. Trip odometer The trip odometers are used for measuring shorter distances. The right-hand digit gives tenth of a mile/kilometer. Press the button for more than 2 seconds to reset. Change between trip odometers 1 and 2 using one short press on the button.
  • Page 19 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to an authorized Volvo retailer and have the brake system...
  • Page 20 If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected. pg. 29 Instruments and controls Supplemental Restraint System SRS If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system.
  • Page 21 URGENT: Refer to your owner's manual. For additional information, please contact your Volvo retailer. MANUAL: SERVICE Take your car to an authorized Volvo retailer for inspection at your convenience (but preferably before REQUIRED: the next scheduled maintenance service). FIX NEXT Have the system affected inspected at the next scheduled maintenance service.

  • Page 22: Switches In The Center Console

    - SEE page 141 MANUAL* * These messages apply to R-line models only. 1) Yellow warning symbol, see page 27. 2) Red warning symbol, see page 27. pg. 31 Instruments and controls Switches in the center console The positions of these buttons may vary, depending on the specifications of the vehicle Four-C active chassis system (option) Please see page 97 for information on adjusting the active chassis...
  • Page 23 Folding head restraints This button is used to fold down the outboard rear head restraints. The ignition key must be in position I or II or the engine must be running. NOTE: If the head restraints have been folded down, they must be returned to their original position manually. The head restraints should be in the upright position before the rear seat backrests are folded down.

  • Page 24: Steering Wheel Adjustment

    Volvo recommends the use of daytime running lights. If, however, you would prefer to have these lights turned off (USA only), please consult your Volvo retailer. Please note that the use of daytime running lights is mandatory in Canada.
  • Page 25 Parking lights on. The parking lights should be switched off when you leave the car to help avoid battery drain. Headlights, parking lights, license plate lights and instrument panel illumination are on if the ignition key is in position II. If the headlight switch is in this position, all lights will go out when the ignition is switched off.
  • Page 26 Replace the cabin air filter with a new one at the recommended intervals. Please refer to your Warranty and Service Records Information booklet, or consult your Volvo retailer for these intervals. The filter should be replaced more often when driving under dirty and dusty conditions. The filter cannot be cleaned and therefore should always be replaced with a new one.

  • Page 27: Air Distribution

    Climate control maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a(HFC134a). This substance will not deplete the ozone layer. The system contains 2.2 lbs (1000 g) R134a and uses PAG oil.
  • Page 28 Air vents in the door pillars A Open B Closed C Horizontal air flow D Vertical air flow Direct the outer air vents toward the side windows to defrost. In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows. pg.
  • Page 29 Temperature These controls are used to individually set the temperature for both sides of the passenger compartment. Please note that the compartment will not be heated or cooled faster by setting the temperature higher or lower than necessary. Set the control to the temperature you prefer. Defroster This function defrosts/de-ices the windshield and front side windows.
  • Page 30 The air conditioning functions only at temperatures above 32° F (0° C). While the Defroster function is selected, the air conditioning is temporarily activated to dehumidify the air, even if you have manually switched the air conditioning off. This will only function if the blower is not switched off. Recirculation Press this switch to engage the recirculation function (air in the passenger compartment recirculates - no fresh air enters the compartment).
  • Page 31 Select one of the following three functions by pressing 1, 2 or 3 times. 1. The AUT LED lights. The air quality sensor is now activated. 2. No LED lights. Recirculation is not activated unless needed to cool the passenger compartment in a warm climate. 3.
  • Page 32 Blower Blower speed can be increased or decreased by turning the knob. If the knob is set to 0, the air conditioning function is automatically disengaged. Temperature Turn the control to set the temperature for the driver's and passenger's sides of the car. For cooler air, the air conditioning function must be engaged.
  • Page 33 Press again for more than 3 seconds. The LED lights for 5 seconds to confirm your selection. Recirculation is always disconnected when you select Defroster. Air distribution Use the air distribution control positions (marked with dots) between the different symbols to fine-tune air distribution for maximum comfort.

  • Page 34: Front Seats

    2 0 0 5 VOLVO Interior pg. 59 Interior Front seats Interior lighting Floor mats Storage compartments Rear seat and trunk Spare wheel, tools and jack pg. 60 Interior Front seats Manually adjusted front seats 1. Front-rear adjustment: lift the bar and move the seat to the position of your choice.
  • Page 35 pg. 61 Interior Folding the backrests in the front seat The front passenger seat backrest can be folded to a horizontal position to make room for a long load. Fold the backrest as follows: Move the seat as far back as possible. Adjust the backrest to the upright position.
  • Page 36 Passenger seat: The seat can only be adjusted if the ignition key is in position I, II or if the engine is running. Power seat control panel Seat adjustment If your Volvo is equipped with power seats, the following may be adjusted with the two switches at the side of the seat: A - Front edge of seat (raise/lower)

  • Page 37: Interior Lighting

    WARNING! Because the driver's seat can be adjusted with the ignition off, children should never be left unattended in the car. Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel. Do not adjust the seat while driving.
  • Page 38 You can disconnect the automatic function by pressing the courtesy light button for more than 3 seconds. Briefly pressing the courtesy light button again automatically reconnects the function. The courtesy light timer periods can be changed. Contact your Volvo retailer. Rear reading lights Reading lights - front/rear The reading lights can be switched on or off by pressing the respective buttons.
  • Page 39 Vanity mirror The light comes on when you open the cover. Floor mats Volvo offers floor mats specially manufactured for your car. They must be properly placed and secured in the mat clips. WARNING! An extra mat on the driver's floor can cause the accelerator pedal to catch. Check that the movement of the accelerator pedal is not impeded.

  • Page 40: Keys And Remote Controls

    2 0 0 5 VOLVO Locks and alarm pg. 73 Locks and alarm Keys Remote controls Locking and unlocking Child safety lock Alarm pg. 74 Locks and alarm Keys and remote controls Keys Two types of keys are provided with your car; master keys and a service (valet) key. The master key, the remote control, and the central locking button may all be used to lock and unlock all of your car's locks.
  • Page 41 If you misplace a key, take the other keys to an authorized Volvo retailer for reprogramming as an antitheft measure. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following condition: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 42 Using the remote control Button 1: Press to extend the key. This button must also be pressed when the key is folded back into the slot in the side of the remote control unit. Button 2(Lock): Press once to lock all doors, and the trunk. Button 3(Approach light): Press this button when approaching the car at night to light up the interior courtesy light, parking lights, license plate lights and the lights in the sideview mirrors.

  • Page 43: Locking And Unlocking

    3. Press the cover back into place. Ensure that the rubber seal is correctly positioned to help keep out moisture. Note: The old battery should be disposed of properly at a recycling center or at your Volvo retailer. pg. 77 Locks and alarm...
  • Page 44 Locking and unlocking the car from the inside The switch on the driver's door armrest can be used to lock or unlock all doors and the trunk, and to set the alarm. Opening/locking the trunk lid with the remote control Do as follows to unlock the trunk lid only: Press the "Open trunk"...

  • Page 45: Child Safety Lock

    Opening the trunk from the inside Opening the trunk from the inside (U.S. models only) The S60 is equipped with a florescent handle on the inside of the trunk lid, which can be used in an emergency situation to open the trunk from the inside. Pull the handle down to release the trunk lid. After use, the handle must be pushed back into its original position before the trunk can be closed.
  • Page 46 Control for child safety lock - right rear door WARNING! Remember, in the event of an accident, the rear seat passengers cannot open the doors from the inside with the buttons in position A. pg. 80 Locks and alarm Alarm Alarm The alarm is automatically armed whenever you lock your car.
  • Page 47 minutes. Audible alarm signal An audible alarm signal is given by a battery powered siren. One alarm cycle lasts for 25 seconds. "Panic" button In an emergency situation, this feature can be used to attract attention. Activate the "panic" button by pressing the red button on the remote control (see illustration on page 75) for at least 3 seconds or by pressing this button twice within 3 seconds.
  • Page 48 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact your Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the trunk has been opened.

  • Page 49: Table Of Contents

    Fuel requirements Octane rating Volvo engines are designed for optimum performance on unleaded premium gasoline with an AKI octane rating of 91 or above. AKI (ANTI KNOCK INDEX) is an average of the Research Octane Number, RON, and the Motor Octane...
  • Page 50 To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated" fuels; however, the octane ratings listed on this page must still be met.
  • Page 51 wear neoprene gloves while handling a fuel filler nozzle. Use of Additives With the exception of gas line antifreeze during winter months, do not add solvents, thickeners, or other store-bought additives to your car's fuel, cooling, or lubricating systems. Overuse may damage your engine, and some of these additives contain organically volatile chemicals.

  • Page 52: Starting The Car

    * If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 87 Starting and driving...
  • Page 53 CAUTION: Automatic transmission The engine should be idling when you move the gear selector. Never accelerate until after you feel the transmission engage! Accelerating immediately after selecting a gear will cause harsh engagement and premature transmission wear. Selecting P or N when idling at a standstill for prolonged periods of time will help prevent overheating of the automatic transmission fluid.

  • Page 54: General Information

    Steering wheel lock The steering wheel lock might be under tension when the car is parked. Turn the steering wheel slightly to free the ignition key. In order to help reduce car theft, make sure the steering wheel lock is engaged before leaving the car. WARNING! Never switch off the ignition (turn the ignition key to position 0) or remove the key from the ignition switch while the car is in motion.

  • Page 55: Manual Transmission

    Some of the above mentioned items and others are checked at the standard Maintenance Service intervals. NOTE: Vehicles equipped with automatic transmissions should use (D)rive as often as possible and avoid using "kickdown" to help improve fuel economy. WARNING! Driving with the trunk open: Driving with the trunk open could lead to poisonous exhaust gases entering the passenger compartment.
  • Page 56 5-speed manual transmission Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. * Clutch interlock The clutch must be fully depressed before you can start your car.

  • Page 57: Automatic Transmission (Option)

    Engaging reverse gear Never engage R while the car is moving. CAUTION: Be careful to avoid inadvertently engaging reverse while moving forward. pg. 92 Starting and driving Automatic transmission (option) Automatic transmission AW55- 50 (option) P Park Use this position when starting the engine or parking the car. Never use P while the car is in motion.
  • Page 58 The transmission will shift automatically between gears 3, 2 and 1 from this position. The transmission cannot shift up to fourth gear or (D)rive from third gear. L (Low gears) The transmission is locked in gears 1 and 2 when the selector is in this position. NOTE: Gears 4, 3, or L can be used if you are driving in a mountainous area, towing a trailer or to increase engine braking effect.

  • Page 59: Geartronic (Option)

    Kickdown can be used for maximum acceleration or when passing at highway speeds. Automatic transmission - adaptive system The automatic transmission is controlled by an adaptive system that constantly monitors the way in which the transmission functions. It senses and adapts each gear shift for optimal performance. Cold starts When driving before the engine has reached its normal operating temperature, the transmission will shift up at a slightly higher engine speeds to heat the three-way catalytic converter as quickly as possible.
  • Page 60 The automatic transmission is controlled by an adaptive control system that constantly monitors the way in which the transmission functions. It senses and adapts each gear shift for optimal performance. The system also monitors your particular driving style and adapts gear shifting accordingly. Automatic transmission - shift gate positions You can move the gear selector freely between the (MAN)ual and (D)rive positions while driving.

  • Page 61: All Wheel Drive (Option)

    Tire dimensions Volvo recommends that you always drive on tires of the same brand, size, construction (radial), tread pattern, load-, speed-, traction-, temperature-, and treadwear rating. Never drive on mixed tires, except for brief periods when the temporary spare tire is in use.
  • Page 62 The FOUR-C (Continuously Controlled Chassis Concept) active chassis system, consisting of Comfort and Sport modes, is available as an option. NOTE: The S60 R has a standard FOUR-C system consisting of Comfort, Sport, and Advanced sport modes. The buttons for controlling these driving modes are located in center instrument panel, above the ventilation system panel vents, see the illustration below.

  • Page 63: Brake System

    If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to a Volvo retailer and have the brake system inspected.
  • Page 64 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to a Volvo retailer and have the brake system inspected.
  • Page 65 2 0 0 5 VOLVO Wheels and tires pg. 113 Wheels and tires General information Tire inflation pressure tables Tire Pressure Monitoring System (TPMS) - option on certain U.S. models only Changing tires Tire designations Glossary of tire terminology Vehicle loading...
  • Page 66 Tread wear indicator The tires have wear indicator strips running across or parallel to the tread. The letters TWI are printed on the side of the tire. When approximately 1/16" (1.6 mm) is left on the tread, these strips become visible and indicate that the tire should be replaced.
  • Page 67 Tire inflation Check tire inflation pressure regularly. A table listing the recommended inflation pressure for your vehicle can be found on page 117. Tire inflation pressure placards are also located on the driver's side B-pillar (the structural member at the side of the vehicle, at the rear of the driver's door opening), or on the inside of the fuel filler door on Canadian models.

  • Page 68: Tire Inflation Pressure Tables

    117 Wheels and tires Tire inflation pressure tables Tire pressures recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed on your vehicle at the factory. a. These weights include the weight of all occupants of the car plus cargo.

  • Page 69: Tire Pressure Monitoring System (Tpms) - Option On Certain U.s. Models Only

    NOTE: TPMS indicates low tire pressure but does not replace normal tire maintenance. For information on correct tire pressure, please refer to the table on page 117, or consult your Volvo retailer. Erasing warning messages When a low tire pressure warning message has been displayed, and the tire pressure warning light has come on: 1.

  • Page 70: Changing Tires

    This message will remain on until wheels with TPMS sensors are mounted on the vehicle and it has been driven for at least one minute at a speed of 20 mph (30 km/h) or faster. TPMS valves can be fitted on winter wheels or full-size spare wheels/tires. Consult your Volvo retailer. CAUTION: When inflating tires with TPMS valves, press the pump's mouthpiece straight onto the valve to help avoid bending or otherwise damaging the valve.
  • Page 71 pg. 120 Wheels and tires Federal law mandates that tire manufacturers place standardized information on the sidewall of all tires (see the illustration). The following information is listed on the tire sidewall: The tire designation (the following figures are examples of a tire designation): 1.

  • Page 72: Glossary Of Tire Terminology

    This limit is set by the tire manufacturer. Recommended tire inflation pressure: inflation pressure, established by Volvo, which is based on the type of tires that are mounted on a vehicle at the factory. This inflation pressure is affected by the number of occupants in the car, the amount of cargo, and the speed at which the vehicle will be driven for a prolonged period.

  • Page 73: Uniform Tire Quality Grading

    Capacity weight All weight added to the curb weight, including cargo and optional equipment. When towing, trailer hitch tongue load is also part of cargo weight. NOTE: For trailer towing information, please refer to the section "Towing a trailer" on page 105.
  • Page 74 Snow chains can be used on your Volvo with the following restrictions: Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. If accessory, aftermarket or "custom" tires and wheels are installed and are of a size different than the original tires and wheels, chains in some cases CANNOT be used.

  • Page 75: Temporary Spare

    Recommended tire pressure (see the placard on the B-pillar or on the fuel filler door) should be maintained irrespective of which position on the car the temporary spare tire is used on. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING! Current legislation prohibits the use of the "Temporary Spare"...

  • Page 76: Changing Wheels

    pg. 126 Wheels and tires Changing wheels Insert flat end of lug wrench and turn/pull straight out Changing wheels The spare wheel is located under the carpet on the trunk floor. The jack and crank are secured in the wheel recess. There are two jack attachment points on each side of the car (see illustration on next page).
  • Page 77 pg. 127 Wheels and tires Attaching the jack Position the jack correctly on the bar in the attachment (see illustration above) and crank while simultaneously guiding the base of the jack to the ground. The base of the jack must be flat on a level, firm, non-slippery surface. Before raising the car, check that the jack is still correctly positioned in the attachment.
  • Page 78 greased. pg. 128 This page intentionally left blank. Contents Top of Page...

  • Page 79: Washing And Cleaning The Car

    2 0 0 5 VOLVO Car care pg. 129 Car care Washing and cleaning the car Paint touch up pg. 130 Car care Washing and cleaning the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage.
  • Page 80 Do not polish or wax your car in direct sunlight (the surface of the car should not be warmer than 113° F (45° C). CAUTION: Volvo does not recommend the use of longlife or durable paint protection coatings, some of which may claim to prevent pitting, fading, oxidation, etc. These coatings have not been tested by Volvo for compatibility with your vehicle's clear coat.
  • Page 81 Volvo also offers a special leather softener that should be applied after the cleaner and protectant. It leaves leather soft and smooth, and reduces friction between leather and other finishes in the vehicle.

  • Page 82: Paint Touch Up

    Paint repairs require special equipment and skill. Contact your Volvo retailer for any extensive damage. Minor scratches can be repaired by using Volvo touch-up paint. NOTE: When ordering touch-up paint from your Volvo retailer, use the paint code indicated on the model plate. The plate is located in the engine compartment.
  • Page 83 pg. 134 This page intentionally left blank. Contents Top of Page...

  • Page 84: Volvo Service

    Volvo service Maintenance service Volvo advises you to follow the service program outlined in the Warranty and Service Records Information booklet. This maintenance program contains inspections and services necessary for the proper function of your car. The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician.
  • Page 85 NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light (Malfunction Indicator) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. Timing belt For proper functioning of the engine and emission control systems, the timing belt and belt tensioner must be replaced every 105,000 miles (168,000 km).
  • Page 86 Never use a fast charger to charge the battery. The battery cables should be disconnected when recharging. The battery contains acid that is both corrosive and poisonous. It is important that the battery is handled in an environmentally friendly way. Let your Volvo dealer assist you. Hoisting the car If a garage jack is used to lift the car, the two jack attachments points should be used.

  • Page 87: Hood And Engine Compartment

    NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze. Top off with Volvo Genuine Coolant/Antifreeze only (a 50/50 mix of water and antifreeze).
  • Page 88 Opening the hood Pull the lever located under the left side of the dash to release the hood lock. Lift the hood slightly. Press up the release control located under the front edge of the hood (at the center) and lift. WARNING! Check that the hood locks properly when closed! Engine compartment...

  • Page 89: Oils And Fluids

    Please consult your Volvo retailer. Operation in hot climates When temperatures exceed 86° F (30° C) in your area, Volvo recommends, for the protection of your engine, that you use a heavier weight oil, such as SAE 10W/30. See the viscosity chart below.
  • Page 90 The API Service Symbol "donut" is divided into three parts: The top half describes the oil's performance level. The center identifies the oil's viscosity. The bottom half tells whether the oil has demonstrated energy-conserving properties in a standard test in comparison to a reference oil.
  • Page 91 NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze. Top off with Volvo Genuine...
  • Page 92 Replace: Every second year or 30,000 miles (48,000 km). The fluid should be replaced once a year or every 15,000 miles (24,000 km) when driving under extremely hard conditions (mountain driving, etc.) Always entrust brake fluid changing to an authorized Volvo retailer. Power steering fluid reservoir...
  • Page 93 Fluid type: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 or equivalent. Replace: No fluid change required NOTE: If a problem should occur in the power steering system or if the car has no electrical current and must be towed, it is still possible to steer the car.
  • Page 94 The VIN plate is located on the top left surface of the dashboard. The VIN is also stamped on the right hand door pillar. 6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing...

  • Page 95: Dimensions And Weights

    For further information regarding these regulations, please consult your Volvo retailer. 7 Child safety latch label 8. Loads and Tire Pressures - U.S. models only Certain models will only have one decal, depending on the specifications of the vehicle.
  • Page 96 See also page 105 for additional information * When driving for prolonged periods at temperatures above 86°F (30°C), the maximum recommended weight is 2000 lbs (900 kg). WARNING! When adding accessories, equipment, luggage and other cargo to your vehicle, the total capacity weight must not be exceeded.

  • Page 97: Capacities

    Automatic: JWS 3309 Different types of oil should never be mixed. Power steering Grade: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 or equivalent. Brake fluid Fluid type: DOT 4+ boiling point > 536°F (280° C) Cooling system...

  • Page 98: Three Way Catalytic Converter

    Type Positive pressure, closed system. Coolant Volvo original coolant/antifreeze Volume 5 cyl. non-turbo 8.5 US qts. (8.0 liters) 5 cyl. turbo 9.3 US qts (8.8 liters) The thermostat begins to open at 194°F (90° C). pg. 167 Specifications Three way catalytic converter Three-way catalytic converter cautions Keep your engine properly tuned.

  • Page 99: Electrical System

    SV5.5 WARNING! Bi-Xenon headlights (option) - due to the high voltage used by these headlights, these bulbs should only be replaced by an authorized Volvo service technician. pg. 170 Specifications Electrical system 12-volt system with voltage controlled generator. Single wire system in which the chassis and engine block are used as conductors, grounded on the chassis.

  • Page 100: Engine Specifications

    ** Automatic transmission: 350Nm at 32-100 rps, 258 ft. lbs at 1850-6000 rpm pg. 172 Specifications Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional information, features, and benefits are described in a separate information package in your glove compartment.
  • Page 101 1-800-263-0475 Technician certification In addition to Volvo factory training, Volvo supports certification by the National Institute for Automotive Excellence (A.S.E.). Certified technicians have demonstrated a high degree of competence in specific areas. Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued. These professional technicians are best able to analyze vehicle problems and perform the necessary service procedures to keep your Volvo at peak operating condition.
  • Page 102 Features: AM/FM radio, integrated 6-disc CD changer, 4x50W or 4x70W output plus 25W Dolby Pro Logic II, eleven speakers. A subwoofer mounted under the floor in the cargo area is available as an option. Consult your Volvo retailer. Compact disc care Before using a new disc for the first time, remove any burrs in the center/outer edge by running the stem of a pen or similar object around the hole/edge of the disc.
  • Page 103 Volvo does not recommend the use of plastic outer rings on the disc. Condensation may occur on discs/optical components of the changer in cold winter weather. The disc can be dried with a clean, lint-free cloth. Optical components in the CD changer may, however, take up to one hour to dry off.
  • Page 104 1. On/off - press Volume - turn 2. Buttons for selecting stored radio stations/discs in optional CD changer 3. Bass (press to release control and turn to adjust) 4. Treble (press to release control and turn to adjust) 5. Balance (left/right) - press to release control and turn to adjust 6.
  • Page 105 Volume control - ALARM If a CD is playing when the radio receives an alarm bulletin (available in certain areas only), the CD player enters pause mode. The bulletin is broadcast at the volume selected for this type of message. After the bulletin has been completed, the audio system reverts to the originally selected sound.
  • Page 106 Selecting a sound source The sound source (e.g. AM, FM, etc.) can be selected in two ways: Use the sound source buttons (see the center illustration above). Turn the SOURCE knob (see illustration above) to select a sound source (AM1, AM2, FM1, FM2, FM3, or CD). Press the knob to select the AM or FM band of your choice.
  • Page 107 Storing stations To store a selected station under one of the station setting buttons 1-6: 1. Tune to the desired station. 2. Press the button under which the station is to be stored and keep it depressed. The audio system sound will be interrupted for a few seconds and STORED will appear in the display.
  • Page 108 The RBDS or Radio Broadcast Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Coverage by local broadcasters may be limited at this time, but as the technology and benefits grow, you will find the radio in your car is equipped to take advantage of this system.
  • Page 109 PTY OFF News NEWS Current affairs AFFAIRS Information INFO Sports SPORT Education EDUCATION Drama DRAMA Art and culture CULTURE Science SCIENCE Entertainment VARIED Pop music POP M Rock music ROCK M Easy listening EASY M Light classics LIGHT M Classical music CLASSICS Other music OTHER M...
  • Page 110 2 0 0 5 VOLVO Index pg. 195 Index A/C (air conditioning) Adjustable steering wheel Air bags - dual threshold/stage Air distribution Air quality sensor Air vents Airbag - Side Impact (SIPS) Airbags Alarm All Wheel Drive All Wheel Drive - towing...
  • Page 111 Brake circuit Brake fluid Brake light Brake system Bulbs Capacities Capacity weight Carbon Monoxide - Important Warning Catalytic converter Ceiling lighting Central locking system - remote control Changing coolant Changing oil and oil filter Changing wheels Check Engine warning light Child restraint anchorages Child safety Child safety locks...
  • Page 112 Electrical system Electrically operated moonroof Electrically operated windows Engine - starting Engine compartment Engine oil Engine oil - checking Engine oil, capacity Engine specifications Environment Federal Clean Air Act FIX NEXT SERVICE Floor mats Fog lamp Fog light, rear Front fog light, changing Front fog lights Front park assist Front seat - backrest...
  • Page 113 Grocery bag holder Gross vehicle weight (GVW) Handling Hazard warning flashers Head restraint - center, rear Headlight flasher Headlight wiper blades Headlights Heated front seats High beam "flash" High beam indicator Hoisting the car HomeLink® Universal Transceiver Hood - opening Ignition switch Immobilizer (start inhibitor) Indicator and warning symbols...
  • Page 114 Locks Long distance trips Long loads - carrying Low beam bulb Lubricants Maintenance service Malfunction indicator light Manual climate control with air conditioning Manual transmission Messages in the display Moonroof Multifilter with air quality sensor Occupant safety Octane rating Odometer Oil pressure Oil quality Oil viscosity...
  • Page 115 Rear park assist Rear seat, folding backrests Rear suspension Rear window defroster Rearview mirror/door mirrors Recirculation REDUCE SPEED Refrigerant (A/C system) Refueling Remote control - central locking system Replacing the battery Reporting safety defects Roadholding Roof racks (load carriers) Run flat tires Safety Safety defects - reporting Safety system warning light...
  • Page 116 Stability systems Stability Traction Control (STC) Start inhibitor (immobilizer) Starting the car Steering wheel adjustment Steering wheel lock Stone chips, touching up STOP ENGINE Storage compartments Studded tires Sun visor Supplemental Restraint System (SRS) Supplemental Restraint System (SRS) - warning light Suspension Switches in the center console Tachometer...
  • Page 117 Vanity mirror Vanity mirror bulb, changing Vehicle Identification Number (VIN) Vehicle loading Vehicle weights VIN (Vehicle Identification Number) Volvo and the environment W - Winter Warning light, safety systems Warning symbol in center of dashboard Warranties Washer fluid reservoir Washing the car...
  • Page 118 When used properly and safely, they enrich the driving experience. Improperly used, any of these could cause a distraction. For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety: Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely.
  • Page 119 The following should be checked regularly: * 1 Washer fluid reservoir should be filled with water and solvent (wintertime: windshield washer anti-freeze). See page 143. 2 Power steering- When cold, the level must not be above the COLD mark and when hot it must not be above the HOT mark.
  • Page 120 Direction indicator/parking light Low beam High beam Fog light (option) *H3 on R-models Fog light Tail/parking light Brake light Side marker light Direction indicator Backup light pages 149-155 for more information on replacing bulbs. Contents Top of Page...
