This manual deals with the operation and care of your Volvo.
Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe driving in your
Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this
vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and
maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts
at all times in this or any other automobile. And, of course, please do not operate a vehicle if you may be affected by
alcohol, medication or any impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels
attached to the driver's door opening and on the left wheel housing in the engine compartment.
For further information please contact your retailer, or:
In the USA:
2 0 0 4
VOLVO
V70
In Canada:

Advertisement

Table of Contents
loading

Related Manuals for Volvo 2004 V70R

Summary of Contents for Volvo 2004 V70R

  • Page 1 This manual deals with the operation and care of your Volvo. Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
  • Page 2 Volvo Cars of North America Volvo Cars of Canada Ltd. Customer Relations 175 Gordon Baker Road P.O. Box 914 North York, Ontario M2H 2N7 Rockleigh, New Jersey 07647-0914 800-663-8255 800-458-1552 We also invite you to visit our Home Page on the Internet at: http://www.volvocars.com...
  • Page 3 Volvo reserves the right to make model changes at any time, or to change specifications or design, without notice and without incurring obligation.
  • Page 4 Volvo and the environment Volvo is committed to the well being of our customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
  • Page 5 Top of Page...

  • Page 6: Seat Belts

    Volvo also believes no child should sit in the front seat of a car.
  • Page 7 Always fasten the seat belts before you drive or ride. A chime will sound several times if the driver's seat belt is not fastened. To buckle: Pull the belt out far enough to insert the latch plate into the receptacle until a distinct click is heard. The seat belt retractor is normally "unlocked"...
  • Page 8 Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
  • Page 9 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
  • Page 10 SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible. pg. 5 Front airbags - SRS A self-diagnostic system incorporated in the sensor monitors the SRS.
  • Page 11 There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of airbags and seat belt tensioners.
  • Page 12 Collisions can occur where only one of the airbags deploys. NOTE: Volvo's dual-stage airbags: If the impact is less severe, but severe enough to present a clear injury risk, the dual-stage airbags are triggered at just 70% of its total capacity. If the impact is more severe, the dual-stage airbags are triggered with full capacity.
  • Page 13 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car. The SRS system is a supplement to the seat belts.
  • Page 14 Never try to open or repair any components of the SIPS airbag system. This should be done only by an authorized Volvo service technician. In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened.
  • Page 15 This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs. pg. 9 Volvo Inflatable Curtain (VIC)
  • Page 16 The IC system is a supplement to the Side Impact Protection System. It is not designed to deploy during collisions from the front or rear of the car or in rollover situations. Never try to open or repair any components of the IC system. This should be done only by an authorized Volvo service technician.
  • Page 17 If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced.

  • Page 18: Table Of Contents

    2 0 0 4 VOLVO Chapter 2 - Instruments, switches and controls pg. 23 Instruments, switches and controls Interior 24 Exterior 25 Instruments 26 Instrument panel 27 Indicator and warning lights 28 Text information window 30 Switches in the center console 31...

  • Page 19: Exterior

    pg. 25 Exterior pg. 26 Instruments...

  • Page 20: Instrument Panel

    pg. 27 Instrument panel 1 Turn signals 2 Text window 3 Temperature gauge The pointer should be approximately midway on the gauge when driving. Do not drive the car if the warning light is on. The text window will provide you with additional information. If the engine temperature remains high, check coolant level - see page 133.
  • Page 21 7 General warning light (see page 28). 8 High beam indicator light 9 Tachometer Indicates engine speed in thousands of rpm. Do not drive for long with the needle in the red section. The engine has an built-in function preventing too high an engine speed. When this function operates, you may discern some pulsation, which is normal.

  • Page 22: Oil Pressure Warning Light

    138. If the light stays on after restart, have the car towed to the nearest authorized Volvo retailer. After hard driving, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.

  • Page 23: Indicator And Warning Lights

    On-Board Diagnostic II (OBDII): As you drive, a computer called "OBDII" monitors your car's engine, transmission, electrical and emission systems. The CHECK ENGINE light will light up if the computer senses a condition that potentially may need correcting. When this happens, please have your car checked by a Volvo retailer as soon as possible.

  • Page 24: Text Information Window

    STOP SAFELY: Stop and switch off the engine - to help prevent serious risk of damage. STOP ENGINE: Stop and switch off the engine - to help prevent serious risk of damage. SERVICE URGENT: Take your car to an authorized Volvo retailer for inspection as soon as possible.

  • Page 25: Switches In The Center Console

    SEE MANUAL: Refer to your owner's manual. For additional information, please contact your Volvo retailer. SERVICE REQUIRED: Take your car to an authorized Volvo retailer for inspection at your convenience (but preferably before the next scheduled maintenance service). FIX NEXT SERVICE: Have the system affected inspected at the next scheduled maintenance service.

  • Page 26: Trip Computer

    This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. Four-C active chassis system: R-models only:...
  • Page 27 Trip computer controls and functions The four* trip computer functions can be accessed by twisting control B one step at a time in either direction. Twisting a fifth time** returns you to the original function. The trip computer can be reset (current data will be erased from system memory) by pressing RESET (button C). 1.

  • Page 28: Climate Control System

    2 0 0 4 VOLVO Chapter 3 - Climate control system pg. 45 Climate control system Ventilation 46 Climate control system - general information 47 Electronic Climate Control (ECC) 48 Manual climate control with air conditioning, A/C 52 pg. 46 Ventilation...

  • Page 29: General Information

    Air flow The air that is drawn into the passenger compartment is distributed from 14 ventilation points. Air vents in door pillars Air vents in door pillars A Open B Closed C Horizontal air flow D Vertical air flow Direct the air vents toward the rear side windows to demist. Direct the air vents toward the rear seat for the best heating/cooling effect.

  • Page 30: Cabin Air Filter

    The air conditioning is momentarily disengaged during full-throttle acceleration. ECC maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a.
  • Page 31 pg. 49 Electronic Climate Control (ECC) AUTO This function automatically regulates the Electronic Climate Control system so that the selected temperatures are maintained. The blower, heating, air distribution (air flow) and air conditioning are controlled. If you prefer to manually set any of these functions, the remaining functions will still be controlled automatically. Pressing the AUTO button overrides any settings that were previously made manually.

  • Page 32: Interior

    This function demists/de-ices the rear window and sideview mirrors. The LED in the switch will light up to indicate that the heating function is engaged. See page 38 for additional information on this function. CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface. pg.
  • Page 33 Press the switch to turn the air conditioning on or off. The "ON" or "OFF" LED will light up to indicate if the system is switched on or off. Other functions will still be regulated automatically (if the AUTO switch is on). The air conditioning functions only at temperatures above 32°...
  • Page 34 You can switch between these three functions by repeatedly pressing Keep the following in mind: Make it a rule to have the Air quality sensor activated at all times. Recirculation is limited in cold climates to avoid misting up. If misting occurs, you should deactivate the Air quality sensor. If the windows mist up, you can also use the windshield and side window defroster functions.

  • Page 35: Air Distribution

    This function demists/de-ices the rear window and sideview mirrors. The LED in the switch will light up to indicate that the heating function is engaged. See page 38 for additional information on this function. CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface. Recirculation Recirculation can be used to shut out stale air, exhaust, etc.
  • Page 36 Use the air distribution control positions (marked with dots) between the different symbols to fine-tune air distribution for the maximum comfort. pg. 54 Manual climate control with air conditioning, A/C Air distribution Contents Top of Page...
  • Page 37 2 0 0 4 VOLVO Chapter 4 - Interior pg. 55 Interior Front seats (electrically operated) 56 Front seats (manually operated) 58 Storage compartments 59 Storage compartment, front 60 Folding table in rear seat 62 Rear seat and cargo area 63...
  • Page 38 Turn the control for softer or firmer lumbar support. Move the seat as far rearward as possible for easiest access to the lumbar support control. Electrically operated seats with memory function (option)* Power seat control panel A Front edge of seat (raise/lower) B Forward - rearward C Rear edge of seat (raise/lower) D Backrest tilt...

  • Page 39: General Information

    happens, remove the object and wait 20 seconds before operating the seat again. * This option is only available on the driver's seat. pg. 57 Front seats Electrically operated seats - general information Adjusting the front seats: Passengers's seat: The passenger's seat can only be adjusted if the ignition key is in position I or II. Driver's seat: The driver's seat can be adjusted if the ignition key is in position I or II (see page 36).
  • Page 40 backrest: Move the seat as far rearward as possible Adjust the backrest tilt to the most upright position Lift the catches on the lower rear side of the backrest Without releasing the catches, push the backrest forward Move the seat as far forward as possible WARNING! Cover sharp edges on the load to help prevent injury to occupants.

  • Page 41: Cup Holders

    Clip for toll booth tickets, etc. WARNING! Make sure that no hard, sharp or heavy objects lie on or in any of the storage places where they might cause injury during heavy braking. Ashtray (option) To empty the ashtrays: Front seat, open the ashtray, pull out the insert. Rear seat, as above.
  • Page 42 To open only the upper lid: press the locking mechanism underneath the upper lid and fold the lid backwards to desired position. To open the upper and lower lid: lift the lid from underneath upwards and fold to desired position. pg.

  • Page 43: Coat Hanger

    Pen holder on the center console Coat hanger Use the coat hanger for clothes of normal weight. pg. 62 Folding Table in rear seat Folding Table (option) Pull the tab and fold the table section forward.
  • Page 44 Fold the armrest in the backrest forward. Fold out the table so that it rests on the armrest. Press to release the cup holder. You do not have to fold the backrest forward, if you only want to use the cup holder. To close: Fold the table section upward into place.

  • Page 45: Keys, Locks, Alarm

    2 0 0 4 VOLVO Chapter 5 - Keys, Locks, Alarm pg.75 Keys, Locks, Alarm Keys, Exterior courtesy lights, Locking and unlocking the car 76 Remote keyless entry system 77 Unlocking the tailgate, Central locking buttons 79 Alarm 80 Child safety locks - rear doors 82 pg.
  • Page 46 The headlights, parking lights, license plate lights and the lights in the sideview mirrors will now come on and remain on for 30, 60 or 90 seconds (the time interval is at your discretion and can be changed by an authorized Volvo retailer).

  • Page 47: Remote Keyless Entry System

    The car can also be locked/unlocked with the key. If one of the transmitters is misplaced, contact your nearest authorized Volvo retailer for replacement. Buttons in remote control 1 - Fold key in/out, 2 - Lock, 3 - Approach lighting 4 - "Panic"...
  • Page 48 button again (within 10 seconds) to unlock all doors, and the tailgate. NOTE: If the doors are unlocked with the remote, the locks will automatically reengage (re-lock) and the alarm will reset after 2 minutes unless a door has been opened. The lock/unlock and alarm features can also be utilized by using the keys.
  • Page 49 WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car. The alarm would be activated and would sound when one of the doors is opened. The doors must not be locked using the remote transmitter while the vehicle is occupied.

  • Page 50: Arming The Alarm

    Alarm The alarm is automatically armed whenever you lock your car. When armed, the alarm continuously monitors a number of points on the car. The following conditions will set off the alarm: The hood is forced open. The tailgate is forced open. A door is forced open.
  • Page 51 Temporarily turning off the inclination and movement alarm sensor(s) - accessory This button will only be found in cars equipped with the accessory inclination and/or movement sensors. FCC ID: MAYDA5823 This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 52 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact a Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the tailgate has been opened.

  • Page 53: Starting And Driving

    2 0 0 4 VOLVO Chapter 6 - Starting and driving pg. 83 Starting and driving Fuel requirements 84 Fuel Formulations 85 Refueling 86 Starting the engine 87 Manual transmission 89 Automatic transmission (AW5) 90 Automatic transmission (Geartronic) 92 All Wheel Drive 94...

  • Page 54: Fuel Requirements

    To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated fuels; however, the octane ratings listed on this page must still be met.

  • Page 55: Fuel Formulations

    Fuel Formulations Do not use gasoline that contains lead as a knock inhibitor, and do not use lead additives. Besides damaging the exhaust emission control systems on your car, lead has been strongly linked to certain forms of cancer. Many fuels contain benzene as a solvent. Unburned benzene has been strongly linked to certain forms of cancer. If you live in an area where you must fill your own gas tank, take precautions.

  • Page 56: Starting The Engine

    * If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 87 Starting the engine Starting the engine 1.

  • Page 57: Manual Transmission

    starting position. Release the pedal slowly when the engine starts. 4. To release the gear selector from the (P)ark position, the engine must be running (or the ignition key must be in position II) and the brake pedal must be depressed. While keeping firm pressure on the brake pedal, release the parking brake.

  • Page 58: Speed Manual Transmission

    5-speed manual transmission Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. This gear should be engaged at speeds above approx.

  • Page 59: Automatic Transmission Aw5

    Engaging reverse gear Reverse gear should only be engaged from a complete stop. CAUTION: Be careful that you do not inadvertently engage reverse while moving forward. pg. 90 Automatic transmission AW5 P (Park) Use this position when starting the engine or parking the car. Never use P while the car is in motion.
  • Page 60 Never engage R while the car is moving forward. N (Neutral) Neutral - no gear engaged. Use the parking brake. D (Drive) D is the normal driving position and should be used as often as possible to help improve fuel economy. The car should not be moving when shifting from R to the D position.
  • Page 61 Automatic transmission - shift gate positions The gear selector can be moved freely between N and D. Depressing the button on the front of the gear selector knob enables you to move the gear selector to positions P, R, N, D, 4, 3 and L.

  • Page 62: Automatic Transmission (Geartronic)

    pg. 92 Automatic transmission (Geartronic) P (Park) Use this position when starting the engine or parking the car. Never use P while the car is in motion. The parking brake should be set whenever the car is parked. The gear selector is mechanically locked in the P position (SHIFTLOCK). To release the gear selector from this position, the engine must be running (or the ignition key must be in position II) and the brake pedal must be depressed.
  • Page 63 Automatic transmission - adaptive system The automatic transmission is controlled by an adaptive control system that constantly monitors the way in which the transmission functions. It senses and adapts each gear shift for optimal performance. The system also monitors your particular driving style and adapts gear shifting accordingly.

  • Page 64: All Wheel Drive

    Tire dimensions Volvo recommends that you always drive on tires of the same brand, size, construction (radial), tread pattern, load-, speed-, traction-, temperature-, and treadwear rating. Never drive on mixed tires, except for brief periods when the temporary spare tire is in use.

  • Page 65: Four-C Active Chassis System

    The temporary spare tire is for temporary, low-speed, short-distance use only. Replace it with a full-sized tire as soon as possible, in accordance with "Tire Rotation" above. Do not drive on the temporary spare at speeds above 50 m.p.h. (80km/h) or for distances greater than 50 miles (80 km). Never install snow chains on a temporary spare.

  • Page 66: Driving Economy, Handling

    In this mode, shock absorption is stiffer to reduce the car's body sway during cornering and to provide more immediate steering response. If this setting was selected when the engine was switched off, Sport mode will be active when the engine is restarted. Advanced sport In this mode, movement of the shock absorbers is minimal, response from pressure on the throttle pedal is more direct, and body sway in curves or when cornering is sharply reduced.

  • Page 67: Points To Remember

    that capacity weight or maximum permissible axle loads are not exceeded. Speed-sensitive power steering (Option on certain models) With this feature, the steering is most responsive at lower speeds to make parking, driving in city traffic, etc., easier. The effect of the power steering diminishes as you accelerate for greater stability at highway speeds. Weight distribution affects handling At the specified curb weight your car has a tendency to understeer, which means that the steering wheel has to be turned more than might seem appropriate for the curvature of a bend.

  • Page 68: Roof Racks/Load Carriers

    Volvo has developed especially for your car. Volvo-approved removable roof racks are designed to carry the maximum allowable roof load for this vehicle: 220 lbs (100 kg). For Non-Volvo roof racks, check the manufacturer's weight limits for the rack.
  • Page 69 Check periodically that the load carriers and load are properly secured. Reducing wind noise and improving fuel economy To maximize fuel efficiency and minimize wind noise, Volvo recommends that load carriers be removed when not in use. pg. 99 Load carriers (models with rails)
  • Page 70 The load carriers are identical and can be placed anywhere along the roof rails. Reducing wind noise and improving fuel economy To maximize fuel efficiency and minimize wind noise, Volvo recommends that load carriers be removed when not in use.

  • Page 71: Wheels And Tires

    Laying wheel/tire assemblies on their sides for prolonged periods can cause wheel and/or tire damage. CAUTION: R-models only: 16" wheels may not be used. Consult your Volvo retailer about the types of wheels that may be mounted on R-models.

  • Page 72: Snow Chains

    Unbalanced wheels impair tire economy and driving comfort. Volvo does not recommend rotating the tires. However, if tires are rotated, they must be kept on the same side of the car so that they revolve in the same direction as before rotation.
  • Page 73 Failure to do so could reduce traction to an unsafe level or adversely affect handling. Volvo does not recommend tire rotation. However, as with any other radial tires, if rotated, the tires must be kept on the same side of the car so that they revolve in the same direction as before rotation.

  • Page 74: Vehicle Loading

    Vehicle loading The tires on your Volvo will perform to specifications at all normal loads when inflated as recommended on the tire information label located on the inside of the fuel filler door*. This label also lists vehicle load limits. Do not load your car beyond the indicated limits.

  • Page 75: Uniform Tire Quality Grading

    NOTE: Certain models may be equipped with a full-size spare tire. When used, it should be inflated to the same pressure as the tire it is replacing. *Please note that the tire information label indicates pressure for both comfort and fuel economy. pg.

  • Page 76: Changing Wheels

    Insert flat end of lug wrench and turn/pull straight out Changing wheels The spare wheel is located under the carpet on the cargo area floor. The optional subwoofer, located under the cargo area floor, must be removed to allow access to the spare wheel. See page 72 for instructions.
  • Page 77 attachment (B). See illustration on page 115. Be sure the jack is on a firm, level, non-slippery surface. Never allow any part of your body to be extended under a car supported by a jack. Use the jack intended for the car when replacing a wheel. For any other job, use stands to support the side of the car being worked on.
  • Page 78 Correct tightening order for wheel bolts Installing the wheel Clean the contact surfaces on the wheel and hub. Lift the wheel and place it on the hub. Make sure that you align the wheel with the guide stud on the wheel hub prior to installation.

  • Page 79: Maintenance/Servicing

    2 0 0 4 VOLVO Chapter 8 - Maintenance/Servicing pg. 117 Maintenance/Servicing Fuses 118 Replacing bulbs 122 Paint touch up 128 Washing the car 129 Cleaning the upholstery 130 Maintenance service, Warranty 131 Fuel/emissions systems 132 Drive belt, Coolant 133...

  • Page 80: Replacing Fuses

    If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by an authorized Volvo retailer. WARNING! Never use fuses with higher amperage that those stated on the following pages.
  • Page 81 Ordinary fuses Location Amperage 1 Accessories 2 Auxiliary lamps (option) 4 Oxygen sensors 5 Crankcase ventilation heater, solenoid valves 6 Mass airflow sensor, engine control module, injectors 7 Throttle module 8 A/C compressor, accelerator pedal position sensor, E-box fan 9 Horn 10 Tailgate wiper 11 Ignition coils 12 Brake light switch...

  • Page 82: Shiftlock

    Location Amperage 1 Low beam headlights 2 High beam headlights 3 Power driver's seat 4 Power passenger's seat 5 Speed-dependent power steering, vacuum pump 7 Heated seat - front left (option) 8 Heated seat - front right (option) 9 ABS/STC/DSTC 10 Daytime running lights 11 Daytime running lights 12 Headlight wipers (certain models)
  • Page 83 33 Fuel pump 34 Power moonroof 35 Central locking system, power windows - left door mirror 36 Central locking system, power windows - right door mirror 37 Rear power windows 38 Alarm siren * Please be aware that if this fuse is not intact, or if it is removed, the alarm will sound. pg.

  • Page 84: Replacing Bulbs

    17 All Wheel Drive control module 7.5A 18 - pg. 122 Replacing bulbs Replacing high/low beam headlight bulbs The headlight bulbs must be replaced from the engine compartment. CAUTION: Do not touch the glass on halogen bulbs with your fingers. Grease, oil or any other impurities can be carbonized onto the bulb and cause damage to the reflector.
  • Page 85 Reinstall the plastic cover and turn it clockwise until it is correctly in place (4). "TOP" must be upward. NOTE: If the vertical aim of your headlights needs to be adjusted for any reason (e.g., towing a trailer for extended periods), this should be done by an authorized Volvo retailer. pg. 123 Replacing bulbs To remove and install a high beam bulb (HB3): Switch off all lights and turn the ignition switch to position 0.
  • Page 86 Replacement of front parking light bulb Switch off all lights and turn ignition key to position 0. Remove the low beam cover by twisting counterclockwise. Pull out the bulb and its socket. Replace bulb. Press the bulb and its socket back into place. Check that the new bulb lights.
  • Page 87 Fit the bulb holder in place and twist it clockwise. Refit the sound insulation and put the access panel back in place. Replacement of rear turn signal and brake light bulbs Switch off all lights and turn the ignition switch to position 0. Using a screwdriver, carefully pry off the speaker grille.
  • Page 88 Front fog lights (option) CAUTION: Avoid touching the glass on the bulb with your fingers. Switch off all lights and turn the ignition key to position 0. Turn the bulb holder slightly counterclockwise to release it. Replace the bulb. The shape of the base of the bulb corresponds to the shape of the bulb holder. Reinstall the bulb holder by turning it slightly clockwise.

  • Page 89: License Plate Lights

    Reinstall the lens. pg. 126 Replacing bulbs License plate lights Switch off the ignition. Loosen the screws with a Torx screwdriver. Carefully pull out the lamp housing. Turn the bulb holder counterclockwise and pull it out. Pull out the defective bulb and insert a new one. Reinsert the bulb holder into the housing and turn it clockwise.

  • Page 90: Paint Touch Up

    These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. NOTE: Other bulbs may be difficult for you to replace yourself. Let an authorized Volvo retailer replace these bulbs if necessary.

  • Page 91: Washing The Car

    NOTE: When ordering touch-up paint from your Volvo retailer, use the paint code indicated on the model plate. The plate is located in the engine compartment. Minor stone chips and scratches Material: Primer - can Paint - touch-up bottle Brush Masking tape NOTE: When touching up the car, it should be clean and dry.
  • Page 92 damage. It is particularly important to wash the car frequently in the wintertime to prevent corrosion, when salt has been used on the roads. When washing the car, do not expose it to direct sunlight. Use lukewarm water to soften the dirt before you wash with a sponge and plenty of water, to avoid scratching.

  • Page 93: Polishing And Waxing

    131 Maintenance service, Warranty Maintenance service Volvo advises you to follow the service program outlined in the Warranty and Service Records Information booklet. This maintenance program contains inspections and services necessary for the proper function of your car. The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician.

  • Page 94: Specifications

    Maintenance services Your Volvo passed several major inspections before it was delivered to you, in accordance with Volvo specifications. The maintenance services outlined in the Warranty and Service Records Information booklet, many of which will positively affect your vehicle's emissions, should be performed as indicated.
  • Page 95 6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.
  • Page 96 * The Vehicle Identification Number (VIN) should always be quoted in all correspondence concerning your vehicle with the retailer and when ordering parts. All specifications are subject to change without prior notice. pg. 145 Dimensions and weights Dimensions Length - 185.4 in. (471 cm), V70 -186.2 (473 cm) Width - 71 in.
  • Page 97 WARNING! When adding accessories, equipment, luggage and other cargo to your vehicle, the total loaded weight capacity of the vehicle must not be exceeded. 1) Rear seat backrest up, load height - upper edge of backrest 2) Rear seat backrest folded down, load height - upper edge of front seat backrests/lower edge of rear window 3) Rear seat backrest folded down, load height - head lining (ceiling) * When driving for prolonged periods at temperatures above 86°...

  • Page 98: Engine Specifications

    * The max permissible axle loads or the gross vehicle weight must not be exceeded. pg. 147 Engine specifications Engine specifications Designation: Volvo B 5234 T3 Output 247 hp at 5200 rpm (184 kW/87 rps) Max. torque 243 ft. lbs. at 2400-5200 rpm (330 Nm/42-87 rps)

  • Page 99: Engine Oil

    V70R: 5.5 US qts (5.2 liters) Manual transmission oil M56 (five speed): 2.2 US qts. (2.1 liters) M66 (6 speed): 2.1 US qts. (2.0 liters) Automatic Transmission Fluid AW5: Only Volvo transmission oil (1161540-8). Do not mix with other oils.

  • Page 100: Power Steering Fluid

    Volume: 7.9 US qts (7.5 liters) Cooling system Type: Positive pressure, closed system. The thermostat begins to open at 194 °F (90 °C) Coolant: Volvo original coolant/antifreeze Power steering fluid ATF fluid Volume: 0.95 US qts (0.9 liters) Brake fluid DOT 4+ boiling point >536°F(280°C), P/N 9437433...

  • Page 101: Front Suspension

    Voltage: 12 Volt, capacity: 600 A/115 min reserve capacity. The battery contains corrosive and poisonous acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo retailer can assist you in this matter. Generator Rated output: max. current: 140 A Starter motor: Output: 1.7 kW...

  • Page 102: Volvo On Call Roadside Assistance

    151 On Call Roadside Assistance Volvo On Call Roadside Assistance Your new Volvo comes with a four-year On Call Roadside Assistance program. Additional information, features, and benefits are described in a separate information package in your glove compartment. If you have misplaced your package, dial: In the U.S.A.
  • Page 103 Technician certification In addition to Volvo factory training, Volvo supports certification by the National Institute for Automotive Excellence (A.S.E.). Certified technicians have demonstrated a high degree of competence in specific areas. Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued. These professional technicians are best able to analyze vehicle problems and perform the necessary service procedures to keep your Volvo at peak operating condition.

  • Page 104: Audio Systems

    2 0 0 4 VOLVO Chapter 10 - Audio systems pg. 153 Audio systems HU-613 overview 154 HU-803 overview 155 Audio system functions 156 Specifications 167 General information 168 NOTE: The text on the face of the radio, describing the button functions, may vary slightly depending on which audio system you have in your car.
  • Page 105 TV (option on certain models) 4. Fader - press and turn Balance - press, pull and turn 5. Radio - Station seek up/down Cassette - selecting next/previous track CD - Selecting next/previous track 6. Radio - Manual station selection Cassette - Fast winding forward/backward CD - Fast forwards/backward 7.

  • Page 106: Volume Control

    Internal CD changer Station scan - press TV (option on certain models) External CD changer (option) 7. Radio - Station seek up/down CD - Selecting next/previous track 8. Radio - Manual station selection CD - Fast forward/backward 9. CD eject 10.
  • Page 107 Adjust the bass by pressing the button to extend the control and turning it to the left (less bass) or to the right (more bass). A "detent" indicates "equalized" bass. Press the button back in when you have made the adjustment. Treble Adjust the treble by pressing the button to extend the control, pulling it out as far as possible, and then turning it to the left (less treble) or to the right (more treble).
  • Page 108 A - Setting station Press the left side of the button to select lower frequencies and the right side for higher frequencies. Set frequencies are displayed. B - Station seek up/down Press the left side (lower frequency) or right side (higher frequency) of the button to start the seek function. The radio seeks the next audible station and tunes it in.
  • Page 109 The RDS or Radio Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Please refer to the following pages regarding specific descriptions and operation of these functions.
  • Page 110 Traffic information (TP) -HU- 803 only This feature may not be apply in your area and only functions with FM broadcasts. (See previous page) Push the "TP" button for traffic information from RDS stations. "TP" is displayed when the function is connected. When the unit is in Cassette or CD mode, the FM radio function will seek in the background for a station with a strong signal broadcasting traffic information.
  • Page 111 Contents Top of Page...
  • Page 112 2 0 0 4 VOLVO HomeLink® Universal Transceiver (option) pg. 169 HomeLink® Universal Transceiver (option) HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled- devices (e.g., garage door openers, remote lighting, entry door lock). HomeLink®'s sun visor-mounted transceiver, powered by your car's electrical system, may then be used in place of your hand-held remote controls.
  • Page 113 4. Using two hands, push and hold both your hand-held transmitter's button and the transceiver button you wish to program. The indicator light will flash first slowly, then rapidly. Rapid flashing tells you the HomeLink® button has been successfully programmed. Release both buttons. 5.
  • Page 114 time to complete the training. The programmed button on your HomeLink® Universal Transceiver should now operate your garage door opener. The original hand-held transmitter can also be used, as desired, to operate the garage door. The remaining two HomeLink® buttons can be programmed in the same way. In the event of any problems in programming the HomeLink®...
  • Page 115 Contents Top of Page...

  • Page 116: Index

    2 0 0 4 VOLVO INDEX pg. 173 - 176 Index ABS - warning light Accessory lights Active chassis system Adjusting the steering wheel Advanced User Mode (AUM) - radio Air conditioning 48 - 51 Air filter - engine Air vents...

  • Page 117: General Information

    Automatic Locking Retractor (ALR) Automatic transmission 90, 91 - Cold starts - Geartronic 92, 93 - Kickdown 91, 92 - Sport mode Auxiliary socket - general information - using snow chains Backrest (center) - 3-section rear seat Battery 105, Battery maintenance 140, 141 - Replacing the battery - Ventilation hose...

  • Page 118: General Information

    Climate system - general information Clock Clutch interlock Coat hanger Coin compartment Cold weather driving Combination filter Coolant Cooling system - general information Courtesy light Courtesy lights (front) - replacing Courtesy lights - exterior Cruise control Cup holder Cup holder in the center console Detachable trailer hitch - installing Dimensions Direction indicators...
  • Page 119 Engine - starting 87, 88 Engine air filter Engine compartment Engine oil 105, 137, 138 Extension of cargo compartment Exterior courtesy lights Exterior features - overview Extra seat Fog light - rear Fog lights - front Folding passenger's seat backrest Folding table Four-C active chassis system Front airbags - SRS...

  • Page 120: Keylock

    Hazard warning flashers Head restraint (center) - 3-section rear seat Head restraint - center rear Headlight bulbs - replacing Headlight wiper blades - replacing Headlights Heated front seats Heated rear window Heated sideview mirrors Heating 48-51 Hoisting the car Holder for grocery bags Home Safe System HomeLink®...
  • Page 121 Locking steering wheel Long distance trip Long loads Maintenance service Malfunction indicator lamp Manual climate control with air conditioning 52-54 Manual transmission Memory function - front seats Mirrors Mirrors, sideview - memory function Moonroof Net - cargo Nylon cargo net Occupant safety Octane rating Odometer...

  • Page 122: Seat Belts

    Rear seat backrest Rear window - heated Rearview mirror Refrigerant Refueling Remote central locking system and sideview mirrors system Remote control - keyless entry system Remote control - Homelink® Universal Transceiver Remote keyless entry system Remote keyless entry system - replacing batteries Remote keyless entry system and driver's seat Removing the seat cushion Replacing bulbs...
  • Page 123 Start inhibitor (immobilizer) Starting the engine 87, 88 Steel grid Steering wheel adjustment Steering wheel lock Stop and Store bag Storage compartments Storage in the glove compartment Studded tires Subwoofer Supplemental Restraint System Suspension Switches in center console Tachometer Tailgate - locking/unlocking Tailgate wiper blade - replacing Temperature gauge Temporary spare tire...

  • Page 124: Whiplash Protection System (Whips)

    Volvo On Call Volumes (oils and fluids) Warning flashers Warning light - center Warning lights 28, 29 Warranty Washer fluid reservoir Washer fluid solvent Washing the car 129, 130 Waxing Weight distribution Wheels - changing 114, 115 Wheels and tires...

  • Page 125: Back Cover

    When used properly and safely, they enrich the driving experience. Improperly used, any of these could cause a distraction. For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety: Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely.
  • Page 126 the vehicle and others sharing the roadway. Avoiding distractions is part of that responsibility. The following should be checked regularly: * 1 Washer fluid reservoir should be filled with water and solvent (wintertime: windshield washer anti-freeze). See page 135. 2 Power steering - When cold, the level must not be above the COLD mark and when hot it must not be above the HOT mark.
  • Page 127 Bulbs Power Socket US no. Bulb Power Socket US no. 60 W HB 3 55 W 21 W BAU 15d - 21 W BA 15s 1156 55 W W2.1x9.5d 1157NA 21/4 W BA 15d BA 15s Contents Top of Page...

This manual is also suitable for:

2004 v702007 v70 r2007 v70

Table of Contents
