- Page 1 Performa System 12e, 18e, 24e & 28e Gas Fired Wall Mounted System Boilers User’s Operating Instructions Please keep these instructions safe. Should you move house, please hand them over to the next occupier.
- Page 2 41 590 89 Potterton Performa System 24e G.C.N 41 590 90 The boiler meets the requirements of Statutory Potterton Performa System 28e G.C.N 41 590 91 Instrument “ The Boiler (Efficiency) Regulations 1993 N 3083” and is deemed to meet the...
-
Page 3: This Appliance Must Be Earthed
1.0 Warnings “Benchmark” Installation, Commissioning and Service Safe Installation Record Log Book 1. The appliance is suitable for installation only in G.B. and I.E. and should be installed in Please ensure that your installer has completed the Installation accordance with the rules in force. For Ireland and Commissioning sections of the Log Book and hands the Log install in accordance with I.S.813 “I NSTALLATION... - Page 4 2.0 Introduction Introduction 1. Your Potterton Performa System is a gas fired, room sealed, powered flue boiler, providing central heating and hot water for your home. It is fully automatic and does not have a pilot light. Facia Panel 1. The facia panel is behind the hinged lower door.
-
Page 5: Operating The Boiler
3.0 Operating the Boiler Operating the Boiler 1. Ensure that the electricity and gas supplies are turned on. Check that the central heating pressure is between 0.2 and 1.0 bar (Fig. 4). 2. Turn the On/Off/Reset selector switch either anti-clockwise from the off position (Fig. 6) to both central heating and hot water or clockwise to domestic hot water only. - Page 6 3.0 Operating the Boiler Temperature Control 1. The water flow temperature can be adjusted between 30° C (± 5° C) minimum and 85° C (± 5° C) maximum. 2. Turn the control knob clockwise to increase the temperature (Fig. 9). 3.
- Page 7 1 minute in every 24 hours to prevent sticking. Safety Thermostat Reset 1. Your Potterton Performa System is fitted with an additional safety device, which shuts down the boiler in the event of the system or the boiler overheating. The safety thermostat neon ( ) will light in this instance (Fig.
- Page 8 3.0 Operating the Boiler Pressure Gauge Central Heating System Pressure 1. The water pressure in the central heating system is indicated by the pressure gauge. 2. With the system cold and the boiler not Fig. 14 operating the pressure should be between 0.2 Normal Pressure (when cold) and 1.0 bar.
- Page 9 4.0 Clearances and Check List 450mm 5mm Min 5mm Min Clearances around the Boiler (Figs. 19 & 20) 1. The minimum clear spaces needed around 200mm Min the boiler measured from the casing are as follows: 200mm Bottom 200mm Both sides - Front (In Operation) 450mm...
- Page 10 1. Any repairs to the boiler will usually be the responsibility of the Installer during the guarantee period after which spare parts may be obtained through approved Potterton stockists if required. 2. Quote the appliance name, model number and where possible the part number when ordering spares.
- Page 11 6.0 Notes...
- Page 12 Potterton, Baxi UK Limited, Brownedge Road, Bamber Bridge, Preston, Lancashire. PR5 6SN After Sales Service 08706 096 096 www.baxi.com 922.515.1 Comp N 5107332 - Iss 1 - 6/02...
